- Page 1 INTERFACES MANUAL PART NUMBER: 400-0103-001 PRODUCT REVISION: 2 VA6822 SYSTEM INTERFACE WITH AUDIO & EQUALIZATION USER’S GUIDE...
-
Page 2: Table Of Contents
SYNC ON GREEN OUTPUT SWITCH ... 10 TERMINATION SWITCH ... 10 EQUALIZATION... 10 AUDIO ... 10 ACCESSORIES ... 11 FAQ (FREQUENTLY ASKED QUESTIONS)... 12 TROUBLESHOOTING GUIDE ... 12 ALTINEX POLICY ... 13 LIMITED WARRANTY ... 13 RETURN POLICY... 13 CONTACT INFORMATION... 13 Page INTERFACES... -
Page 3: Precautions / Safety Warnings
1.1 GENERAL Unauthorized personnel shall not open the unit since there are high-voltage components inside. Qualified ALTINEX service personnel, or their authorized representatives must perform all service. 1.2. SAFETY GUIDELINES FOR THE RACK- MOUNTING OF THE VA6822 Maximum operating ambient temperature is 35 (degrees C). -
Page 4: About Your Interface
Any changes or modifications to the unit not expressly approved by ALTINEX, Inc. could void the user’s authority to operate the equipment. ABOUT YOUR INTERFACE There are a several varieties of computers and computer video cards on the market today. -
Page 5: Electrical Specifications
75 Ohms for video connection of a computer to the system interface signal; 22 Ohms for using ALTINEX-made input cables which are sync signal available for a variety of popular computers and graphics cards on the market such as VGA, MAC, SUN, and SGI. -
Page 6: Local Monitor Output
The output is VESA compatible for VGA through UXGA signals, but can also be used to transmit signals to other types of local monitors using designated ALTINEX adapter cables such as MAC, SUN, SGI, or RGB. LOCAL MONITOR OUTPUT SIGNALS ON... -
Page 7: Horizontal Delay Removal
Four mounting holes are provided on each side of the unit. To mount a single unit, use ALTINEX 19”-1U Rack Mount Ears (part # DA1294FC). To mount two units in tandem, use an ALTINEX 19”-1U Rack Mount Shelf (part # DA1293FC). - Page 8 INTERFACES DESCRIPTION OF VA6822...
-
Page 9: Application Diagram
INTERFACES APPLICATION DIAGRAM... -
Page 10: Installing Your Interface
Step 4. Connect local connector of the VA6822 to a local monitor or display using the appropriate ALTINEX Local Monitor cables. It is not necessary to terminate this output with a termination plug if a local monitor is not being used. -
Page 11: Operation
OPERATION In most cases no adjustments are necessary to obtain a good quality picture on the display; however, dip-switches located on the front panel should be set for certain types of input and output signals. The factory default settings are shown below in Table 7. -
Page 12: Audio
ACCESSORIES Model No. Description RACK MOUNT ACCESSORIES Rack/Wall Shelf fits two VA6822 DA1293SX units side by side Rack/Wall mount ears for single DA1294SX VA6822 TABLE MOUNT BRACKETS 1U High, ½ Rack-Wide TM1271 1U High, ½ Rack-Wide with 15-pin TM1272 HD connector plate 1U High, ½... -
Page 13: Faq (Frequently Asked Questions)
RED, GREEN, and BLUE channels are less than 1.2Volts b) HSYNC & VSYNC are less than 5.0 volts Please use only an ALTINEX supplied power cord suitable to the country of usage for proper operation of the VA6822. If problems show up on the display after... -
Page 14: Altinex Policy
11.2 RETURN POLICY It is very important to ALTINEX that you receive the products that you have ordered and that this product meets your expectations. In the unlikely event, that an ALTINEX product needs to be...
