EN-9235TX-32
User Manual
09-2012 / v2.0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EN-9235TX-32 and is the answer not in the manual?

Questions and answers

Related Manuals for Edimax EN-9235TX-32

Summary of Contents for Edimax EN-9235TX-32

  • Page 1 EN-9235TX-32 User Manual 09-2012 / v2.0...
  • Page 2 COPYRIGHT Copyright  Edimax Technology Co., Ltd. all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission from Edimax Technology Co.,...

  • Page 3: Table Of Contents

    Contents Chapter 1: Introduction ..................... 4 Model no........................4 Package Contents ..................... 4 LED Status ......................... 4 Product Features ...................... 5 System Requirements ....................5 Chapter 2: Installation Guide ..................... 6 Hardware Installation ....................6 Driver Installation ..................... 7 2.2.1 Windows : Setup Wizard ...................

  • Page 4: Chapter 1: Introduction

    Chapter 1: Introduction Model no. EN-9235TX-32: Gigabit Ethernet PCI Adapter Package Contents Before you start using this product, please check if there is anything missing in the package, and contact your dealer to claim the missing item(s):  Gigabit Ethernet 32-bit PCI Adapter x 1 ...

  • Page 5: Product Features

    Product Features  Supports 32-bit 33/66MHz PCI Local Bus Master high-speed operation (Rev.2.1/2.2/2.3)  Complies with IEEE 802.3, 802.3u, 802.3ab and 802.3x standards  Supports 10/100Mbps full and half duplex, 1000Mbps full duplex  Supports 10/100/1000Mbps Auto Negotiation and jumbo frame ...

  • Page 6: Chapter 2: Installation Guide

    Chapter 2: Installation Hardware Installation To install the adapter, please follow the steps listed below: A. Turn off your computer and unplug/disconnect all cables, including the power supply. B. Remove your computer’s case cover. C. Locate an available PCI Express slot. D.

  • Page 7: Driver Installation

    For Windows XP Driver Installation The included CD contains a setup wizard which will guide Windows users through the installation process, as explained in the next section. You can also install the drivers manually. Please follow the instructions appropriate for your operating system.
  • Page 8 C. Click “Setup Driver”. D. The wizard will help you install the driver for Windows 7/Vista/98SE/ME /2000/XP.

  • Page 9: Windows : Cd Drivers

    Windows 7/Vista/98SE/ME/2000/XP users can alternatively install the drivers manually. The following instructions will guide you through the CD Drivers installation procedure. A. Insert the Edimax Resource CD into the CD-ROM drive. B. Right-click the icon “My Computer” on the desktop, and then click “Manage”.
  • Page 10 C. The “Computer Management” screen will appear as shown. Click “Device Manager”, and you will see various options on the right. Click “Other devices”, and then from the drop-down list please find “Ethernet Controller” you have installed. Right-click it, and then select “Update Driver”.
  • Page 11 E. Select “Search for the best driver in these locations”, and then click “Browse” and choose the system driver location of the disk, and then click “Next”. F. Wait a few seconds for the installation.
  • Page 12 G. Click “Finish” to complete the installation. H. Restart Windows to complete the installation.

  • Page 13: Novell And Linux: Cd Drivers

    2.2.3 Novell and Linux: CD Drivers Novell and Linux Novell and Linux users need to install the drivers manually. The drivers for Novell and Linux operating systems can be found in the CD at the following location: - /Drivers/Linux/ - /Drivers/Novell/ Please follow the usual driver installation procedure for your operating system.

  • Page 14: Chapter 3: Troubleshooting

    Chapter 3: Troubleshooting 1. What should I do if my PC cannot find the new hardware? Check to see if the network adapter is inserted in the PCI slot properly. Otherwise, please reinsert the adapter. 2. What should I do if my PC cannot identify the new hardware? Check if you can find the network adapter you’ve installed in the following location: /My Computer/Manager/Device Manager/Network Adapter/..
  • Page 15 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
