Woodstock SHOP FOX D4088 Instruction Sheet

Model D4088 Drill Press
Lathe Attachment
Instruction Sheet
Phone #: (360) 734-3482 • Online Tech Support: tech-support@shopfox.biz • Web: www.shopfox.biz
Introduction
The Model D4088 Drill Press Lathe Attachment allows
wooden workpieces to be turned on a drill press in the
same manner as a wood lathe. Items like small pickets,
legs, spindles, handles, dowels, and pins can be made.
Fits drill press tables with T-nut slots or with slotted
through holes as shown in Figure 1.

Specifications

Tool Rest Length ............................................. 12"
Maximum Workpiece Length (if reversed) ............... 24"
Maximum Workpiece Diameter ..............................6"
Shank Diameter of Screw and Spur Center ..............
Construction Material .....................................Steel
Shipping Weight .........................................3.5 lbs.
Inventory
Refer to the list and Figure 2 to inventory your package.
If you can't find an item on this list, check the mounting
locations or examine the packaging materials carefully.
Occasionally we pre-install certain components for
shipping purposes.
If any nonproprietary parts are missing (e.g. a nut or a
washer), we will gladly replace them; or for the sake of
expediency, replacements can be obtained at your local
hardware store.
Description ..................................................
A. Tool Rest ....................................................1
B. Screw Center ...............................................1
C. Spur Center .................................................1
D. Hex Wrenches 5, 6mm ................................1 Ea
E. Cap Screw M6-1 x 20 ......................................1
F. Tool Rest Foot ..............................................1
G. Carriage Bolt M10-1.5 x 40 ...............................2
H. Cap Screw M8-1.25 x 20 ..................................1
I.
Base and Live Center Assembly .........................1
J.
Flat Washer 10mm.........................................2
K. Hex Nut M10-1.5 ...........................................2
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE OR FORM WITHOUT
#13043CR
COPYRIGHT © JULY, 2010 BY WOODSTOCK INTERNATIONAL, INC.
THE WRITTEN APPROVAL OF WOODSTOCK INTERNATIONAL, INC.
⁄ "
3
8
Figure 1. D4088 Drill Press Lathe
