- Page 1 INTERFACES MANUAL PART NUMBER: 400-0039-003 PRODUCT REVISION: 1 VA6834FC SYSTEM ANALOG INTERFACE USER’S GUIDE...
-
Page 2: Table Of Contents
SYNC ON GREEN OUTPUT SWITCH ...9 TERMINATION SWITCH ..9 ACCESSORIES..10 FAQ (FREQUENTLY ASKED QUESTIONS) ...11 TROUBLESHOOTING GUIDE ...12 ALTINEX POLICY ..13 LIMITED WARRANTY..13 RETURN POLICY ..13 CONTACT INFORMATION ...13 INTERFACES... -
Page 3: Precautions / Safety Warnings
Otherwise, Rack- VA6834FC INTERFACES to a table or wall, use only Altinex made mounting accessories, such as brackets (DA1293FC or DA1294FC) and cables for optimum setup. To turn off the main power, be sure to remove the power cord from the power outlet. The... -
Page 4: About Your Interface
Any changes or modifications to the unit not expressly approved by Altinex, Inc. could void the user’s authority to operate the equipment. ABOUT YOUR INTERFACE There are many types of computers and computer video cards on the market today. There are also numerous data monitors and large screen data projectors. -
Page 5: Va6834Fc Description
COMPATIBLE HD 15-PIN CONNECTOR). The HD 15-pin connector input allows the connection of a computer source to the interface using Altinex input cables, which are available for a variety of popular computers and graphics cards on the market. These include VGA, MAC, SUN, and SGI type video output connectors with the proper cables. - Page 6 INTERFACES...
- Page 7 INTERFACES...
-
Page 8: Horizontal Position Adjustment
The VA6834FC can be easily mounted into an equipment rack. Four mounting holes are provided on each side of the unit. To mount a single unit, use Altinex 19”-1U Rack Mount Ears (part # DA1294FC). To mount two units in tandem, use an Altinex 19”-1U Rack Mount Shelf (part # DA1293FC). -
Page 9: Application Diagram
The Interface can also be attached on top or under furniture using the optional TM Series Altinex brackets. Step 2. Before you plug in the power cord to the unit, please verify that the voltage rating of 110V/220V which is located on the FUSE CLIP at the rear of the unit is the same as the power outlet. -
Page 10: Operation
OPERATION The settings of the VA6834FC Interface can be adjusted using the dip-switches in Table 4. There are no other adjustments necessary to operate the unit. The VA6834FC will operate successfully as long as cables are attached properly and technical specifications are followed. -
Page 11: Rack Mount Accessories
ACCESSORIES Model No. Description RACK MOUNT ACCESSORIES DA1293SX Rack/Wall Shelf fits two VA6834FC units side by side DA1294SX Rack/Wall mount ears for single VA6834FC TABLE MOUNT BRACKETS 1U High, ½ Rack-Wide TM1271 TM1272 1U High, ½ Rack-Wide with 15-pin HD connector plate 1U High, ½... -
Page 12: Faq (Frequently Asked Questions)
100 ft, 5-BNC M to 5-BNC M CB5100PL- 5BM01005BM CB5100PL- 150 ft, 5-BNC M to 5-BNC M 5BM01505BM CB5100PL- 200 ft, 5-BNC M to 5-BNC M 5BM02005BM CB5100PL- 250 ft, 5-BNC M to 5-BNC M 5BM02505BM All MS81 series cables listed on the previous page are 3 ft. -
Page 13: Troubleshooting Guide
Red Gnd Green C.Sync Blue ID Bit 01 ID Bit Green Green Gnd. Red Rtn. ID Bit 02 Green Rtn. Blue Rtn. Blue ID Bit 03 C/V Gnd. ID Bit V. Sync ID Bit Blue Gnd. H. Sync. H. Gnd V. -
Page 14: Altinex Policy
11.2 RETURN POLICY It is very important to Altinex that you receive the product that you have ordered and that this product fulfills your need. In the unlikely event,...
