- Page 1 MULTI-TASKER MANUAL PART NUMBER: 400-0097-004 MT106-101 SCAN DOUBLER CARD FOR MULTI-TASKER USER’S GUIDE...
-
Page 2: Table Of Contents
7.3 SUMMARY OF COMMANDS ... 13 TROUBLESHOOTING GUIDE ... 14 8.1 LED IS NOT LIT... 14 8.2 LED IS BLINKING RED ... 14 8.3 NO DISPLAY ... 14 ALTINEX POLICY ... 15 9.1 LIMITED WARRANTY/RETURN POLICY 15 9.2 CONTACT INFORMATION... 15 MULTI-TASKER Page... -
Page 3: Precautions / Safety Warnings
Any changes or modifications to the unit not expressly approved by ALTINEX, Inc. could void the user’s authority to operate the equipment. cause undesired... -
Page 4: About Your Mt106-101
The MT106-101 offers 3 composite video inputs on female BNC connectors and an S-Video input on a standard 4-pin mini-DIN connector. The latter may be adapted to 2 BNC connectors using ALTINEX adapter cables. The MT106-101 output is provided on a 15-pin HD female (VGA-type) computer video connector. -
Page 5: Description Of Mt106-101
MULTI-TASKER DESCRIPTION OF MT106-101... -
Page 6: Application Diagram
MULTI-TASKER APPLICATION DIAGRAM Application 1 Application 2... - Page 7 MULTI-TASKER Application 2: Internal View of MT106-101...
-
Page 8: Installing Your Mt106-101
INSTALLING YOUR MT106-101 Step 1. Slide the MT106-101 into an available slot in the Multi-Tasker™ Basic Enclosure in order to connect to the bus. Make sure that the MT106-101 Scan Doubler card fits into place. Secure the card to the Multi-Tasker™... - Page 9 Ui = Unit ID (i = # from 0 to 9) (refer to the MT100-100 user’s guide for explanation) Example: If one Scan Doubler Card is in slot #2 of unit 3. Send the command [VERC2U3] Multi-Tasker™ Basic Enclosure will return the following: MT106-101 690-0155-003 MT106-101 = card type...
- Page 10 STATUS Command Value Value [ HPOS ] [ VPOS ] [ HSIZE ] [ VSIZE ] [ BRIG ] [ SHARP ] [ COLOR ] [ HUE ] Attempting to cycle past the minimum or maximum values will have no effect on the attribute's value.
- Page 11 This command selects the Vertical Position adjustment and makes it the active control. It also returns the status of the current Vertical Position. As the active control, it may be adjusted using the [ + ] and [ - ] commands. Command Format: [VPOSCiUy] Ci = card ID (i = slot number) Uy = unit id (i = 0 to 9) (refer to the MT100-100...
- Page 12 15. [BRIGnCi] - Set Value This command selects adjustment and makes it the active control. It also returns the status of the current Brightness level. As the active control, it may be adjusted using the [ + ] and [ - ] commands. Command Format: [BRIGnCiUy] = a value from 0 to 20 (Default = 10) Ci = card ID (i = slot number)
- Page 13 20. [COLORCi] - Status/Adjust The COLOR command, with no value, selects the Color adjustment and makes it the active control. It is also used to return the status of the current Color level. As the active control, it may be adjusted using the [ + ] and [ - ] commands. Command Format: [COLORCiUy] Ci = card ID (i = slot number) Uy = unit id (i = 0 to 9) (refer to the MT100-100...
-
Page 14: Summary Of Commands
25. [CLR] This command clears the members for a single group or for all nine groups. Command Format: [CLRGkUi] Gk = group number (k = # from 1-9) Ui = unit number (i = # from 0-9) Example: 1) To clear group #1, send the [CLRG1U1] command. -
Page 15: Troubleshooting Guide
Solution 2. Solution 2: Turn the system OFF and then ON again. If there is still an error, see Solution 3. Solution 3: Call ALTINEX at (714) 990-2300. 8.3 NO DISPLAY Cause 1: The source has a problem. -
Page 16: Altinex Policy
ALTINEX POLICY 9.1 LIMITED WARRANTY/RETURN POLICY Please Altinex www.altinex.com for details on warranty and return policy. 9.2 CONTACT INFORMATION ALTINEX, INC 592 Apollo street Brea, CA 92821 USA TEL: 714 990-2300 TOLL FREE: 1-800-ALTINEX WEB: www.altinex.com E-MAIL: solutions@altinex.com website MULTI-TASKER...
