Part No.: RN03185AL00
Mode[
Number_
Please register your product at WWW,
rca,com
Please keep your sales receipt and keep the record of
the serial number and the date of purchase in order to
receive warranty
parts and service.
The serial number
is located at the back of the TV.
Serial Number/ Nzimerode serie de TV
Date of Purchase/ Fechade la compra
Made for Today.
www.rca.com

Advertisement

   Also See for RCA 22LB45RQD

   Summary of Contents for RCA 22LB45RQD

  • Page 1

    Part No.: RN03185AL00 Mode[ Number_ rca,com Please register your product at WWW, Please keep your sales receipt and keep the record of the serial number and the date of purchase in order to receive warranty parts and service. The serial number is located at the back of the TV.

  • Page 2: Child Safety Guide

    Congratulations on your purchase! As you enjoy your new product, please keep thesesafely tips in mind: THE ISSUE • The home theater entertainmentexperience is a growing trend and larger flat panel displays are popular purchases.However, flat panel displays are not always supported on the proper standsor instaled according to the manufacturer's recommendations.

  • Page 3

    iMuchas gracias por su uso del presente productoT Cuando usted disfruta de su nuevo producto, por favor tenga en cuenta los consejos de seguridad: POSIBLES PROBLEMEAS La experiencia de entretenimiento de cine en casa es una tendencia creciente y los grandes monitores de pantalla plana son muy populares.

  • Page 4: Table Of Contents

    Child Safety Guide ............................Caution and Warning ........................... FCC and Class 1 Laser Product Notice ....................Safety Precautions ............................Preparation for Your New rv ........................Cheek Accessories ............................Setup TV Table Stand ..........................Select TV Location ............................Connection and Using ..........................TV Stand Installation ............................

  • Page 5

    OSD Menu Operations ..........................Adjust the OSD Screen ..........................Picture Menu ............................. Sound Menu ............................. Channel Menu ............................Parental Menu ............................Setup Menu ..............................Others Menu ............................. DVD Operations ............................Frequently Asked Questions (FAQs) ...................... Troubleshooting ............................V-Chip Rating Explanations ........................

  • Page 6: Caution And Warning

    CAUTION Caution: To reduce the risk of electric shock, do not remove cover or back. No user-serviceable parts inside. Refer servicing to qualified service personnel. WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.

  • Page 7: Safety Precautions

    Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. For example, do not use near a laundry tub, in a wet basement, or near a swimming pool, and the like. Clean only with dry cloth.

  • Page 8

    23. WARNING: To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions. 24. To reduce the risk of electric shock, the grounding of center pin of plug must be maintained. 25. If an outside antenna or cable system is connected to the TV, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges.

  • Page 9: Preparation For Your New Rv

    Before Turning On TV Check Accessories Check the accessories that are packed with your TV. F±_[e] I_e],vAvJ ::1 -'[e.7±! :] III::1 =|vd[.._ F±! _ 1 =__e] -'1 :kVAV_'] -'1=_[e;t i: [o,le]_ii -'[e] ! PART NO.: RE20QP83 SCREWS RC,n _>_' USER'S QUICK START M4 x 12mm, 4pcs Part# RS01TB412H...

  • Page 10: Tv Stand Installation

    TV 19LB30RQD/22LB45RQD are packaged with the TV stand separated from the cabinet. To setup the TV table stand, please carry out the installation according to the instructions below. Step One Place the TV faced down on a soft cloth or cushion to prevent the LCD panel from being damaged.

  • Page 11

    The first step in connecting your TV is obtaining the signal. Your TV 19LB30RQD/22LB45RQD has a side panel, which allows you to receive analog and/or digital television channels via TV jack. Before connecting your TV, determine using an antenna or a cable service to obtain the signal. A.

  • Page 12: Cable Connections

    Choose Your Connections TV 19LB30RQD/22LB45RQD supports various connections to other devices (such as DVD, VCR, Set-top box, etc.). Please follow the table to choose the cables which adapt to your device. Go to page 12 AUDIO-IN L and R, Video In Video/Audio cable Audio Cable...

  • Page 13: Side Panel Connections

    Connecting AV Composite device (Good Video Quality) To connect a composite AV device, such as a DVD player, follow these steps: 1. Connect the Video In jack on the side of TV to the video output jacks of device via video cable (yellow). 2.

  • Page 14: Connecting Ypbpr Component Device (better Video Quality)

    Connecting YPbPr Component device (Better Video Quality) To connect a component device, such as a DVD player, follow these steps: 1. Connect the COMPONENT IN Y/Pb/Pr jack on the side of TV to the video output jacks of device via video cable (green, blue and red).

  • Page 15: Connecting Hdmi Device (best Video Quality)

    Connecting HDMI device (Best Video Quality) To connect a HDMI device, such as a DVD player, please connect the HDMI jack on the side of TV to the output jack of device via HDMI cable. To connect a DVl device, such as a computer via DVl port of PC and HDMI jack of TV: 1.

  • Page 16: Connecting A Computer

    Connecting a computer To connect a computer, follow these steps: 1. Connect the VGA port on the side of TV to the VGA output jack of device via D-sub 15-pin cable. 2. Connect the PC Audio In jack on the side of TV to the audio output jack of computer with audio cable (3.5mm). Note.

  • Page 17: Tv Jacks Explanation

    _uuuuuuuuuuuuuuuuuuqH_, _HUUUuuuuuuuuuuuuuuuu_ € € Head phone: Connect a 3.5mm headphone for personal audio. PC Audio In: Use to obtain sound when a PC is connected to the PC input. Use 3.5mm stereo mini-pin cable to connect PC to TV. TV: Connect to receive the signal from your antenna or cable via coaxial cable. VGA: Connect your computer or other device with a VGA output to this jack using a 15-pin, D-sub cable.

  • Page 18: Top Panel And Front Panel

    Top Panel Buttons If you cannot locate your remote, you can use the top panel buttons on your TV to operate many TV features. /° ?° ° qo° INPUT MENU INPUT: Displays the Source Select List. MENU: Displays the TV Main Menu. OH •...

  • Page 19: Remote Control Instructions

    Inserting Batteries in the Remote • Remove the cover of battery cabin on the back of the remote control by pushing the tab and sliding the cover. • Insert two AAA batteries, making sure the polarities (+ and -) are aligned correctly. •...

  • Page 20: Learning About Remote Control

    Remote Oontrol Buttons POWER (_): Turns the TV on or off. MUTE (1_): Reduces the TV volume to its minimum level. Press again to restore the volume. Numeric Buttons: Use these buttons to enter numbers. "--": To enter a digital channel with a sub-channel, enter the main channel; then, press this button to enter the sub-channel and press ENTER.

  • Page 21: Initial Setup

    If it is the first time you turn on your TV, or you have done Clear Channel List option (see page 30), the initial setup menu appears automatically. Step One Please select Menu Language, press the up/down arrow select the language you need. Available languages: English, Spanish and French.

  • Page 22: Basic Operations

    Turning On and Off Connect the AC cord to power the LCD TV. At this time the TV will enter standby mode and power indicator will turn red. Use Power button (_) on the top panel of TV or on the remote control to turn on the TV. After switching off the TV for 5 seconds, you can turn on TV again.

  • Page 23: Channel Bar

    Channel Bar Press the DISPLAY button on the remote control, the channel bar will appear on the top right corner of the screen. It displays the current channel's information. The following list describes the items on the channel bar. A2/D50-1 If the channel is analog, A is displayed.

  • Page 24: Osd Menu Operations

    Adjust the OSD Screen The OSD (On Screen Display) menu enables you to approach to the TV functions. To use OSD menu system, press MENU button on remote control, then use left/fight arrow to highlight an option from PICTURE, SOUND, CHANNEL, PARENTAL, SETUP or OTHERS and press ENTER/down button.

  • Page 25

    Screen Size Screen Size: Select a screen aspect ratio. (Available ratio: Wide, Cinema, Zoom, and Normal.) Please choose the ratio that applies to your video signal format best. PC Settings (only available in PC mode) • Auto Adjust: Adjust the PC picture display automatically. •...

  • Page 26: Sound Menu

    Sound Menu The Sound Menu lets you adjust audio output. To access the Sound Menu, press MENU on the remote, and then select SOUND from the Main Menu. Press ENTER/down button to proceed to SOUND menu. Use up/down to choose the function you need, press ENTER or right arrow to adjust or enter a sub-menu.

  • Page 27: Channel Menu

    Equalizer Settings The seven-band graphic equalizer allows you to adjust the audio frequency settings. You can select one of the equalizer presets (Off, Pop, Rock, Jazz) or create your own personal preset (User). Press the left or right arrow to select the frequency (100Hz, 250Hz, 500Hz, 1KHz, 2KHz, 4KHz, 10KHz) you want to adjust.

  • Page 28: Parental Menu

    Signal Type Select your TV signal type: Air or Cable. Auto Channel Search Execute an auto channel search (see page 20). Parental Menu The Setup Menu enables you to lock program with special content, panel key board and input source. Press MENU and choose PARENTAL from the Main menu.

  • Page 29

    Movie Rating arrow keys to select the rating level you want to block, press ENTER to IocWunlock the rating level. If you have blocked a lower level rating, the higher ratings will be blocked too. For example, when PG-13 is blocked, R, NC-17 and X will be blocked at the same time.

  • Page 30

    Canada V-Chip Press ENTER or right arrow to enter US V-Chip ratings menu, which contains two sub-menus: English Rating and French Rating. English Rating Press ENTER or right arrow to enter English rating menu. Use arrow keys to select the rating level you want to block, press ENTER to IocWunlock the rating level.

  • Page 31

    Change Password Change the password of parental menu. Input the old password. Input the new password. Input the new password again to confirm. Remote Select your Remote: Off, Remote1 or Remote2. This is for special purpose. Keypad Lock Select this option to block or unblock the TV's side panel buttons so that they can't be used. Source Lock This option allows you to lock or unlock the input source.

  • Page 32: Setup Menu

    Setup Menu The Setup Menu lets you config the TV with your preferences. Select SETUP from the Main Menu. Press ENTER/down button to proceed to SETUP menu. Use up/down to choose the function you need, press ENTER or right arrow to adjust or enter a sub-menu. sub-menu image and explanation are shown below.

  • Page 33

    Digital CO Style Select the item you want to adjust in Digital CC Style menu with up/down arrows. After changing, you can preview the caption style here. Menu Language To choose your menu language, press the left/right arrow until the language you need appears. Available languages: English, French and Spanish.

  • Page 34: Others Menu

    Others Menu The Others Menu lets you config the TV with your preferences in other features. ©hoose OTHERS from the Main Menu. Press ENTER/down button to proceed to SETUP menu. Use up/down to choose the function you need, press ENTER or right arrow to adjust or enter a sub-menu. The sub-menu image and explanation are shown below.

  • Page 35

    DVD mode of TV 19LB30RQD/22LB45RQD TV 19LB30RQD/22LB45RQD has a built-in DVD player module, which you can use to watch DVD disk. The following operation guide gives the DVD module instruction. 1. How to enter DVD mode for TV 19LB30RQD/22LB45RQD Press INPUT button on remote control, select "DVD"...

  • Page 36: Dvd Operations

    Keypad on DVD module EJECT (_&): Ejects or loads the disk from DVD module. PLAY/PAUSE ( I_11 ): Plays or pauses the DVD disk. About DVD control buttons on remote control, see page !9, remote control buttons. 4. DVD basic operations Play/pause the disk: After inserting the disk to DVD module, the TV will play DVD disk automatically.

  • Page 37

    5. DVD setup menu A. General setup page There exist three sub-menus in DVD setup menu, the first one is General Setup. Press SETUP button on remote control to display General Setup Page. Press up/down arrow to select the item you want to adjust and press right arrow or ENTER button to activate it.

  • Page 38

    Downmix This option is preset as Stereo. C. Preference page Press SETUP button on remote control to display General Setup Page. Press left/right arrow to choose Preference Page. The operating method is similar with the General Setup Page. TV Type Set the TV type as PAL, Auto or NTSC.

  • Page 39: Frequently Asked Questions (faqs)

    What's the most convenient way to view High Definition (HD) video? Connect an antenna to the TV Input jack to view free local digital channels. You may need to purchase an antenna. (See page 10 for more information about antenna setup). Visit www.antennaweb.org for assistance in deciding what type of antenna to use to receive the local digital channels available to you.

  • Page 40: Troubleshooting

    Identifying Problems If there are any problems when using the product, please consult the list below. If the list does not solve the problem, call our Customer Service Center immediately. TV Problems The TV can't be turned on. • Make sure the AC cord is plugged in. •...

  • Page 41

    Keep your TV unplugged for about 5 minutes. Then plug in the TV and turn it on. See if the problem is fixed. If the problem remains, then please visit the Customer Support Menu at www.rca.com or updated FAQs or contact RCA Customer Support at the support number provided in your Warranty card.

  • Page 42: V-chip Rating Explanations

    US V-Chip Rating System TV-MA (Mature Audience Only): Specifically designed to be viewed by adults and may be unsuitable for children under 17. It contains one or more of the following content themes: crude indecent language (L), explicit sexual activity (S), or graphic violence (V). TV-14 (Parents Strongly Cautioned):...

  • Page 43: Canadian French Rating System

    C8+ (Children 8 and older): Programming generally considered acceptable for children 8 years and over to watch on their own. Violence Guidelines: Violence will not be portrayed as the preferred, acceptable, or only way to resolve conflict or encourage children to imitate dangerous acts which they may see on television. Any realistic depictions of violence will be infrequent, discreet, of low intensity and will show the consequences of the acts.

  • Page 44: Wall Mounting Unit Specification

    19LB30RQD/22LB45RQD VESA 100 x100 M4 screws, length 12mm 00 mm -_-'_IIIIHIIIIIIIHIIHIII_ 100 mm ® Note: A. The wall mount is not contained in the accessories sold with television. We only provide the installing specifications but not the wall mount itself. If you need the mount, please consult with the local dealer for a VESA wall mount. B.

  • Page 45: With Usb Media Play

    USB storage device while the TV is playing back picture or music. This may result in loss of data or damage to the USB storage device, and RCA is not responsible for any damage to, or loss of, data on the USB...

  • Page 46: Product Specification

    18.5 inches 21.6 inches Diagonal Display Size Television System American TV standard ATSC/NTSC system VHF: 2-13 UHF: 14-69 CATV: 1-135 Channel Coverage Storage Temperature: -20°C-+60°C (-4°F -+140°F) Temperature Operating Temperature: 0°C-+50°C (+32°F-+122°F) Storage Humidity: Less than 85% RH (No condensation) Humidity Operating Humidity: Less than 80% RH (No condensation)

  • Page 47: Warranty Card

    How to Obtain Service ° For assistance (USA) - if you purchased RCA product in USA, please call 1-888-977-6722. Or visit www.rca.com * For assistance (Mexico) - if you purchased RCA product in Mexico, please call 01-800-8233858 Or visit www.rca.com...

  • Page 48

    WARRANTY PERIOD(S) FORTH ABOVE. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU ALSO MAY HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE. RCA is a trademark of RCA Trademark Management SAS and used under license by ON Corporation...

  • Page 49

    RCA, pagaremos un centro autorizado de servicio de RCA el cargo de mano de obra para reparar cualquier defecto en materiales o mano de obra en el televisor. Si su televisor es irreparable...

  • Page 50

    LIMITADA A LIMITADA periodo de garantia (S) mencionado anteriormente. Esta garantia le otorga derechos legales especificos y USTED TAMBII_N PUEDE TENER OTROS DERECHOS, QUE PUEDEN VARIAR DE ESTADO. RCA es una marca registrada de SAS bajo licencia de ON Corporation...

  • Page 51

    10920 Via Frontera, Ste 540 San Diego, CA 92127, U.S.A. ©2012 ON Corporation RCA is a trademark of RCA Trademark Management used under license to ON Corporation. RCA es una marcade RCA Trademark Management usada bajo licencia de ON Corporation.
