Fedders FV95A Series Specifications

FV95A Series All-Position Gas Furnace
The Fedders 95% High Efficiency All-Position
Two-Stage Gas Furnaces are 40" tall and among
the smallest in the industry. They are ready to
accommodate the 13 SEER "A" Coils for today's
more efficient air conditioning systems and the
changing needs of home construction. The
unique FV95A Series Furnace offers unmatched
installation flexibility and provides consistent
air circulation and temperature control.
EFFICIENCY:
95% AFUE
Variable speed blower motor
Two-stage induced draft blower
WARRANTY:
Lifetime limited warranty on heat exchanger
5-year limited warranty on all other parts
EFFICIENCY
RATING
ama
CERTIFIED
FV95A Series
All-Position Gas Furnace
95% AFUE – Two-Stage, Variable Speed
STANDARD FEATURES:
Designed for all-position installation: upflow, downflow and horizontal
40" high, for ease of installation
AL 29 - 4C stainless steel secondary heat exchanger
Industry-proven, integrated hot surface ignition control with igniter
and flame sensor positioned in coolest part of flame for ultimate
performance and longevity
Aluminized-steel multi-port in-shot burners provide smooth ignition
coupled with superior flame stability, low noise and reliability
California low NO
Insulated cabinet to increase efficiency and reduce sound levels
Single or two-stage thermostat ready
Supports two-stage cooling units
Electronic air cleaner and humidifier terminals
EASY TO INSTALL AND SERVICE:
Built-in self diagnostics with fault code view without removing
the door
All-position capability easily converts from upflow to horizontal
left and right position with minimum effort
Easily removable blower with slide-out design
Factory shipped for natural gas, with LP Gas conversion kits available
Left or right side gas and electrical connections
Active and passive dehumidification in conjunction with
cooling system
INPUT
MODEL
(BTUH)
FV95A0543A 54,000
FV95A0723A 72,000
FV95A0905A 90,000
FV95A1085A 108,000
Specifications subject to change without notice.
approved
X
COOLING
EFFICIENCY
CAPACITY
(AFUE %)
(Tons)
95 1.5 - 3
95 1.5 - 3.5
95 2.5 - 5
95 2.5 - 5
UNIT DIMENSIONS
H x W x D (Inches)
40 x 17.5 x 29
40 x 20.5 x 29
40 x 20.5 x 29
40 x 24.5 x 29
