Summary of Contents for Garden Oasis AS-I-138-2/6
- Page 1 OWNER’S Product code: D71 M80206 UPC code: 7-6945575480-6 MANUAL Vendor Item: AS-I-138-2/6 Clayton 7 PC Dining Set Date of purchase: _____/ _____/ _____...
- Page 2 PARTS Read through all the instructions before beginning assembly. Unpack and identify all the parts. Place them on a flat, non-abrasive surface. Assembly by two people is recommended. A (6) B (6) Chair Base Sling Seat and Back ACCESSORIES Ce (2) Ca (12 + 1 spare) Allen Wrench Short Bolt...
- Page 3 ASSEMBLY INSTRUCTIONS Fig. 2 Place the sling seat and back (B) on the chair base (A) and align the holes in the arms of the base with the holes in the sling back. For each side of hole, insert a short bolt (Ca) through a metal washer (Cc), through the side rail of sling back, secure into the arm.
