- Page 1 If you have questions concerning the op- eration of this Whistler product please call customer technical service: 1-800-531-0004 Hours: Monday - Friday 9:00 am - 5:00 pm EST...
- Page 2 To fully acquaint yourself with the operation of the Whistler 1560/ 1565 and to better understand the differences between detect- ing radar, laser and safety radar signals, we recommend reading this entire manual.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Topic Page Model Features Summary 3 - 5 Installation 6 - 8 • Mounting Guidelines • Dash/Visor/Windshield Mounting • Power Connection And Fuse Replacement Operation 9 - 14 • Power On And Self-Test • Feature Engaged Confirmation •... -
Page 4: Model Features Summary
WHISTLER FEATURES Whistler 1560/1565 Whistler’s ergonomic and user-friendly design provides a new level of operating convenience. Special features include: 1. Bracket Release Button - Provides quick and easy re- lease of the mounting bracket. 2. Power Jack - Provides connection for the power cord. - Page 5 9. Auxiliary Jack - Provides easy connection of the WHIS- TLER 1400 EXTERNAL SPEAKER, Part Number 202180 or WHISTLER MOTORCYCLE HELMET SPEAKER, Part Num- ber 202698 (see page 27). Any other speaker may damage the unit and void your warranty.
- Page 6 WHISTLER FEATURES Accessories Accessories included are highly functional and easy to use. Coiled Power Cord - Connects to the unit’s power jack and your vehicle’s lighter socket. Windshield Bracket - Allows installation of unit on your vehicle’s windshield. Velcro ®...
-
Page 7: Installation
INSTALLATION Mounting Guidelines • Mount the unit as low as possible near the center of the windshield. • Do not mount your unit behind wipers, ornaments, mirrored sunscreens, etc. These obstructions have metal surfaces which can affect radar and laser signals and reduce critical warning time. -
Page 8: Dash Mounting
INSTALLATION IMPORTANT: Some newer cars have a plastic safety coat- ing on the inside of the windshield. The windshield bracket may leave permanent marks on this type of surface. To find out if your vehicle has this type of windshield, check the owner’s manual or ask your dealer. - Page 9 INSTALLATION Visor Mounting (optional accessory) • Slide the visor bracket into the bracket mounting slot. • Clip the visor bracket onto the visor making sure it is rela- tively level and has a clear view of the road. Slide on visor Insert into bracket mounting slot Power Connection...
-
Page 10: Operation
OPERATION Power On And Self-Test Each time your Whistler detector is turned on, an automatic self-test sequence confirms that the speaker and visual dis- plays are functional and displays the engaged features. • Press (Power/Volume) or apply Power. Display reads: Memory/Beep Confirmation All features selected (except Stay Alert) are retained in memory. -
Page 11: Audio Level Adjustment
OPERATION Audio Level Adjustment The audio levels can be adjusted high to low, or low to high, in four steps: (1) is the lowest audio level, (4) the highest. • Press and hold (Power/Volume) (for more than 1.5 seconds). • Release when desired level is reached. - Page 12 City/City 1 Mode Whistler’s two-stage City Modes are designed to reduce the annoyance of automatic door openers, intrusion alarms and other devices which share frequencies with police radar.
-
Page 13: Dim/Dark Mode
OPERATION lowered. If Auto Quiet is engaged and the unit receives a strong X band signal, the unit performs the Auto Quiet feature. City Modes do not change the audio alert for laser or VG-2. Dim/Dark Mode Dim/Dark Mode reduces the illumination of the display. •... - Page 14 OPERATION If a button was not pressed within 3-5 seconds alarm sounds and the display reads: K Ka W H C T M All indicators flash. • Press (Power/Volume) to exit. WARNING!!! Stay Alert is NOT intended as a substitute for adequate rest.
-
Page 15: Teach/Tutorial Mode
• Press to exit. Auxiliary Jack Allows you to use a WHISTLER 1400 EXTERNAL SPEAKER , Part Number 202180 or WHISTLER MOTORCYCLE HEL- MET SPEAKER, Part Number 202698 (see page 27). Any other speaker may damage the unit and void your war- ranty. -
Page 16: Speed Radar Audio/Visual Alerts
RADAR ALERTS Speed Radar Audio/Visual Alerts When X, K or Ka is detected the band ID and signal strength is displayed. The audio alert is continuous and has a geiger counter-like pattern. The faster the beep the closer the radar source. - Page 17 SAFETY RADAR ALERTS When Safety Radar is detected the audio alert is geiger counter-like and 1 of 5 letters illuminates. W H C T M Weather Advisory “W” confirms detection of a weather advisory such as heavy fog, high wind, etc. Highway Hazard “H”...
-
Page 18: Laser Audio/Visual Alerts
LASER/VG-2 ALERTS Laser Audio/Visual Alerts When a laser signal is detected an “L” is displayed, the au- dio alert is continuous for a minimum of 3 seconds. Example: Reception of laser signal is confirmed by “L” on the display. VG-2 Audio/Visual Alerts When a VG-2 signal is detected, the detector “hides”... -
Page 19: Reset Features/Care Maintenance
RESET FEATURES/CARE & MAINTENANCE Reset Features All user features can be reset to factory set positions. • Remove Power from unit. • Press and hold (Power/Volume) and (Mute). • Apply power to the unit. • Wait for 2 beeps. • Release . -
Page 20: Troubleshooting Guide
PROBLEM: No display or audio. • Check fuse in Whistler plug; replace if necessary with a 2 amp 3AG type. • Check fuse for lighter socket; replace if necessary. -
Page 21: Are Detectors Legal
ARE DETECTORS LEGAL? In Most States YES! Laser detectors are completely legal in every state when used in automobiles or light trucks (under 10,000 lbs.). Similarly, when used in automobiles or light trucks, radar detectors are legal in almost every state. Exceptions are Virginia and Washington, D.C., which have local regulations restricting the use of radar receivers in any vehicle. -
Page 22: Speed Monitoring Technologies
For best protection, keep these points in mind: • Because your vehicle’s license plate or headlights are the laser gun’s primary targets, mounting your Whistler detector on the dashboard can improve laser detection at short range. • Do not follow closely behind any vehicle you cannot see through. -
Page 23: Other Speed Detection Systems
SPEED MONITORING TECHNOLOGIES Other Speed Detection Systems Several techniques other than radar or laser are used to mea- sure vehicle speeds. When these methods are being used, no detector can provide a warning. These techniques include: • Pacing - A patrol car drives behind you and matches your driving speed. -
Page 24: Warranty Information
All express or implied warranties for this product are limited to one year for the 1560, two years for the 1565. Whistler is not liable for damages of any type arising from the use, misuse, or operation of this product. - Page 25 WARRANTY INFORMATION IMPORTANT: Whistler will not assume responsibility for loss or damage incurred in shipping. Therefore, please ship your unit insured with return receipt requested. 2. Include with your unit the following information, clearly printed: • Your name and street address (for shipping via UPS), and a daytime telephone number.
-
Page 26: Warranty Information
• The unit has been abused, modified, installed improperly, or had its housing removed. The minimum out of warranty service fee for your Whistler detector is $55.00 (U.S.). If you require out of warranty ser- vice, please return your unit as outlined in the section “Ser- vice Under Warranty”... -
Page 27: Specifications
SPECIFICATIONS • Dimensions: 1.1"H x 2.7"W x 4.6"L • Weight: 6.5 oz. • Laser Wavelength Detection Range: 50 nanometers (nm) • Radar Frequencies: 10.500 - 10.550 GHz (X Band) 24.050 - 24.250 GHz (K Band ) 33.400 - 36.000 GHz (Ka Superwideband) •... -
Page 28: Accessories
ACCESSORIES The following accessories are available through Whistler retailers or can be ordered directly from Whistler by call- ing 1-800-531-0004. Order Description Price Code 202138 Visor Bracket $6.95 202139 Windshield Bracket $9.95 206294 *Modular Lighter Plug $7.95 (Requires 206550 or... - Page 29 Sales Tax (if Applicable) Shipping and Handling 3.00 Total Enclosed SEND ORDER FORM WITH CERTIFIED CHECK OR MONEY ORDER TO: Whistler CTS 16 Elizabeth Drive Chelmsford, MA 01824 IF PAYING BY MASTERCARD OR VISA PLEASE PROVIDE: Type Of Card _____ MasterCard...
