Summary of Contents for Panasonic P2HD AJ-HPX3100

  • Page 1 AJ-HPX3100 Memory Card Camera Recorder...
  • Page 2 high-end performance in a compact, Lightweight Design. this 2/3-type p2 hD camera recorder Ushers in a new Level of Mobility to nature, Dramatic, Documentary and enG production. the new aJ-hpX3100 may just change the way you view high-end broadcast camera recorders. its new body design has a low center of gravity for added stability and gives you an unobstructed view to both sides.
  • Page 3 *3: The optional AJ-YDX30G Video Encoder Board is required for use of proxy data. *4: Proxy data can be saved only in PCs/Macs. * For the latest information, see “Support & Download” on the Panasonic website (http://pro-av.panasonic.net/). The use of DCF Technologies is under license from Picture simulated Multi-Format, Inc.
  • Page 4 c a M e r a S e c t i o n High-Image-Quality, High-Sensitivity HD Camera with 2.2-Megapixel 2/3-type 3CCD 2.2-Megapixel 3CCD Offering Both High Resolution Chromatic Aberration Compensation (CAC) and High Sensitivity This exclusive technology works between the lens and camera, allowing for a highly sophisticated algorithm to be deployed that The camera section features a automatically compensates the registration error that is caused...

  • Page 5: User Buttons

    DRS (Dynamic Range Stretch) Function 5 User Buttons DRS recognizes the average brightness of highlight and shadow The User buttons let you turn frequently used functions on or off with areas and then automatically adjusts the aperture and uses knee a single touch.
  • Page 6 p 2 r e c o r D e r S e c t i o n AVC-Intra Codec for High-Quality Image and Sound Recording. P2 HD for Superb Reliability. Comes Equipped with an AVC-Intra Codec The P2 Card: Reliable, Reusable and with Extended Recording Time AVC-Intra is a new codec that further advances HD production.

  • Page 7: Advanced Recording Functions

    HD Recording Format supported by AJ-HPX3100 SD Recording Format supported by AJ-HPX3100 Rec. Time (using two 64GB P2 cards) by Codec Rec. Time (using two 64GB P2 cards) by Codec Pull Recording video Format Pull down Recording video Format down DVCPRO HD AVC-Intra 100 AVC-Intra 50...
  • Page 8 *4: Proxy data can be saved only in PCs/Macs. filter position, metadata and others can be checked remotely. *For the latest information, see “Support & Download” on the Panasonic website (http:// pro-av.panasonic.net/). • Proxy video*...
  • Page 9 TC IN and OUT terminals make time code throughput possible. This Backup recording operation can be interlinked with the Rec Start/ permits an external time-code lock. Stop controls of an HD-SDI input-equipped Panasonic recorder, such Other System Functions and Options as the AG-HPG20, etc. The AJ-HPX3100 can also output down- converted SD-SDI from an HD source.

  • Page 10: S Y S T E M W O R K F L O W

    *1: The optional AJ-SFU3100G Upgrade Software Key is required. *2: Select a model that supports IEEE 801.11b/g ad-hoc connection. Proxy data can be stored and transferred by Mac/PC only. *3: The AG-MBX10 Removable SSD Interface Box is required. Use a commercially available optional SSD (must be a model for which compatibility has been confirmed by Panasonic). *4: Must support proxy video data.
  • Page 11 *1: The P2 card E Series may require P2 equipment software to be updated. Please go to the P2 support page on the Panasonic web page https://eww.pavc.panasonic.co.jp/pro-av/ *2: Use a commercially available removable SSD that is recommended by Panasonic. In addition to the removable SSD interface box that comes with the AG-MSU10 as a standard accessory, an additional AG-MBX10 can be purchased as an option.

  • Page 12: Optional Accessories

    o p t i o n a L a c c e S S o r i e S a S o f M a r c h , 2 0 1 0 AJ-SC900 AJ-CVF100G Soft Carrying Case SHAN-TM700 25.4 mm (1 inch) Tripod Adapter *Not available in some areas.

  • Page 13: Specifications

    S p e c i f i c a t i o n S a S o f M a r c h , 2 0 1 1 General Specification Digital Video Power Supply: DC12V (11V to 17V) Sampling Frequncy: AVC-Intra 100/AVC-Intra 50/DVCPRO HD: Y: 74.1758 MHz, P : 37.0879 MHz (59.94 Hz)
  • Page 14 P2 store. The included P2 driver is compatible with Windows 7, Windows Vista, Windows XP, Windows 2000 and Mac OSX. For other operating requirements, refer to the P2 installation manual. The P2 driver and the P2 installation manual can be downloaded for free from the following Panasonic web site: https://eww.pavc.panasonic.
