M0772/0802
User' s Guide
Shop online at
e-mail: info@omega.com
FSW-50 Series
Industrial Flow Switches
www.omega.com
Advertisement
Table of Contents
Related Manuals for Omega Engineering FSW-50 Series
Summary of Contents for Omega Engineering FSW-50 Series
- Page 1 User’ s Guide Where Do I Find Everything I Need for Process Measurement and Control? OMEGA…Of Course! Shop online at www.omega.com TEMPERATURE Thermocouple, RTD & Thermistor Probes, Connectors, Panels & Assemblies Wire: Thermocouple, RTD & Thermistor Calibrators & Ice Point References Recorders, Controllers &...
- Page 2 Directives. OMEGA will add the CE mark to every appropriate device upon certification. This affords our customers the latest in technology and engineering. The information contained in this document is believed to be correct, but OMEGA Engineering, Inc. accepts OMEGA is a registered trademark of OMEGA ENGINEERING, INC.
-
Page 3: General Description
General Description Notes The OMEGA ® FSW-50 Series Flow Switches feature a 15A SPDT switch and an internal screw adjustment which provides continuous switch point adjustment while in operation in-line. Multiple drag disks are supplied with each unit to provide incremental switch point adjustment. Their non- magnetic design makes them ideal for applications where rust is a problem. - Page 4 Notes Available Drag Disks The FSW-50 Series Switches come with three different drag disks. The drag disks are sized as follows: DRAG DISK SIZE .5" dia. .83" dia. 1.0" dia. The following table lists flow adjustment limits for various pipe sizes relative to Model No.
-
Page 5: Installation Dimensions
Relay Switch: SPDT 15A @ 125 or 250 Vac, 10,000,000 Notes operations median Nominal Sensitivity (% Flow Change to Activate Switch): Approximately 10% @ upper end of range; approximately 30% @ lower end of range Differential Pressure Drop Across Unit: (Under normal operating conditions) 1"-3"... -
Page 6: Installation
ASSEMBLY WARNING THE FSW-50 SERIES SWITCHES EMPLOY AN EXTERNAL SEAL SHAFT (A) A FLEXIBLE ELASTOMER DIAPHRAGM SEAL (B) AND AN INTERNAL FEED THRU SHAFT OR SWITCH ACTUATING ARM (D). ALL THREE ELEMENTS ARE ASSEMBLED AND LOCKED IN PLACE WITH LOCTITE ADHESIVE. TO PREVENT RUPTURE OF SEAL AND LEAKAGE INTO SWITCH AREA, IT IS CRITICALLY IMPORTANT THAT TORQUE NOT BE APPLIED TO SEAL SHAFT (A), FLOAT SHAFT (E) OR DRAG DISK ARM (E) DURING CHANGE 10402-6. -
Page 7: Electrical Wiring
Thus: 1. Teflon tape thread and tighten the plastic bushing into the pipe or tank fitting. 2. Teflon tape thread and tighten the switch into the PLASTIC bushing by applying a wrench to the hexagon section. Repeat steps 1 and 2 until the ARROW on the body points in the 10398-6. -
Page 8: Switch Point Adjustment
Figur 6. If the system flow rate is changed, the FSW-50 can be adjusted to e 2: Wiring Schematic for power applied to load when the flow is greater monitor the new flow rate by turning the adjusting screw in a than set point (power to load interrupted when flow decreases to below set counterclockwise direction to the minimum flow position and then point).
