- Page 1 Eden Electronics Operation Manual World Tour Series Amplifiers EDEN METRO TWIN CHANNEL BASS GUITAR AMPLIFIER The DC-210XLT Combo OWNERS MANUAL 2-18-03 Rev. A...
- Page 2 Foreword Congratulations on your purchase of the New Eden David series Bass Guitar Combo Amplifier by Eden Electronics. We are proud to present our very best high power Combo Amplifier. This Amplifier represents a great deal of research and design effort. We have put our best cutting edge amplifier technologies, enclosure design and styling together to create a great sounding Bass head with some wonderful new features.
- Page 3 General Description The DC-210XLT system is 23” x 21 ½” x 18 ”. It weighs only 85 Lbs. The Metro features a one piece aluminum chassis, High efficiency power transformer, Dual channels, thermostatically controlled fan, automatic limiter, a high temperature Auto-limiting system, and international power supply voltages are available on every model.
- Page 4 Gain Control The gain control is used to match the output level of your instrument to the proper operating level for the Amplifier and Compressor Limiter. For normal operation you should set the control between 10:00 and 1:00, unless you have an unusually high signal output Bass or a very low output Bass.
- Page 5 When this switch (WORKS ONLY WITH THE FOOT SWITCH ) is engaged ,it mutes both the stage sound and the D.I. send. Only the tuner output stays hot. The Mute is on or muted when the foot-switch LED is on (on those foot switches with LED’s).
- Page 6 Gain Control This controls the available gain to the first preamplifier stage. For normal operation run the input Gain between 9:00 and 2:00 for most instruments. -12 dB Pad Pulling out on the Gain Control knob operates the control and results in a signal reduction of –12dB at the input.
- Page 7 The filters in the Eden DC-500 are adjustable for level up to +/- 15 dB and for center frequency (the pitch where the tone change happens). The bandwidth is fixed so that the filters will interact smoothly and musically.
- Page 8 This control works just like the midrange control with +/- 15 dB of change available. It regulates frequencies between 1.2 KHz and 12 KHz. This control is very effective for bringing out the bright overtones on the bass. E.Q. Clipping Indicator This LED will light up if the signal is clipping any place in the tone control or Pre- amp section.
- Page 9 Main AC Inlet (IEC standard) This inlet fits a standard computer office machine AC cable interconnect. The Fuse is located just above the plug receptacle. The correct voltage is displayed in the upper left corner of the holder and should read correctly with the rest of the printing on the amplifier.
- Page 10 CREATING YOUR SOUND This is what we have found to be the best way to get your sound out of the World Tour amplifiers. Setting the pre-amp to flat Set the Enhance controls to “0” or Min. Set all other tone controls straight up or in the 12:00 position Set the master Volume control to (0) Plug in you bass and speaker and turn on the amplifier.
- Page 11 The tube is easily replaced by removing the unit’s cover. Use a genuine Eden 7025 / 12AX7 or equivalent. Always disconnect the power cord from the back of the unit prior to removing...
- Page 12 Please ship Authorized Returns for service to: Eden Electronics 115 2 Montrose, MN 55363 Eden Electronics C/O U.S. Music Corp. 444 E. Courtland Rd. Mundelein, IL 60060 (847) 949-0444 (847) 949-8444(fax) eden@eden-electronics.com http://www.eden-eletronics.com CR Eden Div. US Music 444 Courtland Rd., Mundelein, IL 60060...
- Page 13 Your Favorite Tone Settings__________________________...
