Hitachi CP-WX4022WN Specification

CP-WX4022WN LCD Projector
Accessories and Lenses
Supplied Remote control, power cord,
Accessories computer cable, user's manuals, safety
manual, lens cap, security label
Optional TB-1 wireless USB tablet, USBWL11N
Accessories USB wireless adapter, HL02651 laser/
wired remote control, MS-1 switcher,
MS-1WL wireless multifunction switcher,
LCDS2000 soft sided case
Replacement Parts
Lamp CPX5021NLAMP (DT01171)
Remote Control
HL02881
Filter MU07791
Projection Throw Chart (In inches)
Screen Size 16:10
Diagonal Width
30 25
60 51
100 85
120 102
150 127
200 170
300 254
Throw Ratio: 1.5 - 2.5 :1 (distance : width)
HI0155-04/13 WEB
All specifications subject to change without notice.
3LCD and the 3LCD logo are registered trademarks of the Seiko Epson Corporation.
iPad and iPhone are registered trademarks of Apple Inc., registered in the U.S. and other countries.
©2013 Hitachi America, Ltd. All Rights Reserved.
Hitachi America, Ltd.
900 Hitachi Way, Chula Vista, CA 91914
Toll Free: 1.800.HITACHI Email: dmd.info@hal.hitachi.com
•
Web: hitachi-america.us/projectors
Specifications
Throw Distance
Min Max
36 61
74 124
126 209
151 251
190 315
254 421
382 632
* Actual lamp life will vary by individual lamp and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
lamp life specified are not guaranteed and do not constitute part of the product or lamp warranty. Lamp brightness decreases over time.
** Actual filter life will vary by individual filter and based on environmental conditions, selected operating mode, user settings and usage. Hours of average
filter life specified are not guaranteed and do not constitute part of the product warranty.
CP-WX4022WN
Projection Technology 3LCD, 3 chip technology
Resolution WXGA 1280 x 800
White Light Output 4,000 ANSI lumens
Color Light Output 4,000 ANSI lumens
Colors 16.7 million colors
Aspect Ratio Native 4:3 / 16:9 and 16:10 compatible
Contrast Ratio 3000 : 1 (using active IRIS)
Throw Ratio 1.5 - 2.5 : 1
(distance : width)
Lens F = 1.6 - 2.1, f = 19 - 32 mm
x 1.7 manual zoom, focus, lens shift
Lamp Wattage 245W
Expected Lamp Life* Approximately 3,000 hours (standard mode)
5,000 hours (Eco mode)
Expected Filter Life** Approximately 5,000 hours
Speaker Output 16W
Acoustic Noise Level
35 dB (29 dB in Eco mode)
Keystone H and V: +/- 37.5º
Computer VGA, SVGA, XGA, WXGA, SXGA/WXGA+/WSXGA+/UXGA
(compressed), MAC 16"
H-Sync 31.5 kHz - 106 kHz
V-Sync 56 Hz - 120 Hz
Composite Video NTSC, NTSC4.43, PAL, PAL-M, -N, SECAM
Component Video 480i, 480p, 576i, 720p, 1080i, 1080p
HDMI 480i, 480p, 576i, 720p, 1080i, 1080p,
Computer signal TMDS Clock 27 MHz - 150 MHz
Digital Input HDMI x 1 (HDCP compliant)
Computer Input 1 15-pin mini D-sub x 1
Computer Input 2 BNC x 5
Computer Monitor Output
15-pin mini D-sub x 1
Video Input
S-Video Mini DIN 4-pin x 1
Composite Video RCA jack x 1
Component Video RCA jack x 3, 15-pin mini D-sub x 1 (shared with computer In 1)
BNC x 3 (shared with computer In 2)
Audio Input 3.5 mm stereo mini jack x 2, RCA jack (L/R) x 1, MIC-in 3.5 mm
mini jack x 1
Audio Output RCA jack (L/R) x 1
Network LAN Wired RJ-45 port (10 base-T / 100 base-TX)
Network LAN Wireless USB-A, IEEE802.11 b/g/n - optional wireless adapter required
USB Type A x 2 (PC-less presentation, wireless adapter, TB-1)
Type B x 1 (USB display or mouse control)
Control Terminals 9-pin D-sub x 1 (RS-232 control)
Power Supply AC100-120V / AC220-240V, 50/60Hz
Power Consumption 370W
Operating Temperature 41ºF - 95ºF (5ºC - 35ºC)
Dimensions (W x D x H) 15.8" x 12.5" x 4.1" (excluding protruding parts)
Weight approx. 10.1 lbs.
Approvals UL 60950-1 / cUL, FCC Part 15 subpart B class B
Warranty 4 year limited parts and labor
Extended Service Contract available (additional cost)
Collegiate Series
