Sharp XG-V10XU Quick Reference Manual

Applicable Models: XG-V10WU
XG-V10WM XG-V10XM
Quick Reference Guide Sections:
1.) AN-L10T Installation
2.) Projector Configuration
3.) S.A.P.S. Configuration
1.) Install Lan Card into expansion slot
on A/V connector side of the projector
Refer to O/M page numbers 2 - 3 for details
2.) Configure Projector Menu
There are (4) four items to configure
on the projector menu.
A.) Set ID Number
B.) Set IP Address
C.) Set Gateway
D.) Set Subnet Mask
A.) Set ID Number
Refer to Operation Manual - page 4
L:\tekcentr\cactrain\qck_ref.xls
How to Connect a Sharp Projector to a Network
Quick Reference Guide
XG-V10XU
Must be
obtained from
IT / MIS
Department
B.) Set IP Address
NOTE: IP Address is Static - verify with
IT / MIS Department.
Refer to Operation Manual - page 5
C.) Set Gateway
Refer to Operation Manual - page 6
D.) Set Subnet Mask
Refer to Operation Manual - page 7
1
3:18 PM
10/12/2001
