1 Creating virtual cache partitions

Unless otherwise specified, the term P9000 in this guide refers to the following disk array:
P9500 Disk Array
The GUI illustrations in this guide were created using a Windows computer with the Internet Explorer
browser. Actual windows may differ depending on the operating system and browser used. GUI
contents also vary with licensed program products, storage system models, and firmware versions.
This chapter provides detailed instructions for dividing storage system cache memory into virtual
cache logical partitions (CLPRs) using Cache Partition software.

About virtual cache partitions

If one storage system is shared with multiple hosts, one host reading or writing a large amount of
data can require enough of the storage system's cache memory to affect other users. The Cache
Partition function allows improved I/O performance by dividing storage system cache memory
into multiple virtual cache memories (cache logical partitions or CLPRs).
Partitioning cache matches data to appropriate storage resources based on availability,
performance, capacity, and cost. It improves flexibility by allowing dynamic changes to cache
partitions while in use.
Partitioning cache dedicates cache resources for exclusive use by specific applications to maintain
priority and quality of service for business-critical applications. Storage administrators can secure
and/or restrict access to storage resources to ensure confidentiality for specific applications. By
dedicating resources to each partition as needed, a high quality of service can be maintained for
all users.
The following illustrates the use of cache memory within a corporation. In this example, cache
memory is partitioned into three segments of 40 GB, each of which is allocated to a branch office.
The host of branch A has a heavy I/O load. Because the cache memory is partitioned, that heavy
I/O load does not impact the cache memory for the other two branches.

Cache capacity for a CLPR

A CLPR is a pool of the cache and parity groups in the storage system. Partitioning cache into one
or more CLPRs allows storage administrators to dedicate individual CLPRs to a different host,
preventing I/O contention for cache memory.
