HOMELITE 26cc STRING TRIMMERS
The model number will be found on a plate attached to the engine housing. Always mention the model number in all correspondence regarding your
STRING TRIMMER or when ordering repair parts.
KEY PART
NO. NUMBER DESCRIPTION
1 870174001 * Spark Plug (Champion RCJ6Y) ............................1
2 940991039 Logo Label ...........................................................1
3 678029002 Hex Nut (M6) ........................................................1
4 519823001 Air Box Cover .......................................................1
5 940734059 Starting Label .......................................................1
6 660634001 Screw (8-16 x 5/16 in.) .........................................1
7 760700002 Switch ...................................................................1
8 308680001 Fuel Cap ...............................................................1
9 660697002 Bolt (M6 x 20 mm) ................................................1
10 270032001 Throttle Cable .......................................................1
11 518529001 Throttle Trigger .....................................................1
12 518674001 Handle ..................................................................1
13 678008001 Washer (1/4-20) ....................................................1
14 678034001 Wing Nut (1/4-20) .................................................1
15 660643009 Bolt (1/4-20 x 45 mm) ...........................................1
16 518949001 Wing Nut (1/4-20) .................................................1
17 678436001 Mounting Bracket .................................................1
18 308781001 Straight Shaft Grass Deflector
(Incl. Key Nos. 14, 17, and 28) .............................1
– MODEL NUMBERS UT32000 AND UT32050
PARTS LIST
QTY
* STANDARD HARDWARE ITEM – MAY BE PURCHASED LOCALLY
(FIGURE B)
KEY PART
NO. NUMBER DESCRIPTION
19 308746002 Large String Head Housing ..................................1
20 308044007 Dual Line Spool and String (0.080 in.) ..................1
21 308042003 Spool Retainer ......................................................1
22 308401002 Boom Assembly
(Incl. Key Nos. 26, 27, 31 and 32) ........................1
23 940964009 Warning Label ......................................................1
24 678022001 Spring ...................................................................1
25 308743002 String Head Assembly
(Incl. Key Nos. 19-20 and 24) ...............................1
26 678011002 Flanged Washer ...................................................1
27 678019002 Arbor.....................................................................1
28 660857001 Square Bolt (1/4-20 x 1 in.) ..................................1
29 940654088 Combusion Warning Label ...................................1
30 308210002 Gear Head ............................................................1
31 660642001 Bolt (1/4-20 x 1-1/4 in.) ........................................1
32 660641001 Screw (10-24 x 5/8 in.) .........................................1
5
