870-03-018, rev. 05/13/04
www.ergotron.com
© 2004 Ergotron, Inc.
Ergotron
CRT Monitor Arm

Mounting Solutions

Ergonomic solutions for any area of your facility
®
Orderguide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CRT Monitor and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ergotron CRT Monitor

  • Page 1: Mounting Solutions

    870-03-018, rev. 05/13/04 www.ergotron.com © 2004 Ergotron, Inc. Ergotron ® CRT Monitor Arm Mounting Solutions Ergonomic solutions for any area of your facility Orderguide...
  • Page 2 Ergotron is a registered trademark of Ergotron, Inc. Reproduction of this material in whole or in part for any purpose other than that authorized by Ergotron, Inc. is prohibited. © 2004 Ergotron, Inc. All rights reserved.
  • Page 3: Table Of Contents

    Orderguide CRT Monitor Arm Mounting Solutions Table of Contents Introduction ........
  • Page 4: Introduction

    200° of Side-to-Side Rotation 360° of Monitor Swivel Note: Ergotron also offers a wide variety of mounting systems specially designed for flat panel monitors. For more information, see our Flat Panel Mounting Solutions Orderguide, #870-03-005 on our website, www.ergotron.com. •...
  • Page 5: Product Line Overview

    16" Arms Lift N12 Arms for NEMA environments Extender Arms Mounting Systems Lift 19" Horizontal Arm Components Suspend • CRT Monitor Mounting Solutions Orderguide 870-03-018 rev. 05/13/04 Keyboard Solutions Command Posts Wall Tracks Wall Brackets Peripherals & Accessories Desk Mounts...
  • Page 6: Sample Configurations

    Sample Configurations Configure your own customized solutions with Ergotron’s modular components. Here are some examples of common configurations. Mounts to ceiling • CRT Monitor Mounting Solutions Orderguide Configuration A 20-078-000 Command Post, 4" x 4" x 96" Post 60-138-000 Base for 4" x 4" Post 60-155-000 Bracket for Arm to 4"...
  • Page 7 Sample Configurations Configure your own customized solutions with Ergotron’s modular components. Here are some examples of common configurations. Configuration D 31-018-182 Wall Track, 34"L 44-314-000 18" Extender Arm 60-188-099 Bracket for Arm to Wall Track 44-303-000 6" x 13" “B” Suspension Arm...
  • Page 8: Monitor Arms

    13.54 • CRT Monitor Mounting Solutions Orderguide Fixed Arms swing, and rotate monitors to the point of need. Their tilt control extends a monitor’s vertical viewing range. These arms can be used with a Monitor Caddy in a suspend mode, or turned over and used with a Monitor Platform in a platform mode.
  • Page 9: 10" Lift Arms

    Command Post ..13 Rotation Control Kit . .12 Wall Track ..16 Wall Bracket ..17 • CRT Monitor Mounting Solutions Orderguide 870-03-018 rev. 05/13/04 Wall Track Wall Bracket...
  • Page 10: 16" Suspension And Lift Arms

    21.69 24.76 • CRT Monitor Mounting Solutions Orderguide Sixteen inches (406 mm) of vertical movement provides true ergonomic adjustability in sitting or standing applications. It even accommodates the average sit-to-stand height-range. This arm features clean styling and built-in cable management. It’s available as a suspension arm (use with Caddy) or a lift arm (use with Platform).
  • Page 11: N12 Arm For Nema Environments

    A monitor arm attaches to an Extender Arm, which connects to Command Post or Wall Track via a bracket. Wall Bracket requires no extra bracket • CRT Monitor Mounting Solutions Orderguide 870-03-018 rev. 05/13/04 Weight Capacity 25-100 lbs (11.4-45.4 kg)
  • Page 12: Arm Components

    Rotation Control Kit 97-053-002 • CRT Monitor Mounting Solutions Orderguide Monitor Caddies are used in conjunction with Suspension and Fixed Arms. A monitor is securely cradled within the Caddy. Choose a Caddy appropriate to your monitor’s size. The Caddy’s telescoping frame further adjusts to an individual monitor’s height.
  • Page 13: Mounting Systems

    Ext = Extender Arm (page 11) The 2" x 2" Post should not be mounted to floor or ceiling in applications using CRT Monitor Arms. ** When mounting 4" x 4" Post to machine or bench, fasteners to be supplied by customer.
  • Page 14 (4) concrete stud anchors (9.5 x 95 mm) Note: Mounting 2" x 2" Post to floor or ceiling is not recommended in applications using CRT Monitor Arms. Note: Order the Hardware Kit for Base when attaching to a concrete surface.
  • Page 15 Note: If you plan to mount a monitor arm and peripheral on the same bracket, order Bracket for Arm to Post (previous page) and Fastener Kit #97-097-099 (above). • CRT Monitor Mounting Solutions Orderguide 870-03-018 rev. 05/13/04 Example of CPU...
  • Page 16: Wall Tracks

    This system attaches to most vertical surfaces – such as walls, pillars, and machines – and provides one standard interface that will mount multiple Ergotron components anywhere along its length. Choose a length of Wall Track that will accommodate the size and number of components you wish to mount.
  • Page 17: Wall Bracket

    60-152-000 Wall Mounting Bracket 6-5/8" x 8" with arm fasteners (168 x 203 mm) Note: Fasteners that attach Wall Bracket to wall are not supplied by Ergotron. Wall Bracket Fasteners that attach bracket to wall not included Desk Mounts allow direct attachment of a monitor arm to a horizontal surface, like a tabletop or desk.
  • Page 18: Keyboard Solutions

    Note: See page 25 for information regarding other keyboard mounts. • CRT Monitor Mounting Solutions Orderguide Wire Keyboard Holders: Store your keyboard out of the way, then pull it out when needed. Tilt up or down in 15˚ increments. Keyboard Holders mount under Caddies and Platforms.
  • Page 19: Peripherals And Accessories

    Note: When mounting directly to surface, fasteners are supplied by user. CPU Cabinet: Ergotron’s CPU Cabinet provides a secure enclosure to mount and protect equipment up to 18-3/8" wide. It secures with a lockable, hinged front panel and lockable, removable back panel.
  • Page 20: Peripheral Table

    Fastener Locking Strap • CRT Monitor Mounting Solutions Orderguide The Peripheral Table provides a solid, laminated surface for writing or holding equipment. Comes in Grey Millstone finish. Configure it with either a Fixed or Fold-Away Underbracing. Mount to Command Post, Wall Track, or directly to a vertical surface.
  • Page 21: Footrests

    The 12-foot length can be cut down to any size that is required by your application. The N12 Suspension Arm employs a tubing system that conceals and routes cables in NEMA 12 environments – order 97-179-098 when configuring an Ergotron NEMA Arm. Part...
  • Page 22: Appendix

    • CRT Monitor Mounting Solutions Orderguide Fixed Arms ..........100 lbs (45.4 kg) 6"...
  • Page 23: Hole Patterns

    (63.5 mm) 1" (25.4 mm) 7" (178 mm) 8" (203 mm) .406" (10.3 mm) Center-line • CRT Monitor Mounting Solutions Orderguide 870-03-018 rev. 05/13/04 4" x 4" Post Hole Pattern 16-9/16" (421 mm) 8-9/32" (210 mm) Center 8-9/32" lines (210 mm) 16-9/16"...
  • Page 24: Computer Carts

    CRT Monitor Mounting Solutions Orderguide No matter how demanding the mobile computing application, or what type of computing equipment you need to mobilize, Ergotron has a computer cart to get the job done. Ergonomic design, versatile cable management, high-quality components and rugged construction let you go mobile with confidence and stay mobile over the long term.
  • Page 25: Other Keyboard/Laptop Mounts

    22" (559 mm) Several keyboard and laptop mounting products are available from Ergotron. Choose from arms and pivots that extend, raise, swing and/or tilt a keyboard to the point of use. Keyboard and Mouse Trays featured on page 18 of this guide are compatible with these products.Use with Command Post, Wall Track and other...
  • Page 26: Ergonomics Data

    1. Eye Height — The following vertical height mounting tables are based upon the sound ergonomic principal that for optimum viewing comfort and proper posture, the top of the CRT monitor screen should be level with or slightly below the eye height of the user. This provides an approximate 15°...
  • Page 27 Anthropometric Data for Average Range of Users Eye height/elbow height = distance from top of CRT monitor screen to keyboard tray—roughly 21". Workstation with 6" of vertical adjustability can provide optimum viewing height for the average range of female to male operators in either a sitting or standing environment.
  • Page 28 1982, Ergotron has designed and engineered products specifically for improving the human interface with computers. Innovative engineering concepts incorporate the human factor into each and every product. With our patented Monitor Suspension technology as the core, Ergotron designs Mounting Solutions that consistently meet the ever changing needs of our customers.
