Craftsman 917.371860 Owner's Manual

875 series briggs & stratton engine power-propelled electric start 21" multi-cut rotary lawn mower
Hide thumbs

Advertisement

Quick Links

Owner's Manual
CRAFTSMAN °
ROTARY
875 Series Briggs & Stratton
Power-Propelled
Electric Start
21" Multi-Cut
Engine
Model No.
917.371860
• EspaSol, p. 22
CAUTION'.
Read and follow all
Safety Rules and Instructions
before operating this equipment
Sears, Roebuck and Co., Hoffman Estates, IL 60179
Visit our Craftsman website: www.sears.com/craftsman
U.S.A.
