Jenn-Air JS42SEDUDB00 Parts List page 18

FREEZER DOOR PARTS
For Model: JS42SEDUDB00
(Stainless Steel)
Illus. Part
No. No. DESCRIPTION
1 Freezer Door
Panel (Includes
Item #14)
W10157903 Black
2 W10127710 Plate, Door Handle
3 2302879 Hinge, Bottom
4 489282 Screw
5 2266854 Hinge, Top
6 2316804 Spacer−Door,
Top & Bottom
7 2222814 Door Gasket,
Magnetic
8 Handle, Door
12850907 Stainless Steel
9 Spacer, Door−Skin
(Handle Side)
2309060 For Stainless
Steel Model
10 Skin, Door
W10144963 Stainless Steel
11 Screw
8281250 Stainless Steel
12 2005433 Spacer, Door−Skin
(Top)
13 488568 Screw
14 2257385 Spacer, Door−Skin
(Bottom)
15 2005030 Spacer, Door−Skin
(Hinge Side)
16 308544 Screw, Handle
17 Filler, Door
W10159585 Top
W10159582 Bottom
18 2258951 Brace, Door Corner
19 2222776 Bin, Door (3)
20 W10153450 Stud, Mounting
18
W10180976
