Following is a sample output for the DDR adapters:
# ibstatus
Infiniband device 'qib0' port 1 status:
fe80:0000:0000:0000:0011:7500:0078:a5d2

ibtracert

The tool ibtracert determines the path that IB packets travel between two
nodes. It is installed from the openib-diag RPM. The IB LIDs of the two nodes
in this example are determined by using the ipath_control -i command on
each node. The ibtracert tool produces output similar to the following when
run (as a root user) from a node on the IB fabric:
# ibtracert 0xb9 0x9a
"iqa-37"
"MT47396 Infiniscale-III"
"SilverStorm 9120 GUID=0x00066a000200016c Leaf 6, Chip A"
"MT47396 Infiniscale-III"
"idev-05"
"idev-05"
IB0054606-02 A
default gid:
base lid:
sm lid:
state:
phys state:
rate:
link_layer:
From ca {0x0011750000ff9886} portnum 1 lid 0xb9-0xb9
[1] -> switch port {0x0002c9010a19bea0}[1] lid 0x14-0x14
[24] -> switch port {0x00066a0007000333}[8] lid 0xc-0xc
[6] -> switch port {0x0002c90000000000}[15] lid 0x9-0x9
[7] -> ca port {0x0011750000ff9878}[1] lid 0x9a-0x9a
To ca {0x0011750000ff9878} portnum 1 lid 0x9a-0x9a
Summary and Descriptions of Commands
0x1
0x4
4: ACTIVE
5: LinkUp
40 Gb/sec (4X QDR)
InfiniBand
G–Commands and Files
G-23
