USER'S MANUAL
MANUEL DE L'UTILISATEUR
MANUAL DEL USUARIO
CW39T8RW

Advertisement

Table of Contents
loading

Related Manuals for Westinghouse CW39T8RW

Summary of Contents for Westinghouse CW39T8RW

  • Page 1 USER’S MANUAL MANUEL DE L’UTILISATEUR MANUAL DEL USUARIO CW39T8RW...

  • Page 3: Table Of Contents

    Contents Contents Caution Safety Information Unit and Accessories Product Feature Introduction 1. Front View 2. Rear View 3. Instruction for Wall Mount 4. Remote Control First Time Installation 10-11 Basic Operation OSD Menu 13-21 1. Picture menu 13-14 2. Sound menu 3.

  • Page 4: Caution

    FEDERALLAWS. ENERGY STAR : This Westinghouse product has earned the Energy Star for meeting U.S. Federal energy efficiency guidelines as set by the Department of Energy and Environmental Protection agency. The Energy Star program exists to provide energy saving guidelines and help promote energy efficient products and practices.

  • Page 5: Safety Information

    Safety Information Safety Information Electrical safety the power cable Physical safety...

  • Page 6: Unit And Accessories

    Unit and Accessories and Product Feature Unit and Accessories Warranty Card TV set User's Manual Power Cord Quick Connect Guide Remote Control and Batteries (AAA x2) Product Feature 1920 x 1080 native resolution for Full-HD(1080p) performance Three HDMI inputs for true digital connections ®...

  • Page 7: Introduction

    Introduction Introduction 1. Front View Power Indicator Remote Control window (Keep clear) 1). (IR) Infrared Receiver: Receives IR signals from the remote control. (Power on/Standby)LED Indicator: Press POWER to turn on and off. Indicator on(Red) Standby mode Indicator on(Green) Power on mode The effective receiving range for the signal is 5-8 metres from the front of the remote control window, and 30 to the left or right side and 20...

  • Page 8: Rear View

    Introduction 2. Rear View COAX PC-IN HDMI 1 HDMI 2 HDMI 3 AC POWER IN SWITCH (SERVICE) VIDEO R in L in AUDIO OUT HEADPHONE OUT 1). COAX : Digital audio output. RF : Connect antenna or cable 75 Ohm coaxial to receive TV signal. : Connect it to the HDMI output of video device.

  • Page 9: Instruction For Wall Mount

    - Do not mount your Westinghouse TV at more than a 15 degree tilt. - Always use two people to mount the TV to a wall. - Do not install your Wall Mount Kit while your TV is turned on. It may result in...

  • Page 10: Remote Control

    Introduction 4. Remote Control The remote control is using Infra-Red(IR). Point it towards the front of the TV. The remote control may not work correctly if it is operated out of range or out of angle. POWER(red button): Turn the TV on/standby. INPUT INPUT: Press to display the input source menu.
  • Page 11 Introduction Installing Batteries 1. Open the battery compartment cover on the back of the remote control. 2. Insert two 1.5V AAA size batteries observing the polarity markings inside the battery compartment. Don’t mix different types or used batteries with new ones. 3.

  • Page 12: First Time Installation

    First Time Installation First Time Installation The following pictures will appear on the screen when the TV is turned on for the first time. 1. Select the OSD menu language by buttton, and press OK/ENTER button to enter the next menu. 2.

  • Page 13: First Time Installation

    First Time Installation 5. Select the Antenna [ATSC] or Cable mode by buttton, and press OK/ENTER button to enter the next menu. 6. Select Next item by button and press OK/ENTER button to enter the next menu. Model: XXXXXXX Serial No: XXXXXXXXXXX Channel Scan Type: ATSC 7.

  • Page 14: Basic Operation

    Basic Operation Basic Operation Power on/off 1. Connect to the power supply with the power cord, and turn on the switch. 2. -To turn on the TV Press POWER button on the TV or remote control. -To turn off the TV Press POWER button on the TV or remote control.

  • Page 15: Osd Menu

    OSD Menu OSD Menu 1. Picture menu Description Picture Settings: Press button to enter the Picture Settings menu. Picture mode: Select between Dynamic, Standard, Movie and User. You may select the picture mode directly by pressing the PICTURE button on the remote control. Note: when select the "Standard", the machine is in energy-saving status.
  • Page 16 OSD Menu OSD Menu Advanced Picture Settings: Press button to enter the Advanced Picture Settings. Dynamic Contrast: Activate or deactivate the Dynamic. Contrast funciton. Film Mode: Activate or deactivate the Film Mode. Noise Reduction: If the broadcast signal received is weak, you can select the DNR option to reduce the video noise level between Off, Low, Medium and High.

  • Page 17: Sound Menu

    OSD Menu OSD Menu 2. Sound menu Description Sound Settings: Press button to enter the Sound Settings menu. Sound Mode: Select your desired picture mode as follow: Dynamic, Standard, Soft and User. You may select the sound mode directly by pressing the SOUND button on the remote control.

  • Page 18: Channel Menu

    OSD Menu OSD Menu 3. Channel menu Description Channel List: Display the channel list. Favorite List: Display the favorite channel list. Channel Settings: Press > button to display the Channel Settings menu. Press button to select the item, and press OK button to change the setting.
  • Page 19 OSD Menu OSD Menu If you select “QAM” as input signal in Signal Type item, you can press button to search the channels automatically. The receivable channels will be stored automatically. When searching channels, press MENU to stop. NOTE: It will take a while to auto scan in NTSC or ATSC mode, please wait patiently. 1.

  • Page 20: Parental Control Menu

    OSD Menu OSD Menu 4. Parental Control menu You must enter the password to gain access to the Parental Control menu. The default password is 0000. You may modify the following options: Description V-CHIP: Press button to enter the V-CHIP menu. US V-CHIP: Press button to enter the US V-CHIP menu.
  • Page 21 OSD Menu OSD Menu Canada V-CHIP: Press button to enter the Canada V-CHIP menu. English Rating: Select among: C, C8+, G, PG, 14+ and 18+. French Rating: Select among: G, 8ans+, 13ans+, 16ans+ and 18ans+. Block UnRated Show: Activate or deactivate the Block UnRated Show function. Downloadable Rating: Setting the Downloadable Rating in DTV mode when the program has the rating information.

  • Page 22: Setup Menu

    OSD Menu OSD Menu 5. Setup menu Description Closed Caption: Press button to enter the Closed Caption menu. Caption Display: Activate or deactivate the Caption displaying. Analog Caption Type: Allow you to select the basic selection among: CC1, CC2, CC3, CC4, Text1, Text2, Text3 and Text4.

  • Page 23: Others Menu

    OSD Menu OSD Menu 6. Others menu Description Blue Back: Turn on/off the blue screen function when there’s no signal. No Signal Power Off: The TV will turn off automatically if there’s no signal after 10 minutes. No Operation Power Off: The TV will turn off automatically if there’s no operation on the TV after 3 hours.

  • Page 24: Simple Troubleshooting

    Simple Troubleshooting If the TV has failed or its performance has seriously deteriorated, check the TV by using the following simple troubleshooting guide. If you can not resolve the problem with this troubleshooting, please call Westinghouse Technical Support. No power - Check all power connections to the TV.
  • Page 25 LCD Panel Panel Size 39 inches (diagonal) Resolution 1920 x 1080 Input Connector Video Audio(L/R) PC Audio HDMI YPbPr Headphone Output Connector COAX Audio (L/R) Power Source AC 100 - 240V, 50/60Hz Maximum Power Consumption 150W * Product specifications and appearance are subject to change without notice. HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.
  • Page 28 S/N: Westinghouse Digital, LLC Orange, CA SE-UM-3901-1201...
