TOSHIBA
Equium 8000S
Part Number: PV1066U-XXXXX
Product Specification
Processor
Configure this Product
CPU
Intel® Pentium® processors
1GHz, 933MHz, 866 MHz,
800MHz or 733 MHz
Intel® Celeron™ processors
700MHz, 667MHz,633MHz,
or 600 MHz (with 128
cache)
Frontside Bus
133MHz (Pentium III)
Speed
66MHz (Celeron)
Memory
Configure this Product
Options
256MB, 128MB, OR 64MB
SDRAM
Maximum
512MB
Speed
PC133 (Pentium III)
PC100 (Celeron)
Storage
Configure this Product
Hard Disk Drive
5400rpm
30.7GB, 20.5GB, 15.3GB or
7.5GB
(UDMA 66)
7200rpm
20.5GB, 15.3GB or 10.2GB
(UDMA 100)
Hard Drive
Interface
ATA 100 (transfers up to
100 MB/sec)
Media Options
Configure this Product
CD-ROM
24X max. speed or none
(sustainable data transfer
rate 1548KB-3600KB/sec)
DVD-ROM
8X speed or none (DVD
mode sustainable data
transfer rate 10,820 KBytes
Max)
Diskette Drive
1.44MB
Keyboard
104-key enhanced keyboard
Operating
Configure this Product
System
Options
Windows NT Workstation
4.0, Windows 98SE
Windows 95 or Win
2000Pro
Network
Configure this Product
Intel EtherExpress™
Options
PRO10/100B integrated on
motherboard or
3COM PCI LAN Card or
None
Network option supports
IEEE 802.3 auto-negotiation
for 10/100Mbps operation,
RJ-45 port, Wake-On-
LAN™ and Instant On
support
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change
without notice. Copyright 2000 TAIS equium_8000s.rtf Rev. 2 04/26/01
V.90/k56 PCI fax modem
Modem
Expansion
Slots
2 slots, 2 available: 2 PCI
Drive Bays
3 bays: 2 front accessible
(1-3.5", 1-5.25" Slim Type),
1 Internal 3.5"
Plug & Play
Yes
Support
Video
Graphics
Intel 3D Graphics with
Controller
Direct AGP (Integrated in
Intel 815e chipset)
Video Memory
Dynamic Video Memory
Technology Provides
Excellent Performance
Using System Memory For
Video Memory ( Upto max
13MB)
Video Cache
Configure this Product
Options
4 MB or none
Color Support
640 X 480 x 16.7M/24 bit @
( Note: The
85 Hz
800 x 600 x 16.7M/24 bit @
video is capable
85 Hz
of displaying
these refresh
1024 x 768 x 16.7M/24 bit
rates as long as
@ 85 Hz
1152 x 864 x 16.7M/24 bit
the monitor can
@ 85Hz
support the high
frequency.)
1280 x 1024 x16.7M/24bit
@ 85Hz
1280 x 1024 x256/8bit @
75Hz
Audio
Software Audio Sound
Blaster® Pro and
Windows Sound System
compatible
Configure this Product
Speakers
Bexim BEX691C External
Speakers or None
Audio Jacks
Microphone-In
Line-Out
Power Supply
120 watts
Input Voltage
115VAC/ 4A
230VAC/ 2A
Pointing Device
Configure this Product
2 button scroller PS/2™
mouse or PS/2 mouse
Ports
Serial
1 16C550 UART compatible
Parallel
1 DB25 Multimode bi-
directional (ECP/EPP)
USB
Supports 2 USB peripherals
without external hub
Software
1.
Intel LANDesk® Client
Manager 6.0,
2.
Toshiba Configuration
Builder CD
3.
Norton AntiVirus
VirtualTech™ Online
4.
Technical Support
5.
Toshiba Screensaver
6.
Freedomware™
7.
Automated software
upgrade notification
8.
Internet Explorer 5.0
Manageability
Hardware Alert
Temperature, Fan Speed
and Voltage Monitoring
Security Alert
CPU Missing, LAN Link
Loss, Presence Heartbeat
DMI 2.1
Yes
Intel LANDesk
PC health monitoring,
Client Manager
hardware inventory,
(6.0)
software inventory, remote
management
Year 2000
NSTL hardware tested
Compliant
Intel Wired for
Yes
Management
Microsoft Logo PC99
Certifications
Novell Workstation Certified
Advance Power
Management (APM) 1.2
Compliant
ACPI 1.0
Security
Security loop to lock chassis
Password Protection,
Dimensions
Weight
18.71 lbs. (base model)
Measurements
(W) 13.8"x (D) 14.4"x (H)
3.3"
Agency
UL 1950
CISPR 22 Class B
Approvals
FCC class B
CSA 22.2 No. 950
TUV
CE Marks
Energy Star MOU 3.0 Tier 1
Compliant
Warranty
3 year on-site next business
day service warranty.
Part Number
Determined by custom
configuration, See Equium
Web Configurator at
www.config. toshiba.com
