Spacer Combinations - Icom BC-146 Instructions

• Charging with the IC-F11 Series
Spacer A
Attach the spacer (Spacer B/C) to the adapter
(Spacer A) with the orientation as illustrated in the
diagram above.
• Attach the spacer (Spacer B/C) to the adapter with
the orientation of the stamp " " pointing up.
• Charging with the IC-F30G, IC-V82 Series
The adapter (Spacer A) only is required.
When removing the spacer (Spacer B/C)
Remove the spacer (Spacer B/C)
from the adapter.
Push the notch
carefully.
Icom, Icom Inc. and

SPACER COMBINATIONS

Check orientation
and
Spacer B/C
Spacer A
logo are registered trademarks of Icom Incorporated (Japan) in the United States and/or other countries.
• Charging with the IC-F3G Series
Spacer A
Attach the spacer (Spacer B/C) to the adapter
(Spacer A) with the orientation as illustrated in the
diagram above.
• Attach the spacer (Spacer B/C) to the adapter with
the orientation of the stamp " " pointing up.
Push the notch carefully with your finger to remove
the spacer (Spacer B/C) from the adapter (Spacer A).
R CAUTION!
DO NOT push or force the notch with a screw
driver, etc., to remove it.
DO NOT bend the notch when the adapter and
spacer are not joined together. This will cause
weakening of the notch plastic.
Both cases may break the notch and it may not
be able to be reattached.
Check orientation
and
Spacer B/C
