Read First Warning & Cautions Beforeusingthecamera,pleasemakesurethatyoureadandunderstand allthefollowingsafetyprecautions. A lwaysensurethatthecamerais operatedcorrectly.Thesafetyprecautionswillinstructyouinthesafeand correctoperationofthecameraanditsaccessories,preventinginjuryor damagetoyourself,otherpersonsandequipment. Inthefollowingpages,theterm“equipment”refersmainlytothecamera anditspowersupplyaccessories. *Microsoft,WindowsandWindowslogoareregisteredtrademarksof MicrosoftCorporationincorporatedintheUnitedStatesand/orother countries. * A llbrandandproductnamesappearinginthismanualareregistered trademarksoftheirrespectivecompanies. WARNING Topreventpossibleinjury,pleaseobservethefollowingwarningswhen usingthisproduct. •Do not use the flash too close to eyes Using the flash too close to your subject’s eyes can damage the eyesight.Especially,remainatleastonemeter(39inches)awayfrom infants when you use the flash. •Do not place camera strap around neck Thestrapcouldcausesuffocationwhenaccidentallywoundaround neck.
Page 4
Read First •Turn off immediately when malfunction occurs Ifyounoticeunusualsmellorsmokecomingfromtheequipment, pleaseunplugthe A Cadapterandremovethebatteryimmediately. Proceed swiftly but with caution to avoid being burnt. Take the equipment to an authorized service center for inspection. •Unplug the adapter when the camera is not in use Ifyouusetheadapterasthepowersource,unplugtheadapterwhen the camera is not in use to prevent fire and other dangers. Continuous use over a period of time may lead to overheating, deformation and fire. Battery Observethefollowinginstructionswhenhandlingthebatteryusedinthis product.Improperuseofbatterymayleadtoleakageorexplosion. •RechargeonlyLi-ionrechargeablebatteries.Rechargingbatteriesthat arenotrechargeablemayleadtoleakageorexplosion. •Checkbatterypolaritybeforeinserting.Donotattempttoinsertthe batteryupsidedownorbackward. •Donotdisassembleorshortcircuitthebattery. • Do not expose battery to fire or excessive heat. •Donotimmerseorcontactwithwaterorotherliquids. •Stopusingthebatteryimmediatelyifyounoticeanydeformationor changesincolor. •Donotputthebatteriestogetherwithmetalobjectssuchascoins,keys orhairpinsinyourpocket.
Page 5
CAUTIONS Observeandexercisethefollowingcautionstoavoiddamageandkeep yourcamerainanoptimumworkingstatus. •Keep Dry Thiscameraisnotwaterproof,andmaymalfunctionifimmersedin water,oranyliquidsentertheinteriorofthecamera. •Keep away from Moisture, Salt or Dust Wipeoffsaltordustwithaslightlydampenedsoftclothafterusing yourcameraatthebeachorseaside,then,dryyourcamerathoroughly. •Keep away from Strong Magnetic Fields Neverputthecameratooclosetoanyequipmentproducingstrong electromagnetic fields, such as electric motor. Strong electromagnetic fields could lead to camera malfunctions or interfere with the data recording. •Avoid Intense Heat Donotuseorstoretheequipmentundersunlightorhightemperatures. Suchexposurecouldleadtotheleakageofthebatteriesordeformation ofthecasing. •Avoid rapid temperature changes Rapidlymovingtheequipmentbetweenhotandcoldtemperatures maycausewaterdropletstoformonitsexteriorandinterior.To preventcondensation,placetheequipmentinitscarrycaseora...
Read First •Handle the lens and all parts with care Donottouchthelensorlensbarrel.Becarefulinhandlingthememory cardandbattery.Thesepartsarenotdesignedtowithstandforce greaterthanregularuse. •Do not unplug or remove the battery when processing data Whenimagedataisbeingrecordedordeletedfrommemorycards, cuttingoffpowercouldresultindatalossordamagetheinternal circuitryormemory. •Do not drop Strongshockorvibrationofdroppingcouldcausemalfunction.Keep thestraparoundyourwristwhencarryingthecamera. •Memory cards Turnoffthepowerbeforeinsertingorremovingthememorycard. Otherwise,thememorycardcouldbecomeunstable. Memorycardsmaygethotduringuse,soremovememorycardfrom thecamerawithcare.
Chapter 1: Getting Started Set Up Attaching the Wrist Strap Insertthesmallloopofthewriststrapinto thestrapeyelet.Insertthelongloopofthe wriststrapintothesmallloopofthestrap andthentightenit. Charging the Battery ThesuppliedrechargeableLi-ionbatterypackshouldbechargedbefore use. Makesurethatthecameraisturned off. Plug the AC adapter connecter intothe“DCIN5V”socketonthe camera. Plug the adapter into the main power outlet. The Power Access LED goes off when chargingiscompleted.Disconnectthe ACadapterafterchargingandremove thecamera.
Inserting the Battery and Memory Card Openthebattery/memorycardcover. Insert the battery. Please check whetherthebatteryisinsertedwiththe correctpolarity(+/-). Note: Risk of explosion if battery is replaced by an incorrect type. Dispose of used batteries according to the instructions. InsertaSDmemorycardintothe memorycardslotasshown. Note 1: The write protect switch of the memory card prevents files from being deleted or formatted.
Chapter 1: Getting Started Turning On for the First Time Thelanguageselectionscreenappears.Selectthelanguageyouwant fromthelist. Press / buttontoselectthelanguage you need. Press the OK button to confirm allsettings. Note: To change the language after you have performed configuration for the first time, refer to “Setting Language” on page 60. TheDate/Timesetupscreenwillappearautomaticallyafteryouhave selectedalanguage.Setthedateandtimesotheyappearcorrectlywhen reviewingimagesstoredonyourcamera. / Press button to select each field. Press / buttontomakeadjustments to each field. Press the OK button to confirm all settings. Note: To change the date and time after you have performed configuration for the first time, refer to “Setting Date and Time” on page 60.
Chapter 2: Taking Images and Recording Video Clips Using the LCD Monitor Whenyouturnonthecamera,theLCDmonitorturnsonautomatically. WiththeLCDmonitoryoucanframetheimagesorvideoclipsyouwantto captureandrecord. ThefollowingillustrationshowstheLCDmonitorlayoutanddescriptions ofallicons. Note 1: You may not be able to see the LCD monitor clearly when using the LCD monitor under intense light, such as sunlight. You can adjust the LCD brightness to improve visibility. See page 65. Note 2: Note that the following are for illustrative purposes only. They may not exactly match the LCD monitor content actually displayed on the camera.
Chapter 2: Taking Images and Recording Video Clips Capture Mode A uto 80 100 00 400 800 1000 Flashmode WhiteBalance A utoflash A uto Fillinflash Daylight Flashoff Fluorescent FlashwithRed-eyereduction Tungsten SlowSync.(Onlyinnightscenemode) Cloudy Remaining number of Pictures Quality SDCard Normal /Internalmemory Fine CaptureMode...
Chapter 2: Taking Images and Recording Video Clips Changing Mode YoucanchangethecontentsontheLCDmonitorbypressingthe buttontocyclethroughtheavailableoptions. •Capture Mode On(Default) OSDOn+Histogram OSDOff * OSD stands for ‘on screen display’. *Histogram:Thehistogramisagraphtojudgethetonalrangeofthe image.Thecorrectexposureoftheimageisthepeakofthegraphinthe middle.Iftheimageistoodark,thepeakslantstotheleft.Iftheimageis toobright,thepeakslantstotheright.Youcanadjusttheexposurebyus- ingEV(ExposureCompensation). •Video Mode OSDOn(Default) OSDOff Note: If you do not use the camera over 1 minute, the LCD monitor will turn off automatically. Press any button but power button to turn on the LCD monitor.
Using Zoom This camera features 3x optical zoom and 8x digital zoom. Optical Zoom Press the W/T button to zoom in and outofanimage. The zoom indicator appears on the LCDmonitor. OpticalZoom Digital Zoom To use the digital zoom, you must activate it through the settings menu. Seepage61forinstructionsonhowtodothis. Press the T button to optically zoom in to the maximum magnification. Releasethebuttonandpressitagain to activate the digital zoom function. Aframesurroundstheareaofthe imagetobecaptured.Therestofthe LCDmonitorisdulledout. DigitalZoom Note: When recording video clips, you can only change the optical zoom setting.
Chapter 2: Taking Images and Recording Video Clips Taking Pictures Using Auto Focus The A utoFocusfunctionmakestakingstillphotosastraightforward process.Bypressingtheshutterreleasebuttondownhalfway,the camerawillfocusonyoursubjectautomaticallyandcalculateallphoto settings,suchasexposureandsaturation.Youcanchangethe A uto FocusareatoMulti,CenterorFacedetectionbyusingthe A utoFocus function.Forinformationabout A utoFocus,see"Settingfocus"onpage FrameyoursubjectwiththeLCDmonitor. Press the shutter release button halfway down and hold it to set the focusandexposure. Whentheautofocusisset,youwillhearabeepandthe A FLEDwill lightup. Press the shutter release button down fully to take the image.
Using Focus Lock Whentakingaphotowhereyoursubjectisoff-center,thecamerawillfo- cusonthecentralarea,resultinginyoursubjectbeingoutoffocus.Focus Lockallowsyoutofocusonanoff-centersubject. Frameyoursubjectinthecenterofthe frame with the LCD monitor. Press the shutterreleasebuttonhalfwaydown andholdittosetthefocusand exposure. Keeptheshutterreleasebutton pressedandrecomposeyourpicture, withyoursubjectpositionedoff-center. Press the shutter release button down fullytotakethepicture. Note: The color of the focus bracket indicates whether the camera has focused successfully or not.
Chapter 2: Taking Images and Recording Video Clips Macro Mode ( ) Press the button to select “Macro” or “Infinity” function. To shoot a close-upimage,use “Macro”functiontogetthedetailandsharpnessof the subject by fixed focus. To shoot infinity shots, use “Infinity” function to shoot landscapes and distantobjects.Itcanalsobeusedforcompositionscombiningbothnear anddistantobjects. Using Self-timer ( ) Self-timerfunctionallowsyoutotakepicturessec,5secor10seclater afteryoupresstheshutterreleasebuttondownfully.Ifyouwanttotake yourselfintotheimage,youcanusethisfunction.Werecommendyouusea tripodorplacethecameraonasteadysurfacewhenusingself-timer. Press buttonuntiltheicon , or appearsontheLCD monitor. Afterlockingthefocusandpressingtheshutterreleasebutton downfully,theself-timerlampblinks.Thecamerawilltakethe imageautomaticallyafterthetimeyousetends.
Setting EV (Exposure Value) In some difficult lighting condition, the automatic exposure may be misledintogivingthewrongreadings.Exposurecompensationallowsyou toadjusttheexposurevalueandcorrectlyexposeyourimages. InCapturemode,press button(EVvaluewillbeselectedandlight red). / Use buttontoadjusttheexposurevalue(from-.0~+.0). Press OK button to confirm the setting. Setting Flash ( ) When taking pictures in difficult lighting conditions, you may need the flash to get correct exposure. The camera provides you with built-in flash modes. Mode Function Flash fires automatically when the lighting AutoFlash conditionisdark. Flash fires whenever you take a shot, regardless FillinFlash ofthelightingcondition. Flashisturnedoff. FlashOff Reducesthe“red-eye”effectresultingfromthe AutoFlashwith flash. Red-eyeReduction Flash fires with slow shutter speed to get SlowSync naturalexposure.
Chapter 2: Taking Images and Recording Video Clips Mode Options There are six scene mode options (Auto, Video, Portrait, Landscape, Night sceneandSportsmodes)ofthiscamera. In Capture live view, press the SP/ / buttontomodeoptionanduse buttontoselectthemode. Press the OK button to confirm all settings. •Auto Mode Thesimplestwaytoshootbasicimages. •Video Mode Togetthevideoclips. •Portrait Youcantakeanaturalpersonimage. •Landscape Totakethedistantoroutdoorscenes. •Night Scene Thecamerawilldecreasetheshutterspeedwhentakingimagesinthe darkconditions(i.e.atnight).Werecommendusingatripod.
Recording Video Clips Press the SP/ buttonandselect Videomode. Zoominoroutonyoursubjectsby pressingtheW/Tbuttonbeforeyou startrecording. Press the shutter release button halfway downandholdittosetthefocusand exposure. Press the shutter release button down fullytostartrecording. Press the shutter release button again tostoprecording.
Chapter 2: Taking Images and Recording Video Clips Using the Capture/Video Menu Youcanadjustimageandvideosettingsthroughthecapturemenu. Press the / buttontoselect Capture mode or press SP/ buttonto selectVideomode. Press the buttontoenterthecapture orvideomenu. Scrollthroughthemenubypressing / buttonandhighlighttheoption you wish to select. Press the OK button to confirm all settings. Press the buttonorshutterrelease buttonhalfwaydowntoreturntothe CaptureorVideomodeliveview.
Setting Image Size (Resolution) Changing the image size affects the number of images that can be stored onyourmemorycard.Youcancapturemoredetailedimageswithhigher resolutions.Thehighertheresolution,themorememoryspacewillbe required. •Setting Size (for Still Images) InCapturemenu,select“SIZE”. Select“396x47(8M)”, “816x11(6M)”,“560x190(5M)”, “7x1704(4M)”,“048x1536(3M)”, or“640x480(VGA)”. Press OK button to confirm the setting. •Setting Size (for Video Clips) InVideomenu,select“SIZE” Select“640x480”or“30x40”.
Setting White Balance Youcanselecttheappropriatesettingdependingonthelighting conditionofyoursurroundings.WhiteBalancewilladjustcolorlevelsthat areaffectedbytheselightingconditions. InCapture/Videomenu,selectWHITE BALANCE”. Select“CLOUDY”,“TUNGSTEN”, “FLUORESCENT”,“DAYLIGHT”,or “AUTO”. Press OK button to confirm the setting. Setting Function Settingforshootinginovercastcondition. CLOUDY Settingforshootinginincandescentorhalogen TUNGSTEN condition. FLUORESCENT Setting for shooting in fluorescent condition. Settingforshootinginsunnycondition. DAYLIGHT Thecamerawillautomaticallyadjustsettings AUTO dependingontheleveloflightavailable.
Chapter 2: Taking Images and Recording Video Clips Setting ISO (Sensitivity) AdjusttheISOvaluedependingonthelightinglevelsofyour surroundings;useahighISOsettingindimconditionsandalowerISO settinginbrighterconditions. InCapturemenu,select“ISO”. Select“1000”,“800”,“400”,“00”,“100” ,“80”or“AUTO”. Press OK button to confirm the setting. Setting Focus The A Fframehelpsyoutogettheareaonwhichthecamerafocuses. InCapturemenu,select“FOCUS”. Select“MULTI A F”,“CENTER A F”or “FACEDETECTION”. FACEDETECTION Press OK button to confirm the setting.
Setting Function MULTI A F Thecamerawillseetheshootingconditionsand selectamongtheninefocusframestofocuson. CENTER A F The c amera u ses t he c enter f ocus f rame t o f ocus o n. FACEDETECTION Thecamerawilldetectandfocusonfaces automatically. Note 1: If no face is detected, the Focus mode will automatically set to Multi AF. Note 2: You can use the FACE DETECTION function to take pictures of yourself. If the AF LED lights up a solid red, your face is in focus, if the AF LED flashes red, your face is out of the focus.
Chapter 2: Taking Images and Recording Video Clips Setting Exposure Area Thecamerawillmeasurethebrightnessoftheselectedareainorderto determinetheexposurelevel. In Capture menu, select “EXPOSURE AREA”. Select “FULL” , “CENTRAL”or “SPOT”. Press OK button to confirm the setting. Setting Function FULL Measuresbrightnesslevelfromtheentire captureinordertodetermineexposurelevel. CENTRAL Measuresbrightnesslevelfromthecentralarea ofthecaptureinordertodetermineexposure level. SPOT Meterstheexposurevaluefromaverysmall areainthecenterofscreenonly.Usethismode to shoot pictures with a specific exposure area.
Color Style Adjust the color style to change the color of the final image. InCapture/Videomenu,select “COLORSTYLE”. Select “B&W”, “SEPIA” or “NORMAL”. Press OK button to confirm the setting. Setting Function B&W Takesthephotoinblackandwhite. SEPIA Takesthephotoinsepia(avintageeffect). NORMAL Takesthephotowithoutanyspecialeffects.
Chapter 2: Taking Images and Recording Video Clips Setting Sharpness Adjust the sharpness settings to emphasize or soften the overall appear- anceoftheimage. InCapture/Videomenu,select “SHARPNESS”. Select“HARD”,“NORMAL”or“SOFT”. Press OK button to confirm the setting. Setting Function HARD Emphasizes all subjects in the image. Outlines and edges are emphasized and stand out. NORMAL Theimageiscapturedwithoutanyadjustments tosharpnesslevels. SOFT Softensallsubjectsintheimage.Outlinesand edgesaresoftened.
Setting Contrast AdjusttheContrastsettingtoalterthedistinctionbetweenlightanddarkin the image; the result is a harder or softer appearance of the final image. InCapture/Videomenu,select “CONTRAST”. Select“HARD”,“NORMAL”or“SOFT”. Press OK button to confirm the setting. Setting Function HARD The image is hardened, by defining light and darkareasmoreclearly. NORMAL Theimageiscapturedwithoutanyadjustments tocontrastlevels. SOFT The image is softened, by defining light and dark areaslessclearly.
Chapter 2: Taking Images and Recording Video Clips Setting Saturation AdjusttheSaturationsettingtoaltertheintensityandpurityofthecolor. Thehigherthesaturationsetting,themorevividtheimageis. InCapture/Videomenu,select “SATURATION”. Select“MORE”,“NORMAL”or“LESS”. Press OK button to confirm the setting. Setting Function MORE Makesimageslookmorevivid. NORMAL Theimageiscapturedwithoutanyadjustments tosaturationlevels. LESS Makesimageslookduller.
Setting Drive Mode WhenyouselectDRIVEMODEinthecapturemenu,youcanchoosefrom threeshootingmodes:Single,ContinuousandBurstmodes. InCapturemenu,select“DRIVE MODE”. Select“SINGLE”,“CONTINUOUS”or “BURST”. Press OK button to confirm the setting. Note 1: The flash mode and self-timer is “Off” when using “CONTINUOUS” and “BURST”. Note 2: The CONTINUOUS mode will stopped when the SD card or the internal memory is full. A “CARD FULL” warning appears on the LCD . Setting Function SINGLE Takes a single image. Press the shutter release buttononcetocapturetheimage. Takesaseriesofimageswhenyoupressdown andholdtheshutterreleasebutton.Thecamera CONTINUOUS willcontinuetotakeimagesuntilyoureleasethe shutterreleasebutton.Whenselected,theicon appearsontheLCDmonitor. Takes5imageswhenyoupressdownthe BURST shutterreleasebuttononce.Whenselected,the icon appearsontheLCDmonitor.
Chapter 2: Taking Images and Recording Video Clips Setting Photo Frame You can add frames to your photos by using Photo Frame. In Capture menu, select “PHOTO FRAME”. Select “OFF”, “P1”, “P2”, “P3”, “P4”, “P5”, “P6”, “P7”, “P8” or “P9”. Press OK button to confirm the setting and take your picture with the Photo Frame. Note 1: The digital zoom cannot be used when using “Photo Frame”. Note 2: When using “Photo Frame”, Continuous and Burst cannot be used.
Chapter 3: Reviewing Images and Video Clips Using the LCD Monitor ThefollowingillustrationoutlinesthelayoutandiconsontheLCD monitorinplaybackmode. Playback Mode •Capture Flashmode A utoflash Quality Fillinflash Normal Flashoff Fine FlashwithRed-eyereduction Best SlowSync.(Onlyinnightscenemode) WhiteBalance A uto A uto Daylight 100 Fluorescent 00 Tungsten 400 Cloudy ...
Page 40
Chapter 3: Reviewing Images and Video Clips OSDOn(Default) OSDOn+Histogram OSDOff •Video Playback Mode Protection status Movieclip Image size Recorded File size date/time Recordingtime Filename Displayedimagenumber/ Totalnumberofimages Play/pause indicator OSDOn(Default) OSDOn+DetaiedInformation OSDOff...
Using Playback Playback mode allows you to review still images and video clips stored on yourcamera. Press the / buttontoselect Playback mode. The last taken image or the first frame of the videos appears ontheLCDmonitor. / Press buttontothepreviousor next file. Ifyouselectavideoclip,anoperation guideappearsontheLCDmonitor. Press buttontoplaythevideoclip. Press buttonagaintopause. Press OK button to stop playing.
Chapter 3: Reviewing Images and Video Clips Using the Playback Menu Press the / buttontoselect Playback mode. Press the buttonto enter the Playback menu. Scrollthroughthemenubypressing / buttonandpress / buttonto highlighttheoptionyouwant. Press the OK button to confirm all settings. Press the buttontoexit.
Activating Digital Enlargement Youcanmagnifyimageswhenreviewingimagesinplaybackmode. Whenreviewingtheimage,pressT buttontomagnify.Theiconsonthe LCDmonitorwilldisappearandthe approximatelocationoftheareaand magnification level will show. / Use / buttontomovearound theimage. Press the W button to decrease the magnification level. Press OK button to cancel the magnification. Note: The video clips cannot be magnified. When reviewing the video clip, a “CANNOT MAGNIFY” warning appears on the LCD monitor.
Chapter 3: Reviewing Images and Video Clips Using Index Display Indexdisplayallowsyoutoviewuptonineimagesatatime. Whenreviewingtheimage,pressW buttontoshowtheindex.Uptonine imagescanbeviewedatthesame time. / Use / buttontochangethe imageselection. Press the T button to return to single imageplayback.
Deleting Images and Video Clips Thisfunctionallowsyoutodeleteyourimagesandvideoclips. In Playback menu, select “DELETE”. Select“ALL”todeleteallimagesand videoclipsorselect“ONE”todelete the displayed one. Press the OK button. A confirmation dialogue will appear. Select“OK”andpressOKbuttonto deleteimagesorvideoclips. Select“SELECT”andathumbnail / image gallery appears. Press / buttontoselecttheimageyouwantto delete. Press the OK button. A confirmation dialogue appears, prompting“DELETESELECTED IMAGES?”.SelectOKandpressthe OKbuttontodeletetheselectedimage.
Chapter 3: Reviewing Images and Video Clips Protecting Images and Video Clips This function prevents images and video clips from being modified or deletedaccidentally. In Playback menu, select “PROTECT”. Select“ONE”toprotecttheselected oneorselect“ALL”toprotectall images or video clips. Press the OK button. A protected file is indicated by the mark. Followstep1andagainandthen pressOKbuttontoremovethe protection. Select“SELECT”andathumbnail / image gallery appears. Press /...
Adding Voice Memo to a Still Image Youcanaddavoicememouptoaround30secondsinlengthforeach stillimage. In Playback menu, select “MEMO”. Torecordavoicememo,select “RECORD”andthenpressOKbutton. Press buttontostartrecording. Whenthevoicememorecordingstarts, theindicatoriconontheLCDmonitor changes from (green) to (red). Press buttonagaintostoprecordingand returntothepreviousmenu. To play a voice memo, select “PLAY” and then press OK button. Press button to start playing. Press button againtostopplayingandreturn t othe...
Page 48
Chapter 3: Reviewing Images and Video Clips Todeleteavoicememo,select “DELETE”andthenpressOKbutton. A confirmation dialogue will appear. Select“OK”andpressOKbuttonto deletememo.
Setting DPOF Thisfunctionhelpsyoutoprintoutyourimagesataprofessionalprintser- vice or on a DPOF (Digital Print Order Format) compatible printer directly. In Playback menu, select “DPOF”. Todecidewhichimagesaretobe printedandthenumberofcopies, select“STANDARD”andthenpressOK buttontoenterthesubmenu. Inthesubmenu,select“STANDARD” andthenpressOKbuttontostart setting. / Use buttontoselecttheimageyou want t oprintanduse / buttonto specifythenumberofcopies. A fterall thesettingsareselected,press ...
Page 50
Chapter 3: Reviewing Images and Video Clips Tocancelthesettingof“STANDARD”, select “REMOVE” and a confirmation dialoguewillappear.Select“OK”and thenpressOKbuttontoremoveprint settings. Toprintindexofimages,select“INDEX” / andpressOKbutton.Use button to select “ADD” or “REMOVE”. Press OK button to complete DPOF setting. Note: A still image that has DPOF settings is indicated by the mark.
Setting DPOF Thisfunctionhelpsyoutoprintoutyourimagesataprofessionalprintser- vice or on a DPOF (Digital Print Order Format) compatible printer directly. In Playback menu, select “SLIDE SHOW”. Use / buttontoselect“INTERVAL” / anduse buttontoselectthe intervalsetting(1~10sec). / Select “REPEAT” and use button to activate “REPEAT” function (“ON” or “OFF”). Press OK button to confirm the setting and start playing a slide show. Press buttontostopplayingorpress buttontoreturntothepreviousmenu.
Chapter 3: Reviewing Images and Video Clips Rotating the Still Images Thisfunctionallowsyoutorotatestillimages. In Playback menu, select “ROTATE”. Press Left or Right button to rotate 90° clockwise or counterclockwise. Press OKbuttonandreturntotheprevious menu.
•Windows 98SE, ME, 2000, XP, and Vista •Pentium II processor or more •Minimum 64MB RAM •200MB of available hard disk space •1024x768 pixels, 16-bit color monitor Installing the Software Installing the Driver IfyouuseWindows98SEastheOSinyourcomputer,besuretoinstall the driver first before connecting the camera to the PC. AfteryouinserttheCDintotheCD-ROM drive,thepop-upimagewillappear. Iftheimagedoesnotappear,click“Start” andthen“Run”.Type“E:\Rollei.exe” Note: Windows ME, 2000, XP, Vista don’t need the driver installed.
Chapter 4: Installing the Software Installing the Application AfteryouinserttheCDintotheCD- ROMdrive,thepop-upimagewill appear.Iftheimagedoesnotappear, click“Start”andthen“Run”.Type “E:\Rollei.exe”. Click “PhotoImpression”. The computer proceeds to install PhotoImpression. Selectalanguageandclick“OK”. Followtheon-screeninstructionto continuetheinstallation. Note : Follow steps as PhotoImpression to install “VideoImpression” and “Media Player 9” .
Using the Application PhotoImpression Connectthecameratothecomputer. See page 57. Launch PhotoImpression. Todownloadtheimagesfromthe camera,select“RemovableMedia”. Press “OK” and PhotoImpression will detectnewphotostoyourcomputer. Press “OK” and the selected photos will becopiedtoyourcomputer. Jobcompletedandpress“OK”.
Page 56
Chapter 4: Installing the Software VideoImpression We recommend you to install Windows Media Player 9 or later when you play back the video clip on the computer. If you use Windows XP, you also have to upgrade to Windows XP Service Pack 2(SP2). If you use Win- dows Vista, you might need MPEG4 codec. LaunchVideoImpressionandthen select“add”. Select“DCIM”todownloadthevideo clipsfromthecamera. Double-clicktoselectthevideoclips. Click “Play” to play the video clips.
Chapter 5: Uploading, Printing & Displaying Images Afteryoutakeimages,youcanuploadimagestoacomputerfromyour camera,printthemwithaprinter,anddisplaythemonaTV. Uploading to a Computer ConnectthelargerendoftheUSB cabletotheUSBslotonyour computer. A ndconnectthesmallerend oftheUSBcabletotheUSBconnector onthecamera. Thecomputerautomaticallydetectsthe cameraasamassstoragedeviceso you can copy image files from your camera to your computer’s hard drive.
Chapter 5: Uploading, Printing & Displaying Images Printing Images Therearethreeprintingmethodsyoucanusetoprintoutselected images. This camera supports direct printing, Digital Print Order Format (DPOF), and PictBridge. Direct printing allows you to print out images by connecting the camera directly to some specific printers to print your favorite images. Both DPOF and PictBridge printing function need a printerthatsupportsthesefunctions. •Printing with DPOF and PictBridge compatible printers The camera’s DPOF feature allows you to specify which images you wanttoprintandhowmanycopiesofeachyouwant. A fteryouspecify yourprintingpreferenceonthecamera,thenyoucanremovethe memorycardfromthecameraandplugintoaprinterthatsupports DPOF, or connect the camera through the USB cable to a PictBridge compatible printer for printing. See page 49 for DPOF settings and page 68 for PictBridge settings. •Printing with a Computer AfteruploadingtheimagestoacomputerbytheUSBcable,youcan printimagesbyusingthesoftwaresuppliedwiththecamera.Seepage 53onhowtoInstallthesoftware.
Displaying Images on a TV ByconnectingyourcameratoaTV,youcanviewimagesasaslideshow andplayvideoclips. SelectacompatibleTVsystemin “SETUP” menu. Connectthe A /V(Audio/Video)cable tothe A /VinputsoftheTV,andconnect the A /Vcabletothe A /Vconnectorof thecamera. Note 1: When you connect your camera to a TV, the LCD monitor turns off automatically.
Chapter 6: Adjusting the Camera Settings Using the Setup Menu / In Capture, Video or Playback menu, use buttontoselect “Setup”andpressOKbuttontoenterthemenu. / Scrollthroughthemenubyusing buttonanduse / buttonto highlighttheoptionyouwanttoselect. Setting Language Thisfunctionallowsyoutochangethelanguage. InSetupmenu,select“LANGUAGE”. Selectthelanguageyouwantfromthe list and press OK button to confirm the setting. Setting Date/Time Thisfunctionallowsyoutochangethedateandtime.
Setting Digital Zoom This function allows you to activate digital zoom function. DIGITAL Z OOM InSetupmenu,select“DIGITAL ZOOM”. Select “ON” or “OFF”. Press OK button to confirm the setting. Setting AF Illuminator Thisfunctionallowsyoutoturnonoroffthe A Filluminatoratthefrontof thecamera.Turnonthisfunctiontoaidfocusinginlow-lightsituations. Turnoffthisfunctionifyouarecapturinganimage,whichmaybe distractedbytheilluminator(wildlife,forexample). InSetupmenu,select“AF ILLUMINATOR”. Select “AUTO” or “OFF”. Press OK button to confirm the setting.
Chapter 6: Adjusting the Camera Settings Setting Instant Review Thisfunctionallowsyoutoreviewtheimagefor3secondsaftertakinga image. InSetupmenu,select“INSTANT REVIEW”. Select “ON” or “OFF”. Press OK button to confirm the setting. Moving Images to Card Thisfunctionallowsyoutomoveimagesstoredontheinternalmemoryto yourmemorycard. InSetupmenu,select“MOVEIMAGES TOCARD”andthenpressOKbutton. A confirmation dialogue will appear. Select“OK”andpressOKbuttonto moveimagestocard. Note: If the camera does not respond when you select the “Move Images to Card” function, either the memory...
Resetting the File Number This function allows you to reset the file numbers assigned to each image or file. InSetupmenu,select“FILENO. RESET”andthenpressOKbutton. A confirmation dialogue will appear. Select“OK”andpressOKbuttonto reset. Imprinting the Date and Time Whenprintingoutordisplayingimages,youcandecidewhethertoimprint thedateandtimeontheimagesornot. InSetupmenu,select“DATE IMPRINT”. Select “DATE & TIME”, “DATE” or “OFF”. Press OK button to confirm the setting.
Chapter 6: Adjusting the Camera Settings Setting Function DATE & TIME Theimageisprintedwiththedateandtimeit wastaken. DATE Theimageisprintedwiththedateitwastaken. Theimageisprintedwithoutthedateortime. Formatting the Memory Thisfunctionallowsyoutodeletealloftheimages,data,information,and foldersinyourmemorycardorinternalmemory. InSetupmenu,select“FORMAT”and thenpressOKbutton. A confirmation dialogue will appear. Select“OK”andpressOKbuttonto format. Note: If a memory card is inserted, a “FORMAT CARD?” prompt appears.
Setting LCD Brightness ThisfunctionallowsyoutoadjustthebrightnessoftheLCDmonitor. InSetupmenu,select“LCD BRIGHTNESS”. Use buttontoadjustthebrightness value. Press OK button to confirm the setting. Note: This setting is disabled when viewing images or videos through your TV. Setting Camera Sound Youcanadjustthecamerasoundeffectbysettingcamerasound. InSetupmenu,select“SOUND”. Select“SHUTTERONLY”,“ON”,or “OFF”. Press OK button to confirm the setting.
Chapter 6: Adjusting the Camera Settings Setting Function SHUTTERONLY Allsoundisoffapartfromashuttersoundwhen animageistaken. Allcamerasoundsareturnedon. Allcamerasoundsareturnedoff. Setting Camera Volume Thisfunctionallowsyoutoadjustthevolume. InSetupmenu,select“VOLUME”. Use / buttontoincreaseor decrease the volume. Press the OK button to confirm all settings. Setting TV System Both NTSC and PAL are TV broadcast systems. The NTSC system is used mainly in the USA, Japan, Canada, Mexico, the Philippines, Korea and Taiwan. The PAL system is used in western European countries such as Germany, the UK, Switzerland, Holland, Italy (except for France) and Australia,Singapore,ThailandandChina. A sthesesystemsarenotcom- patible,youcannotwatchanNTSCsystembasedTVinanareawhere the PAL system is used. InSetupmenu,select“VIDEOOUT”. Select “NTSC” or “PAL”. Press the OK button to confirm all settings.
Setting Auto Power Off Tosavebatterypower,youcansetthecameratoturnoffautomatically when it is not in use for a fixed time. In Setup menu, select “AUTO POWER OFF”. Select“10MIN”,“5MIN”,“3MIN”,“1 MIN” or “OFF”. Press the OK button to confirm all settings. Changing USB Mode YoucanchangetheUSBconnectionmodedependingonwhetherthe cameraistobeconnectedtoacomputer(STORAGE)oraprinter (PICTBRIDGE). InSetupmenu,select“USB”. Select “STORAGE” or “PICTBRIDGE”. Press the OK button to confirm all settings.
Chapter 6: Adjusting the Camera Settings Using PictBridge You can connect the camera directly to a printer that supports PictBridge, andperformimageselectionandprintingusingthecameramonitorscreen andcontrols. PictBridge is a standard established by the Camera and Imaging Products Association (CIPA). In “SETUP” menu, change the USB connection mode to “PICTBRIDGE”. UsetheUSBcablethatcomeswiththe packagetoconnectthecameratoa PictBridge compatible printer. Once connected, the PictBridge menu / appears. Press buttontochoose theoptionyouwantandpresstheOK button to confirm. / Ifyouchoose“SELECT”,press to selecttheimagesyouwanttoprint. Press / tospecifythenumberof copies. Press the OK button to confirm...
Page 69
Thetotalnumberofimagesyouhave selectedandthenumberofcopiesthat youhavesetappearonthescreen. Press the OK button to print or the button to return to the PictBridge menu. Select“ALL”toprintallimagesand presstheOKbutton. Thetotalnumberofimagesappearson the screen. Press the OK button to print orthe buttontoreturntothe PictBridge menu. Press the OK button to stop when the printerisstarttoprinttheimages.
Chapter 6: Adjusting the Camera Settings Resetting Your Camera Thisfunctionallowsyoutoresetallcamerasettingstodefault. InSetupmenu,select“RESET”and presstheOKbutton. A confirmation dialogue appears. Select OK to reset your camera. Press theOKbuttontoresetallsettings.
Trouble Shooting Problem Possible Cause Solution Thecameradoes Thepowerisoff. Press the power button to notwork. turniton. Thebatteryisinserted Reloadthebattery incorrectly. correctly. Thebatterypoweris Replacebatterywithanew lowordrained. oneorchargethe battery. See Page 12. Theimagecan Thecameraisnotin Press the mode switch to notbetaken capturemode. capturemode. whenIpressthe Youdidnotpressthe Press the shutter release shutterrelease shutterreleasebutton buttondownfully. button. downenough. Thememorycardis Replacewithanother full. memorycard,uploadthe imagestoacomputeror deletetheimages. Thecameraisstill Waituntilimagestoringof savingthelastimage...
Page 72
Trouble Shooting Problem Possible Cause Solution Theimagesare Thecameraismoving Holdthecamerasteadyor blurry. whenyoupressthe useatripodwhentaking shutterreleasebutton. images. Thefocusbracketsare Position the focus brackets notpositionedonthe onyoursubject. subject. Usemacromodeto Setthecameratoshoot shootsubjectswithin innormalfocusormacro normalfocus,orvice focusandthentakethe versa. imageagain. Thelightisdimand Useatripodandturnon the flash is off. the flash. Thelensisdirty. Gentlycleanthelens. Theimagesare The flash is on when Turn off the flash. toobright. thesubjectisbright enough. Thecameraistooclose Movebackfromthesubject tothesubjectwhen andtaketheimageagain.
Specifications Storage •Internalmemory A bout3MB • External memory SD card (Max. card size : 2GB) • File format Still image : JPEG (DCF), Exif 2.2, DPOF 1.1, PictBridge Video clip : ASF (MPEG-4) ; Audio : WAV • Image Size 3296x2472 [8M], 2816x2112 [6M], 2560x1920 [5M], 2272x1704 [4M], 2048x1536 [3M], 640x480 [VGA] I/O External •DCinput DC5Vadapter(regularplug) • Video output NTSC and PAL(selectable) • PC connection Mini-plug type USB, mini USB connector for serial cable Power Source • Rechargeable Li-ion battery (NP60) • A dapter(DC5volt) Dimensions • Size (WxHxD) 93.0mm x 58.0mm x 24.2mm System Requirements: Windows • CPU Pentium II or more •Memory Atleast3MB • OS Windows 98SE/ME/2000/XP/Vista •Interface USB1.0/1.1/.0...
