Menu
Feedback Slack
Feedback 0
Position
Feedback Type
Power Steering
Type
Description
Sets the allowable
tolerance or dead
band before the
system will respond
to changes in
feedback. Reduces
servo jitter or chatter.
Adjusts the zero (0)
position of the rudder
when there is a
di erence between
the actual rudder
position and the
readout on the
display. Make sure
the rudder is in the
center position before
you change this
setting.
Sets the rudder
feedback type
connected to the
autopilot. The
Gyronav sensor must
be connected and
enabled (see
Gyronav).
Sets the type of the
power steering
actuator installed on
the vessel. Pump
should be matched to
steering cylinder size.
Rev 2 and Rev 3
settings attenuate
controller voltage
output.
12
Settings
.5° to 3.0°
Where .5 = tighter response to
rudder feedback, and 3.0 =
looser response to rudder
feedback.
Default: .7°
-7.5° to 7.5°
(where -7.5 = Port and
+7.5 = Starboard)
Default: 0°
Disabled: O
FB30
LF n: Linear Normal
LF r: Linear Reverse
POT n: Potentiometer Normal
POT r: Potentiometer Reverse
LIN: Linear
Default: FB30
SOL: Solenoids
(valve actuators)
REV 1: Pump is well matched
to steering cylinder (100%
controller voltage output)
REV 2: Oversized pump (80%
controller voltage output)
REV 3: Grossly oversized
pump (60% controller voltage
output)
RELAYS: Signal level outputs
for interfacing with vessel
steering systems.
