Homelite UT33651 Quick Start Manual

First Time Assembly
WARNING: This Quick Start Guide is not a substitute for reading the
operator's manual. To reduce the risk of injury, user must read and understand
operator's manual before using this product.
1
Remove product from carton.
Assemble per instructions
in your operator's manual.
2
Spread handle over boom and
snap into place. Secure with bolt,
washer, and wing nut.
Curved Shaft
3
Straight Shaft
- OR -
Snap shield into place over boom and bracket.
Secure with bolt, washer, and wing nut as shown.
4
Align and assemble 2 booms
until fully seated. Tighten
screws with provided hex key.
5
Mix 2.6 oz. 2-cycle oil with
1 gallon of fresh gasoline in
separate gas container. Shake,
then pour into trimmer tank.
First Time Start
6
Place trimmer on ground
with the trim head end facing
away from you.
7 10X
Repeatedly press the primer
bulb 10 times.
8
Set choke lever to A
start position.
9
Squeeze and hold trigger.
Pull quickly and powerfully
10
Continue to squeeze and
hold trigger to allow
engine to warm up.
If engine does not start,
11
Set choke lever to
B run position.
NOTE: There is a detent location
between positions A and B
to help ease starting
and warm up, if needed.
12
You are now ready to Trim!
If engine did not start,
TRIM!
To stop trimmer, press the
red switch located on the
side of motor housing.
Go to www.homelite.com and register your new tool online.
For any questions about operating or maintaining your product,
call the Homelite Help Line!
®
1-800-242-4672
Your Product has been fully tested prior to shipment to ensure
your complete satisfaction. Troubleshooting tips are also
available in your operator's manual.
For additional registration instruction, refer to operator's manual.
to start (6x MAX.)
REPEAT STEPS
7 10
REPEAT STEPS
7 11
–
990000927
2-28-14 (REV:01)
