Rocstor ARCTICROC 4T Quick Installation Manual

LED Indicators / LED Anzeigen / Les Voyants LED
Power LED
Color
Power on
Green
Power off None
RAID Alert LED Color
Healthy None
Danger Blink Red
Error Red
Left
HDD LEDs
(Connection)
Disk error None
Data access White
Source HDD White
Disk Rebuild
Target HDD Blink White
General Notices
• Consistently make multiple backup copies of your data for your protection. Hard disk drives are subject to failure at any time.
• Rocstorage, Inc. shall not be held liable for loss of data or the restoration or recovery of data on the device. Please see complete
Limited Warranty Information in the User's Manual or on the Rocstor website (www.rocstor.com) for further details.
Capacity Disclaimer
Actual accessible hard drive capacity will indicate up to 10% lower than stated under different Operating Systems and
formatting. Therefore, a 500GB capacity drive may show up as a 450GB drive (approximately.)
Warranty Period
The Limited warranty period for Airhawk external hard drives is two years for parts and labor.
Technical Support / RMA
Tel: (888) 877-7716 (USA and Canada)
Tel: +1 (818) 449-2000 (Domestic and Internationals)
Fax: +1 (818) 884-8777
Hours: 9:00 am - 5:00 pm PST, Mon - Fri (excluding holidays)
Email: support@Rocstor.com
Trademarks Acknowledgements
© 2011, Rocstor, Rocsecure and Rocpower are registered trademarks of Rocstorage, Inc. Rocpro, Rocport, Rocbit, are the
trademarks of Rocstorage, Inc. "store your future", "secure your future" and "power your future" are the slogan marks of
Rocstorage, Inc. Apple, the Apple logo, Mac, Power Macintosh, FireWire, and Mac Pro, Leopard ... are trademarks of Apple
Computer, Inc. Microsoft, MS-DOS, Windows CE, Windows NT, Windows 98, Soft Windows, Vista ... are registered trademarks
of Microsoft Corporation. All other names are trademarks of their respective companies in the United States and other
countries. © 2000 - 2011
Designed/assembled/integrated in the U.S.A. using domestic and/or foreign components. Enclosure (without
hard drive) is made in China
Specifications, terms, warranties, descriptions, product and services herein are subject to change without notice. Ver.1207H
4
Number
RAID Mode Switch
of HDD's
RAID 0 (Striping) 2 or 4
RAID 1 (Mirroring) 2
RAID 5 3 or 4
RAID 5+HotSpare 4
RAID 0+1 4
HDD (1, 2, 3, 4)
Right
RAID mode
Color 1 Color 2
(Health) (Access)
Red None RAID 0, RAID 1, RAID 5, RAID 0+1
None Flash Blue RAID 0, RAID 1, RAID 5, RAID 0+1
None Blue RAID 1, RAID 5, RAID 0+1
None Blue RAID 1, RAID 5, RAID 0+1
HD Switch
2
3
4
4 (HotSpare)
ARCTICROC 4T
4-Bay RAID System
Quick Installation Guide
