- Page 1 Panason,c Color Video Projection System Operating Instructions PT-51G53 PT-51G53X PT-61G53 PT-61G53X TQB2AA0225 PRINTED IN USA 80304...
- Page 2 WARNING To move set, push from left side of set. (3asterson right side do not pivot in all directions. Set can tip over if moved from right side, with risk of personal injury. ADVERTENCIA Para mover el conjunto, empuje desde el lade izquierdo del mismo.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Table of Contents Congratulations ............Customer Record ..............Care and Cleaning ..............Specifications ................Installation ..............Television Location..............Optional Cable Connections............. 3 AC Power SupplyCord ............Cable / Antenna ................ Cable Connection ..............Antenna Connection ..............Optional Equipment Connections .......... -
Page 4: Congratulations
The model and serial number of this product are located on the back of the PTV. You should note the model and serial number in the space provided and retain as a permanent record of your purchase. This will aid in identification in the event of theft or loss. Product registration.is available at www.prodreg.com/panasonic. Model Number... -
Page 5: Installation
INSTALLATION Installation Television Location This unitcan be used as an entertainment c enter. Consultyourdealerfor availableoptions.-" Avoidexcessivesunlight or brightlights,including reflections. 13 Keep away from excessiveheat or moisture. Inadequateventilationmay cause internal component f ailure. Fluorescent lighting may reduceRemoteControltransmitting range. Avoid magneticequipment,including motors, f ans,or externalspeakers. Cable Connections Optional Shielded audio and video cables should be used between components. -
Page 6: Optional Equipment Connections
INSTALLATION Optional Equipment Connections VCR's, video disc players,video game consoles, and DSS equipment can also be connected to the video inputs. See the optional equipment manual for details. TERMINALS ON BACK OF PTV CABLES NOT SUPPLIED Procedure Connect equipment as shown to rear AudioNideo input jacks. Select the Video mode by pressing W/VIDEO button. -
Page 7: Picture In Picture (Pip) Operation
PICTURE IN PICTURE (PIP) OPERATION Picture In Picture (PIP) Operation With ! Without A VCR And Cable Box This television includes a two tuner Picture In Picture (PIP) feature. This allows watching-[_d (2) live broadcasts at the same time without or with an external video source (VCR). Without A VCR (External Video Source) -
Page 8: With A Vcr - No Cable Box
PICTURE IN PICTURE (PIP) OPERATION (CONT.) Picture In Picture (PIP) Operation (Cont.) PIP Operation with a VCR - No Cable Box This television includes a two tuner Picture In Picture (PIP) feature. This allows watching two (2) live broadcasts at the same time without or with an external video source (VCR). Connect your television to a VCR, as shown. -
Page 9: Main Menu
MAIN MENU Main Menu Main Menu mml l =FAIll ACTION Button Press the ACTION button to display the Main Menu and Sub Menus. Press the ACTION button repeatedly to exit. CH / VOL Buttons Press the CH (channel) or VOL (volume) buttons to select an icon. Use the CH buttons to highlight the desired features. -
Page 10: Main Menu Feature Chart
MAIN MENU FEATURE CHART Main Menu Feature Chart When entered, TIME will display on screen after pressing POWER button, RECALL button, or changing channels. Choose CABLE or TVto match the signal at your antenna input. Automatically program channels with a signal into memory. - Page 11 MAIN MENU FEATURE CHART Main Menu Feature Chart (Cont.) 90 minutes. Select NO to turn timer off. day. PICTURI Reset all picture adjustments to factory default settings. Adjust desired color intensity. Adjust natural flesh tones. Adjust dark areas for crisp detail. Adjust white areas of picture, Adjust clarity of outline detail.
-
Page 12: Special Features
SPECIAL FEATURES Special Features Languages In SET UP menu, select ENGLISH, ESPAI_IOL, or FRAN(_AIS to change the menu language. Convergence Adj. (Adjustment) In SET UP menu, select CONVERGENCE ADJ only after moving the PTV to adjust for the effects of the earth's magnetic field on the projection tubes. Use the navigation buttons to select CONVERGENCE ADJ. -
Page 13: Timer
SPECIAL FEATURES Convergence Adj. (Adjustment Cont.) Use the navigation buttons to align the red cross with the white cross pattern at the center of the screen. Press ACTION to continue to the blue convergence adjustment screen and repeat,'--- TO PREVENT PICTURE TUBE DAMAGE. DO NOT LEAVE TEST PATTERN Note: ON FOR AN EXTENDED PERIOD OF TIME. -
Page 14: Program Timer
SPECIAL FEATURES Program Timer In "l]mer menu, program Pi-V to automatically turn on and off at selected time on a selectP,.,d channel, daily or one day. Note: TIME must be entered in the SET UP menu to operate PROGRAM TIMER. The PTV automatically turns OFF after 90 minutes when tumed on by the PROGRAM TIMER. -
Page 15: Ch Cap (Channel Caption)
SPECIAL FEATURES CH CAP (Channel Caption) Program channel captions (station labels) for 30 stations using up to four characters. Note: Delete channel captions by entering dashes (-) in all four character slots. LOCK Game Guard Lock In LOCK menu, useto prevent videogames and VCR tapesfrom being viewedfor 12, 24, or 48 hoursusinga secretcode. -
Page 16: Unlocking Game Guard
SPECIAL FEATURES Unlocking Game Guard Enter the same three-digit code. If the three-digit code is not the same as entered previously. If the same three-digit code is used. -
Page 17: Troubleshooting Chart
TROUBLESHOOTING CHART Troubleshooting Chart Before calling for sewice, determine the symptoms and follow suggested solutions. Adjust Antenna Location and Connection Noisy Audio Snowy Video Adjust Antenna Location and Connection Check Antenna Lead-in Wire Noisy Audio Multiple Image Move PTV from Electrical Appliances, Lights, Vehicles, and Medical Equipment Noisy Audio Interference... - Page 18 Division of Matsushita Electric Electric Corporation of America CoL Dei Valle C.P. 03100 of Puerto Rico inc. ("PSC One Panasonic Way Mdxico, D.F. Ave. 65 de Infanteda, Km 9.5 Secaucus, New Jersey 07094 Tel. (915 6 015) 488-1000 San Gabriel Industrial Park www.panasonic.com...
