Panasonic PT-DZ770K Overview

Crisp Pictures with 7,000 lm and
Effective Visual Communication
Vivid Picture Quality with
High Brightness
• Unique lamp drive systems have helped to
make the body compact, while providing a
high 7,000 lm of brightness.
• Full-HD-ready WUXGA resolution.
• Panasonic's proprietary RGB Booster
achieves high image quality with excellent
color reproduction and brightness.
• Detail Clarity Processor brings depth and
clarity to details.
• System Daylight View 2 enhances color
perception with no need to turn off the lights.
• The DICOM Simulation mode reproduces
easy-to-view rendering of X-ray photos. *
• Rec. 709 mode for HDTV projection.
• Full 10-bit signal processing.
• Advanced technologies for excellent image
quality: 3D color management system, HD IP
conversion, digital noise reduction, dynamic
sharpness control.
WUXGA Resolution for
PT-DZ 770K /D Z 770L K
W UXG A ( 1, 9 20 × 1, 2 00 )
The PT-DZ770LK is sold without lenses. The specifications are the same as those of the PT-DZ770K.
Easy Maintenance and
Superior Reliability
• A dust-resistant cabinet and reusable "Eco
Filter" that needs no replacement for up to
12,000 hours*
from dust.
• Panasonic's unique Dual Lamp System
eliminates a sudden interruption if a lamp
should fail (in dual-lamp operation mode).
The Lamp Relay mode also operates the
lamps alternately to enable 24/7 projection.
• The replacement lamp unit*
with all of the Panasonic PT-DW730 Series,
PT-D6000 Series and PT-DZ570 Series
1 projectors. * 4 This reduces the number of lamp
types that need to be kept in stock when
multiple projectors are used.
• Original cooling system allows use in ambient
temperatures from 0 °C to 45 °C (from 32 °F
to 113 °F)* 5 with a compact body and quiet
operation.
7, 000 lm
2 protect optical components
3 can be used
P R E L I M I
A s o f J a n u a r y 2 0 1 2
PT-DZ770
1-Chip DLP™ Projectors
Available from June 2012
System Integration Flexibility
• Flexible vertical 360 degree installation, lens-
centered design, horizontal/vertical-lens shift
and a wide range of optional lenses.
• The Multi-Screen Support System optimally
adjusts multiple screens: Edge blending,
color matching and multi-screen processor.
• Side-by-Side function.
• Abundant terminals, including an HDMI
digital input terminal, meet a wide variety of
customer needs.
• Multi Projector Monitoring & Control Software
allows multiple projectors to be managed
together over a wired LAN.
• Web browser control over a wired LAN.
• PJLink compatibility.
™
• Compatible with Creston RoomView
AMX Device Discovery.
• 30 m long-range wireless remote control.
• Direct Power Off.
• Mechanical lens shutter.
• Environment-friendly, low standby power
consumption of 0.2 W at 120 V AC, 0.3 W at
220 –240 V AC (
STANDBY MODE
• Carefully manufactured at the Panasonic
factory in Japan, under strict quality control.
N A R Y
and
™
: ).* 6
ECO
