Country Living WT-KD1422N Assembly Instruction

ADIRONDACK CHAIR
VENDOR CODE #: WT-KD1422
MADE IN CHINA
READ & SAVE THESE INSTRUCTIONS:
Examine all packing material before assembling, shortages
may occur from parts left in the packing material.
Please follow below instructions to assemble step by step.
PARTS LIST
Parts List
Parts No.
A
B
C
D
E
F
G
H
ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION
ASSEMBLY INSTRUCTION ASSEMBLY INSTRUCTION
Description QTY
SEAT
1PC
BACK
1PC
SUPPORT
RIGHT LEG
1PC
LEFT LEG
1PC
RIGHT ARM
1PC
LEFT ARM
1PC
MIDDLE BACK
1PC
BAR
WOOD SLAT
1PC
Parts List
Parts No.
1
2
3
4
5
6
7
8
9
P.01
Description QTY
BOLT
4PCS
1/4"*2"
BOLT
6PCS
5/16"*2-1/2"
Washer
5/16"* 23mm*1.5mm 12PCS
Washer
4PCS
1/4"* 19mm*1.0mm
Nut
6PCS
5/16"
SCREW
11PCS
8*1-1/4"
Hexagonal
2PCS
Wrench
1PC
Y Wrench
PHILLIPS HEAD
SCREWDRIVER IS
REQUIRED (NOT
INCLUDED)
