i Aodel 139.53778
3-Fu nction
Transmitter
Owners
Manual
F+CC+ rules prohibit adjustments
to or modification
of receiver andlor transmitter
circuitry except for changing
the code setting
and replacing
transmitter
battery. THERE ARE NO OTHER USER SERVICEABLE
PARTS_
Manufactured under I or mors of th_ lot[owingUS palents: RE29,525; 4,037,201;4,750jt8; 4.806,930
MATCH
THE CODE
IN NEW AND
EXISTING
TRANSMITTERS
If this transmitter
will be used wlth an existing
transmitter
to ope_te
the same receiver(a),
proceed
as follows:
Locate the code switches in original transmitter(s),
Open the battery compartment
cover in the new 3-function transmitter
to access the code _witches,
Place the transmitters
side by side as shown below.+
Set code switches in the new transmitter
to the same positions as code switches in the odglnal transmitter(s),
NOTE 1: Code switches
#2 through #9 In ALL transmitters
used to operate
a receiver
must be set to match. (Code
switch
#1 on a 3-function
transmitter
is neutral,
Set it to ANY position.
It will not affect the code
selected.
NOTE 2: If the original
transmitter(s)
has only 7 or 8 code switches,
set code switches #8 and/or #9 to center
(0) position
in new transmitter,
3-Fur_l_on
Transmitler
Cede Switches
(_._)
C:3
C:_ H
J 3-Funclion
_
Transmitte,"
i_--"_1_""_
+
tl
Code Switches
O "
3-Func_n
Mini Transrnirier
Code Switches
(_-9)
REPLACEMENT PARTS: Case, top and bottom (No circuit board) - 41A3476; Visor clip - 290128; 12V Battery. 10A14
CHANGE THE CODE IN RECEIVER AND TRANSMITTER(S)
530OOSR SERIES
0NITH REC-EIVER 'SR' CODE B_N)
Garage
Door Openers
and Light Controls
(ltlustration
A shows e garage door opener receiver)
SeJec[ a transmlt_er ==
push
buttc_
to
_,_
operatereceiver
PUsh Butlons
Cede Bu_on
u_
Make sure all transmitters are set tomatching code switch
positions as described above.
1+Press the 'SR' code button on your receiver+(illustra-
tion (A) shows a representative garage door opener
receiver). The indicator light will turn ON,
2, STAND AWAYFROM DOOR ar_ press the SELECTED
PUSH BUTTON of one transmitter. The indicator light
will turn OFF and door will move.Code In receiver now
matches transmitter(s) code and will activate when the
selected transmitter push button is pressed,
NOTE." If transmitter push button le not pressed
within 30 seconds, the lndic.slor light will turn OFF,
Repeat 1 and 2.
To use the 3-Function Transmitterwith other 53000 SR
Series receivers: Select anothertransmitter pushbutton
tooperatea Ught Control or additbnal garagedooropener.
All transmitters used tooperate receiver mt_'t be set to the
same code (as described abo_e). Then repeat t and 2.
You can select a different transmitter push button to oper-
ate each device.
114Al154B
53000 SERIES
(WITH RECEIVER CODE SWITCHES)
Garage Door Openers
and Light Controls
(Illustration
B shows n garage door opener receiver)
PushButlon(-)_
PushButton(0)
PushBunon(+)
B
t%%%
[]
l
Code switch #1 in (-) pos'll_on, Receiver w_lt
operate wibh transmitters'
large push bullon
Select a
Iransmit[er
push but_c,n
to operate
receiver
Slide receiver
code switch # I
to posldon b"_t
matches selected
Iransmiller
push button
Make sure 811 transmitters are set to malching code switch
positions
as described
above.
I. Select a transmitter push button to operate the receiver
as shown in Figure B,
2. Set RECEIVER code switch #1 to match the position
of the
transmitter
push
button
selected.
Refer
to
Illustration
(B). Then set remaining
code switches in
receiver to match the transmitter(s) code switch positions.
NOTE: if the receiver has only 7 or 8 switches,
set
transmitter swttch #8 and/or #9 to (0)o
To use the 3-Function
Transmitter with other 53000
Series receivers:
Set receiver code swilch #1 to match
the position of another transmitter push button+ Then set
remaining
code switches
to match transmitter(s)
code
switches+
Code switches #2 through #9 in all transmitters
used
to operate
the receiver
MUST be set to matching
positions.
i
ii ii
ii
i H
ml ii i
H ii ilmlll.,.
,ll.ll.llHll
@ 1990_Sears Roebuck & Company
All Rights Reserved
Printed In Mexk:o
