- Page 1 SUPERBA 27" BUILT−IN ELECTRIC DOUBLE OVEN Self Clean Upper and Lower Oven MODEL KEBS276XBL3 BL−Black Glass 1992 KITCHENAID Part No. 4174203 2−92 Litho in U.S.A.
-
Page 2: Control Panel Parts
CONTROL PANEL PARTS For Model: KEBS276XBL3 4174203... - Page 3 CONTROL PANEL PARTS For Model: KEBS276XBL3 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION 12 3179916 Insert, Vent 25 4169372 Bezel, Switch NOTE: The screws and nuts 3179847 Screw (4) 26 3177650 Support, Frame required to attach a part are 13 3179704 Knob, Timer (2) 3177991...
- Page 4 UPPER OVEN PARTS For Model: KEBS276XBL3 4174203...
- Page 5 UPPER OVEN PARTS For Model: KEBS276XBL3 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION NOTE: The screws and nuts 34 3181965 Vent, Middle Trim 20 3179220 Rail, Support (2) required to attach a part are 3180022 Screw (4) 300890 Screw (4) listed immediately following 21 3181733...
- Page 6 LOWER OVEN PARTS For Model: KEBS276XBL3 4174203...
- Page 7 LOWER OVEN PARTS For Model: KEBS276XBL3 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION 30 4173553 Switch, Door 3177551 Bottom, Oven NOTE: The screws and nuts 4159117 Nut (2) 17 3179220 Rail, Support (2) required to attach a part are 313489 Screw (2) 300890...
- Page 8 UPPER AND LOWER OVEN DOOR PARTS For Model: KEBS276XBL3 Illus. Part Illus. Part Illus. Part DESCRIPTION DESCRIPTION DESCRIPTION 8 4164243 Glass, Reflective NOTE: The screws and nuts 3177831 Latch, Strike 9 3181402 Frame, Door required to attach a part are 300890 Screw (2) 10 3178646...
- Page 9 COMPONENT SHELF AND LATCH PARTS For Model: KEBS276XBL3 Illus. Part DESCRIPTION NOTE: The screws and nuts required to attach a part are listed immediately following that part. 1 3178089 Shelf, Component 300890 Screw (7) 258076 Block, Terminal 98445 Screw (2) 3 4159035 Bushing 4 3178668...
-
Page 10: Unit Parts
UNIT PARTS For Model: KEBS276XBL3 Illus. Part DESCRIPTION NOTE: The screws and nuts required to attach a part are listed immediately following that part. 1 3180828 Liner, Oven 661415 Element, Broil 3 3147563 Grill, Broiler 4 3147845 Pan, Broiler 5 3180865 Rack, Offset 6 3180864 Rack, Oven... -
Page 11: Wiring Harness Parts
WIRING HARNESS PARTS For Model: KEBS276XBL3 Illus. Part DESCRIPTION 1 3179941 Harness Wire (Door Switch Upper) 2 3185130 Harness Wire (Door Switch Lower) 3 3185170 Harness Wire (Lower Oven) 4 3185169 Harness Wire (Upper Oven) 5 3179940 Harness Adapter Meat Probe 6 3179668 Standoff, Wire 300890...
