- Page 1 Verro ® ™ Owner’s Manual Model 600...
-
Page 2: Safety Notes
Shut off and unplug the Power Supply every time you remove the cleaner from the water. Do not leave the cleaner in the pool all the time. Mishandling the unit can result in leakage of lubricants. Please keep the plug away from contact with water. iRobot Verro Owner’s Manual... - Page 3 The floating power cord must be locked in the socket on the Power Supply. Do not leave your cleaner in direct sunlight when not in use. Never leave the Power Supply in direct sunlight and avoid leaving it in the rain. www.irobot.com...
- Page 4 Important: Failure to properly store Verro will result in loss of warranty. iRobot recommends using the mesh filter bag (available separately at www.irobot.com) when the pool contains a significant quantity of large debris (leaves, etc.), such as when the pool is opened for the season.
-
Page 5: Table Of Contents
Parts List ..............7 Using Verro ..............8 - 10 How Verro Works ............11 Cleaning the Filter Bag ..........12 - 13 Maintenance and Adjustment ........14 - 18 Troubleshooting ............19 - 20 Customer Care ............21 www.irobot.com... -
Page 6: Anatomy
Anatomy iRobot Verro Owner’s Manual... -
Page 7: Parts List
13. Bottom Lid Assembly 14. Handle Assembly 15. Cable Assembly 16. Power Supply (Transformer) 17. Transformer Socket 8 Wheel Tube Assembly 19. OFF button 20. Light 21. ON button 22. Power Cord (Outlet) 23. Vacuum Intake Flaps 24. Lock Tabs www.irobot.com... -
Page 8: Using Verro
Place Verro in the water and rock it from side to side to allow air to escape. Let Verro settle to the bottom of the pool. Ensure that it is right side up and level. Place the Power Supply (transformer) at least 3.5 meters /12 feet from the pool. iRobot Verro Owner’s Manual... - Page 9 Verro before the end of the cleaning cycle, press the red Power button on the Power Suppy. Light lIGHT: Light indicates that robot is ON. On: Green button turns robot ON. Floating Power Cord OFF: Red button turns Socket robot OFF. www.irobot.com...
-
Page 10: Using Verro
Use the floating power cord to pull Verro to the edge of the pool, but use the handle to lift Verro out of the water. Water will drain from Verro as it is lifted. iRobot Verro Owner’s Manual... -
Page 11: How Verro Works
Verro’s coverage algorithm allows Verro to brush and clean your pool all the way from the bottom to the waterline in only 60 – 90 minutes. www.irobot.com... -
Page 12: Cleaning The Filter Bag
Power Supply. Place Verro upside down on a towel (to prevent scratching the robot’s shell). Towel Unlock and remove the bottom panel by pushing the two locking tabs toward the sides of the robot. Locking Tabs Towel iRobot Verro Owner’s Manual... -
Page 13: Cleaning The Filter Bag
Turn the filter bag so that the felt surface is on the inside and the smooth, shiny surface is on the outside and place it back on the support bars. Label Replace filter bag assembly in the robot. Replace the bottom cover. Make sure the tabs click into place. www.irobot.com... -
Page 14: Maintenance And Adjustment
Maintenance and Adjustment rinsing Verro iRobot recommends that you rinse Verro with a garden hose after using it. This will extend the life of the plastic and keep your robot looking good for years to come. storage Store Verro in a dry place out of direct sunlight at a temperature between 50 and 104 degrees Fahrenheit. - Page 15 20 minutes. Push the new brushes onto the wheel tubes. Place the brushes back in robot, reinstalling the drive belts and drive tracks over the end hubs. Replace the side plate. Reattach the four screws. www.irobot.com...
- Page 16 Place Verro upside down on a towel and remove the filter bag assembly. (p. 12) On each side of the robot, remove the four screws that hold on the side plate. Side Plate Remove the side plates. Remove the drive tracks. iRobot Verro Owner’s Manual...
- Page 17 Place Verro so that you can walk away from it for 50 feet. Holding the Detangler in your hand, walk away from the Verro. The Detangler allows the floating power cord to rotate in the handgrip so that it untwists as you walk. www.irobot.com...
-
Page 18: Maintenance And Adjustment
Unplug the floating power cord from the Power Supply. Remove the screws that attach the outlet top to the robot. Lift off the outlet top. Clean any debris from the propeller and shaft. Replace the outlet top and reinstall the screws. iRobot Verro Owner’s Manual... -
Page 19: Troubleshooting
Do not machine dry the filter bag. If you find the filter bag gets clogged too quickly, consider using the mesh bag instead (mesh filter bags are available separately from www.irobot.com). Always turn off Verro’s Power Supply and unplug it before troubleshooting any problem. -
Page 20: Troubleshooting
The pump impeller is Clean the impeller. (p. 18) fouled Verro gets The floating power cord is Use Detangler to untwist the cord. (p. 17) stuck on its twisted floating power cord iRobot Verro Owner’s Manual... -
Page 21: Customer Care
Customer Care Please visit our web site at www.irobot.com for support tips, frequently asked questions or information about accessories and other iRobot products. We would like to hear from you. Should you still need assistance, call our customer care representative at .. irobot Customer Care Hours: •... - Page 22 *See registration card for details. Pricing and availability subject to change. Shipping and handling not included. © 2007 iRobot Corporation, 63 South Avenue, Burlington, MA 01803. All rights reserved. iRobot is a registered trademark and Verro is a trademark of iRobot Corporation.
- Page 23 Verro ® ™ quick start guide An easy step-by-step guide to using the iRobot Verro Pool Cleaning robot...
- Page 24 OFF: Red button turns the pool is opened for the season. robot OFF. the fine filter bag is ideal for filtering small debris (algae, sand, etc.) and for regular maintenance. Periodically straighten the floating power cord with the detangler. instructional photos available at www.irobot.com/usetips...
- Page 25 © 2007 iRobot Corporation, 63 South Avenue, Burlington, MA 01803. All rights reserved. iRobot is a registered trademark and Verro is a trademark of iRobot Corporation. Cover photo © Veer incorporated 2002 - 2005. All rights reserved.
