Summary of Contents for RCA E13319F11
- Page 2 To reduce the risk of electric shock, do not remove WARNING RiSKOF ELECTRIC cover (or back). No user serviceable parts inside. To reduce the risk of fire or _HOCK.DO NOT OPEN Refer servicing to qualified service personnel. electric shock, do not expose this TV to rain or moisture.
- Page 3 SETUP AND CONNECTION ANTENNA, CABLE, CABLEBOXORVCR Step 1: Connect Your TV Connect the cable from your cable system or off-air antenna to the cable in- jack on the back of the TV, as shown. TV (Back Panel) Step 2: Plug In Your TV Plug the end of the power cord into the wall outlet, matching the wide...
- Page 4 CHANNEL MARKER The Channel Marker comes up when you first turn on the TV, change channels, or press the DISPLAY button. 01:30 Displayed to count down time left on the commercial skip timer. 13 Displays the current channel. 7:17 Displays the current time. CC Displayed when Closed Captioning is available.
- Page 5 REMOTE CONTROL BUTTONS When operating the remote, point it directly at the front of the TV. POWER Objects between the remote and the remote sensor can block the signal to the TV. POWER Button Press to turn the TV on or off. MUTE PREV CH PREV CH Button...
- Page 6 TV MAIN MENU TV Main Menu The TVMain Menu is your gateway to controlling the TV. it lets you adjust the TV's picture quality, screen, channel settings, parental controls, and time functions. To select a menu item: 1. Press MENU to bring up the TV Main Menu. 2.
- Page 7 THE CHANNEL MENU Channel The Channel menu contains all the commands used to control your channels, including custom-building your channel list. Signal Type Displays a toggle that lets you select the current antenna type: Antenna Choose this if you are currently using an off-air antenna The Channel menu...
- Page 8 VICHIP MOVIE RATING LIMIT V-Chip Parental Controls With the Movie Rating Limit you can set movie-viewing limits. Blocking Movie Ratings You can automatically block all movie ratings above a specified rating using Movie Ratings Limit in the Parental Controls menu. Selecting Movie Rating...
- Page 9 The TV Rating Limit Screen Below is an example of where items are located within the TV Rating Limits screen. You can always press MENU to exit back to the previous screen while in the Rating Limit menus. Content Themes Rating field Lets you select from a list of...
- Page 10 Blocking Age-Based Ratings and Content Themes Rating field Content Themes You can automatically block all program ratings or content above a specified age-based rating level using the V-Chip TV Rating Limit screen. Refer to the chart at the beginning of this section to learn about each age- based rating and its associated content ratings.
- Page 11 VICHIP UNRATED PROGRAM BLOCK "Unrated" vs. "Not Rated" Selecting this option lets you decide if programs that the V-Chip recognizes All movies are assigned a rating. as "unrated" can be viewed. Some movies are given a rating of View All unrated programs are available.
- Page 12 If you experience any difficulty with your TV, check these basic remedies before calling your service technician. TV will not turn on or controls don't work • Check to make sure it is plugged • Check the wall receptacle (or extension cord) to make sure it is "live"...
- Page 13 Remote Control A_l_wOdeffonn This is the remote that came packed with your TV. You can Total Description use the order form to order it direct by mail if desired. Transformer AH035 $ 6.95 Cleaner/Polisher VH81 $ 3.95 Screw on Antenna Cable (3 ft) 226551 247905...
- Page 14 Charge your order on your VISA, Placing An Order MasterCard, or Discover Card by filling in below To place your order by phone, have your Visa, MasterCard Discover Card ready and call the toll-free number listed below. USE YOUR CREDIT CARD VISA Use this number only to place an order for accessory items...
- Page 15 How you get service: • For screen sizes of 26" and smaller: Take your RCA television to any Authorized RCA Television Service Center and pick up when repairs are complete.
- Page 16 Please do not send any products to the Indianapolis address listed in this manual or on the carton. This will only add delays in service for your product. _ THOMSON CONSUMER ELECTRONICS 10330 North Meridian Street Indianapolis, IN 46290 @2000 Thomson Consumer Electronics, Inc.
