EPSON PowerLite 7000XB Multimedia Projector
Supported monitor resolutions
The projector displays images at a resolution of 1024
pixels. To display a higher resolution image, the projector
compresses it to 1024 768. The following table lists the
display formats supported by the projector:
Computer type Formats
IBM PC and VGA, SVGA, VESA, EGA
IBM PC compatible XGA
Apple Macintosh Standard 8- and
24-bit color monitor
NEC PC
Note: The frequencies of some computers may not allow the image
to be displayed correctly.
Note: This projector is compatible with DDC-capable graphic
sub-systems and boards only.
* The projector uses a patent-pending technology to resize the
image to 1024 768.
Supported sync rates
Horizontal sync 15 to 81 KHz
Vertical sync 56 to 85 Hz
Supported sync types
Separate Sync, Composite Sync, Sync-on-Green
2 - PowerLite 7000XB Multimedia Projector
Projector Placement Guidelines
768
The distance between the projector and the screen determines
the actual image size. Use the general guidelines in the table
below to determine the proper distance.
Resolutions
640 480
Image size
640 200
(diagonal)
640 400
800 600 300 inches
1024 768
200 inches
*
1152 864
100 inches
*
1280 1024
80 inches
640 480
60 inches
832 624
1024 768
40 inches
1017 768
30 inches
*
1152 864
23 inches
640 480
*
1120 750

Projector Status Indicators

The power and lamp indicators at the top of the projector let
you know the projector's operating status, as described below.
Status indicator
Power indicator
Steady orange:
Steady green:
Flashing orange:
Steady red
Flashing red
Projection lamp indicator
Steady green
Flashing green
Orange and red
flashing alternately
Flashing orange
Steady red
Flashing red
Note: If you press the Power button to turn the projector back on
while the power indicator is flashing orange, there may be a delay
before the projected image appears.
1/2/98
Horizontal distance from
the projector screen
Minimum Maximum
393.7inches (10 m)
263.8 inches (6.7 m) 342.5 inches (8.7 m)
129.9 inches (3.3 m) 169.3 inches (4.3 m)
106.3 inches (2.7 m) 137.8 inches (3.5 m)
78.7 inches (2 m) 102.4 inches (2.6 m)
51.2 inches (1.3 m) 66.9 inches (1.7 m)
39.4 inches (1 m) 51.2 inches (1.3 m)
39.4 inches (1 m)
Function
Sleep mode. (The projector is plugged in,
but not projecting.)
Power and lamp are on.
The projector is hot.
The projector is too hot and has turned off.
Internal projector problem.
Projection lamp is on.
The projector is warming up.
Projection lamp needs replacing.
Projector lamp is cooling down.
Projector lamp has burned out. Replace it
to project images.
Problem with projection lamp or lamp
power supply.
