OPERATING INSTRUCTIONS

BEFORE OPREATING THE UNIT PLEASE READ THIS MANUAL
THOROUGHLY AND RETAIN FOR FUTURE REFEENCE
OWENER S RECORD
THE MODE AND SERIAL NUMBERS ARE LOCATED ON
THE BOTTON. RECORD THE SERIAL NUMBER IN THE
SPACE PROVIDED
BELOW.
WARNING HAZARD
DO NOT OPERATE THIS UNIT UNLESS VEHICLE IS
PARKED IN SAFE AND LEGAL AREA.
ICBM-1-TOUCH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ICBM-1-TOUCH and is the answer not in the manual?

Questions and answers

Summary of Contents for Performance Teknique ICBM-1-TOUCH

  • Page 1: Operating Instructions

    An American Ingenuity OPERATING INSTRUCTIONS BEFORE OPREATING THE UNIT PLEASE READ THIS MANUAL THOROUGHLY AND RETAIN FOR FUTURE REFEENCE OWENER S RECORD THE MODE AND SERIAL NUMBERS ARE LOCATED ON THE BOTTON. RECORD THE SERIAL NUMBER IN THE SPACE PROVIDED BELOW.

  • Page 2: Table Of Contents

    Contents Table of Contents Matters to Note Connection Instructions Touch Key Functions Key Functions Basic Operations Functional Operations Other Functions Supplementary Information Attachment Information Touch Screen Information Connection Instructions Other Functions Clock Connection instructions Connection of Separate Power Amplifier Clock Setting Touch Key Functions Supplementary Information Touch Key Function Introduction...

  • Page 3: Matters To Note

    Matters to Note: Matters to Note Matters to note: Installation Qualified Technicians or Repairmen are expected to install the DVD. To avoid injury or any accident, please read carefully the following remindings Ê × Ï È ¸ Ð Ð » Ä ú ¹ º Â ò ³ ¤ Õ ÷ Ê ý Â ë ³ µ Ô Ø ¶ à Ã ½ Ì å Ó é À Ö Ï µ Í ³ ¡ £ Ô Ú ² Ù × ÷ ± ¾ » ú Ç ° £ ¬ Ç ë before installing and operating this machine.
  • Page 4 Matters to Note Matters to Note Reset the micro-processor The Use and Maintenance of Remote Control Press RESET to initialize the micro-processor. Replacing the Lithium Battery The reset operation is needed only when: Normally, the battery can last for about 1 year. (Its lifespan may be The machine is used for the first time after installation.

  • Page 5: Connection Instructions

    Connection Instructions Connection Instructions AV Output White Yellow Backing Radar TV Antenna Radio Antenna VIDEO White Grey RR SWR RR SWR VIDEO Front Front Right Left Purple Green Back Back Optical Output AUX Input RL SWL CDCÊä Èë CDCÊä Èë Blue&Whitel Hand Brake Lens...
  • Page 6 Touch Key Functions Touch Key Functions Touch Key Sound Menu Function Key Touch this key, and the sound menu will appear.Any item inthis MODE menu can be touched and selected freely.BASS, TREBLE, MUTE BALANCE and FADER can all be adjusted. While adjusting EJECT BALANCE or FADER,one can use the demonstrated arrowhead;...
  • Page 7 Touch Key Functions Touch Key Functions Keys Monitor Angel Adjusting System Menu Page 1 Press to adjust the monitor angels within its variation scope. Picture Mode Menu BRIGHT CONTRAST SETUP Touch this key to activate picture mode menu.Touch and select wanted COLOR MODE picture mode.
  • Page 8 Key Functions Key Functions Keys 20 and 22 Menu Adjusting 7 Funciton Touch Key Touch this key, different menus will appear in different program sources Adjust relevant menu item when there is a menu display. If no (DVD,CDC,TV .Please refer to related chapter. menu display, they will change between TV and RADIO,change Touch Keys Volume Adjusting...
  • Page 9 Keys on Remote Controller Keys on Remote Controller 19 MENU (main menu) Menu Selection(+) POWER ANGLE 20 ENTER(setting SRC(Playing Source) MODE DISP Confirm in DVD mode,(long-press it DVD menu) The machine will be on once the playing source is selected. Save in TV and RADIO mode.

  • Page 10: Basic Operations Src Function

    Basic Operations: Basic Operations Adjust the Monitor Angel: SRC Functions Press ANG key on the monitor panel, the monitor will move within The machine is on once the playing source has been selected Press this key the minimum and maximum angels, until the key is let off. to switch between the following playing sources: If it is a short press, the monitor will be slightly adjusted following 1.AUX...
  • Page 11 Tuner Tuner Listen to the Radio: Advanced Function Operations 1 Semi-automatic Seeking Basic Operations: Press menu adjusting keys on remote controller for 2 seconds or touch Change Bands the semi-automatic seeking area on the screen, the system will begin to Press BAND repeatedly until you find needed band.

  • Page 12: Dvd Playing

    DVD Playing DVD Playing DVD Function Operations 1 DVD Playing and Pausing To Operate with remote controller Press PLAY on the remote to play,long-press it to pause. To use Touch Key Functions: Touch PLAY to play disks. Press the function keys area, the following 2 pages information abou t touch Press PLAY again to stop PAUSE and continue to play.

  • Page 13: Dvd Setup

    DVD Playing DVD Setup The Main Page of DVD Setup 7 DVD Information Display Touch key INFO can control the way of DVD info display. Long-press ENTER on the remote or touch SET in DVD operation menu to perform general setup, speaker setup, audio setup etc. 8 OSD Info Display Touch key DISP can control the way of OSD info display.
  • Page 14 Initial Setup Speaker Setup Select Initial Setup through direction keys on the mainpage, press SET or On Setup Mainpage, select Speaker Setup through direction keys, press SET touch SET to enter Initial Setup page as follows: or touch OK to enter Speaker Setup page as follows: TV Form A U T O TV PAL...
  • Page 15 TV½Ó ÊÕ Press the Function Touch Area on the monitor, the following TV Press function touch area on the monitor, the following CDC touch keys will be displayed: touch keys will be displayed: DISC DISC EXIT TUNE STORE EXIT PLAY Playlist Selection Touch , or press menu adjusting keys on the remote to...

  • Page 16: Clock

    TV½Ó ÊÕ Æ ä Ë ü ¹ ¦ Ä Ü Clock 2 Play Preset Channels Check the clock when the machine is in idle state. Press or open TV touch menu, touch CH+ and CH- to select previous or next channel. When the channel number is the maximum one, the In idle state, press DISP button on the panel or remote once to system will change to the minimum channel.

  • Page 17: Supplementary Information

    Supplementary Information Supplementary Information Malfunction Eliminating Problems Possible reasons Problems Measures (advices) Possible reasons Bad turnoff, or the disk Replace it with a better one Can't be switched Incorrect connection of Make sure all connections are The disk cannot be played has been damaged.

  • Page 18: Dvd Disk

    Supplementary Information Supplementary Information Maintenance of DVD Maintenance of DVD CD-R/CD-RW Disks CD-R/CD-RW Disks While using CD-R/CD-RW disks, only completed ones can be used. Use normal disks only.If irregular, non-round or srtange shape disks are CD-R/CD-RW Disks recorded from CD Recorder or personal computer may inserted, they may be hooked in the machine or can not be played correctly.

  • Page 19: Mp3

    ¸ ½ ¼ Ó × Ê Ñ ¶ ¸ ½ ¼ Ó × Ê Ñ ¶ Supplementary Information Supplementary Information Matters to Note about Remote Controller Do not put the remote on panels, steering wheels, or where with direct Mp3 is the abbreviation of MPEG audio layer3, which is the standard of audio sunshine.

  • Page 20: Dvd Player

    Supplementary Information Information about Touching Screen Product Specification: Matters to Note in Using Touching Screen: Power 13.8V DC(10.8-14.5V) Grounding system:: Negative Polar Touching screen is solid and reliable, however, one should still keep the following in mind: Host: 1 Do not scrape the screen hard, slight touching is enough; max current: size (width*height*depth) 2 Touching Screen is not water-proof.
