OWNER'S
MANUAL
VISALIA 4PCS DEEP SEATING SET
Caution: Carefully Read Instructions and
Assembly Procedures
Product code: D71 M80474
KSN: 0-01282547-7
UPC code: 691135190720
Date of purchase: _____/ _____/ _____
Advertisement
Related Manuals for Country Living D71 M80474
Summary of Contents for Country Living D71 M80474
- Page 1 Please refer to part numbers when reordering For questions or comments about product: OWNER’S Caution: Carefully Read Instructions and Call toll-free: 1-877-251-5558 Assembly Procedures 9 am - 4 pm Pacific Coast Time Monday through Friday Product code: D71 M80474 MANUAL Made in / Hecho en CHINA for Kmart Corporation, Hoffman Estates, IL 60179 KSN: 0-01282547-7 SHOP sears.com...
-
Page 2: Assembly Instruction
ASSEMBLY INSTRUCTION SOFA CHAIR VENDOR CODE #: WT-2010-001SF-A SKU CODE #: 0-01282547-7 MADE IN CHINA READ & SAVE THESE INSTRUCTIONS: Examine all packing material before assembling, shortages may occur from parts left in the packing material. Please follow below instructions to assemble step by step. PARTS LIST Parts List Description... - Page 3 Lay down the back support B on the carpet,and attach seat A to the back support B, insert the bolt# 1 with washer# 5 & #6 by using hexagonal wrench # 7 to tighten, as shown in the diagram. Insert the bolts #3 with washers #5 & #6 to tighten by using hexagonal wrench #7, as shown in the diagram.
- Page 4 Insert the bolts #4 with the washers #5 & #6, fasten by using hexagonal wrench #7, as shown in the diagram. This sofa chair have been assembled completely and put the pillow #8 and cushion #9 on the seat of sofa chair .
- Page 5 This sofa chair have been assembled completely and it is ready to use now. This sofa chair have been assembled completely and it is ready to use now. P.04...
- Page 6 ASSEMBLY INSTRUCTION SOFA BENCH VENDOR CODE #: WT-2010-001SF-B SKU CODE #: 0-01282547-7 MADE IN CHINA READ & SAVE THESE INSTRUCTIONS: Examine all packing material before assembling, shortages may occur from parts left in the packing material. Please follow below instructions to assemble step by step. PARTS LIST Parts No.
- Page 7 Lay down the back support B on the carpet,and attach seat A to the back support B, insert the bolt# 1 with washer# 5 & #6 by using hexagonal wrench # 7 to tighten, as shown in the diagram. Insert the bolts #3 with washers #5 & #6 to tighten by using hexagonal wrench #7, as shown in the diagram.
- Page 8 Insert the bolts #4 with the washers #5 & #6, fasten by using hexagonal wrench#7, as shown in the diagram. This sofa chair have been assembled completely and put the pillow #8 and cushion #9 on the seat of sofa bench .
- Page 9 This sofa bench have been assembled completely and it is ready to use now. This sofa bench have been assembled completely and it is ready to use now. P.08...
- Page 10 ASSEMBLY INSTRUCTION COFFEE TABLE VENDOR CODE #: WT-2010-001SF-C SKU CODE #: 0-01282547-7 MADE IN CHINA READ & SAVE THESE INSTRUCTIONS: Examine all packing material before assembling, shortages may occur from parts left in the packing material. Please follow below instructions to assemble step by step. PARTS LIST Parts List Description...
- Page 11 Lay down table top A on the carpet,insert the legs B & C to the hole of the table top A, insert the washers #1 & spring washers #2 then fasten with Y wrench #5, as shown in the diagram. Attach the shelf D to the legs B &...
-
Page 12: Care And Maintenance
CARE & MAINTENANCE Wood is a living material that continues to respond to climate condition even after being made into a piece of furniture. Left untreated, the wood will weather to a silvery grey. To reinforce its weatherproof ability, this furniture was treated with outdoor Polyurethane paint finish at the factory.
