Technical specifications Pro-Ject Phono Box USB

A
Typical for low output MC cartridges,
Input capacitance/input impedance, MC: 100ohms/120pF
Input capacitance/input impedance, MM: 47kohms/120pF
Gain, MM:
Output voltage typically:
Gain, MC:
Output voltage typically:
Max. output
Noise floor, MM:
Noise floor, MC:
THD, MM:
THD, MC:
RIAA-equalisation curve accuracy:
A/D converter:
Sampling rates:
USB output:
USB signal:
Operating systems:
THD:
Noise floor:
Dynamic range:
Outboard power supply:
Power consumption:
Dimensions W x H x D (D with sockets):
Weight:

Warranty

The manufacturer accepts no responsibility for damage caused by not adhering to these instructions
for use. Modification or change to any part of the product by unauthorized persons release the
manufacturer from any liability over and above the lawful rights of the customer.

Safety instructions

AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.

Copyright, trademarks

PRO-JECT is a Registered Trademark of H. Lichtenegger.
This guide was produced by: Audio Trade GmbH
Copyright © 2011. All rights reserved.
Windows XP ® , Windows Vista
Mac and Mac OS are trademarks of Apple Inc., registered in the U.S. and other countries.
4
© Audio Trade GmbH · Pro-Ject Phono Box USB · Revision 2013.3.15
B
typical for MM or high output MC cartridges
40dB
300mV/1kHz at 3mV/1kHz (MM input)
60dB
300mV/1kHz at 0,3mV/1kHz (MC input)
9,5V (1kHz)
94dB (A weighted)
75dB (A weighted)
<0,01%
<0,05%
20Hz - 20kHz / max. 0,5dB
Burr Brown PCM2904 16-Bit Delta Sigma
32, 44,1 and 48kHz
5 pin mini b connector (USB cable supplied)
digital serial data protocol USB 1.1
Windows XP
0,005%
96dB
93dB
18V/500mA DC, suitable for your country's mains supply
100mA DC
103 x 36 x 104 (115)mm
570g without power supply
® , Windows 7 ® , Windows 8
A
B
® ®
, Windows VISTA , Windows 7
The information was correct at the time of going to
press. The manufacturer reserves the right to make
changes to the technical specification without prior
notice as deemed necessary to uphold the ongoing
process of technical development.
® are trademarks of the Microsoft group of companies.
® ®
, Windows 8 , Mac OS
