Icom IC-F3GT Instruction Manual page 13

D Rapid charging with the BC-121N+AD-101
The optional BC-121N allows up to 6 battery packs to be charged
simultaneously.
The following items are additionally required.
• Six AD-101 (The spacer is supplied with the AD-101.)
• An AC adapter (purchase separately).
Turn power OFF.
AC adapter
(Purchase
separately)
D Regular charging with
the BC-137
#11
The optional BC-137
or BC-146 provides regular
charging of the battery pack.
The following item is addi-
tionally required:
• AD-99N* and an AC adapter
(purchase separately).
* Supplied with the charger.
Turn power OFF.
/BC-146
#11
BATTERY PACKS
Insert together with the
spacer.
Check the orientation of the
spacer for correct charging.
Charge indicator
(each indicator functions
independently)
Insert
with AD-99N.
Check the orienta-
tion of AD-99N for
correct charging.
BC-137 #11
or BC-146
3
together
8
