READ MANUAL BEFORE OPERATING SYSTEM
Read the owner's manual thoroughly before operating to ensure the most efficient
ATTENTION INSTALLER: Please be sure this manual and warranty information are
left with the power unit or customer when installation is complete.
MODELS: 260, 466Q,
566Q, 760 & 960
512 West Gorgas Street • P.O. Box 3912 • Louisville, OH 44641-3912
1-800-822-8356 • www.vacuflo.com
Dealer Name _____________________________________________
Dealer Phone _____________________________________________
Serial Number ____________________________________________
use of the system.
Operating
Instructions For
VACUFLO
True Cyclonic
®
™
®
®
P/N 9043 • 07/08
Advertisement
Table of Contents
Related Manuals for Vacuflo TRUE CYCLONIC 260
Summary of Contents for Vacuflo TRUE CYCLONIC 260
- Page 1 VACUFLO ® True Cyclonic ® MODELS: 260, 466Q, 566Q, 760 & 960 512 West Gorgas Street • P.O. Box 3912 • Louisville, OH 44641-3912 1-800-822-8356 • www.vacuflo.com Dealer Name _____________________________________________ Dealer Phone _____________________________________________ Serial Number ____________________________________________ P/N 9043 • 07/08...
-
Page 3: Important Safety Instructions
MODELS: 260, 466Q, 566Q, 760 & 960 • VACUFLO True Cyclonic ® ® IMPORTANT SAFETY INSTRUCTIONS Read These Instructions Before Using This Vacuum System When using an electrical appliance, basic precautions should always be followed, including the following: WARNING: To reduce the risk of fire, electric shock or injury: • Unplug and disconnect power before servicing. -
Page 4: Grounding Instructions
MODELS: 260, 466Q, 566Q, 760 & 960 • VACUFLO True Cyclonic ® ® Connect To A Properly Grounded Outlet Only. GROUNDING INSTRUCTIONS This appliance must be grounded. If it should malfunction or break down, grounding provides Grounding Method: 260, 466Q, 566Q a path of least resistance for electric current to reduce the risk of electric shock. This appliance is equipped with a cord having an equipment grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. WARNING Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check with a qualified electrician or service person... -
Page 5: General Information
Caution: Do not allow the motor to remain turned on, unless a hose is connected or an inlet valve is open. If air is not permitted to pass through the fan blades, damage may occur to the motor. Registration To register your VACUFLO system warranty in the United States and Canada, register online at www.cvacregistration.com or fill in and mail the warranty card located with this manual. Proof of Purchase or Registration of the VACUFLO System is required before any warranty work will be performed by an Authorized VACUFLO Dealer. Registration ensures a fast and easy resolution to your warranty requirements. - Page 6 MODELS: 260, 466Q, 566Q, 760 & 960 • VACUFLO True Cyclonic ® ® Emptying the Dirt Canister & Cleaning the Guard Screen The dirt canister – where the vacuumed dirt is deposited – is the removable lower portion of the power unit. The canister needs to be removed and emptied when it is 3/4 full. The Motor Guard Screen should be cleaned each time you empty the dirt canister. The motor guard screen is located directly above the dirt canister inside the power unit. The guard screen is not removable, it is designed to prevent lightweight fibers from entering the motor impeller blades. A buildup of material on the guard screen may result in a loss of vacuum. Illustration #1 Follow these steps (refer to Illustration #1, #2, and #3) Make sure the Power Unit is OFF.
-
Page 7: Troubleshooting The System
Troubleshooting the System Motor Fails to Turn On: • Check the main fuse or circuit breaker at the main power supply panel of your home. Reset breaker or replace fuses if necessary. • Check the Power Unit reset button located above the power cord. Pressing the button should restore operation. • If the circuit protector continues to trip off after a short period of time, the motor brushes may be worn out. Contact the qualified servicing dealer written on the front of this manual or locate an authorized dealer on-line at www.vacuflo.com for service. Loss of Vacuum If the system shows a loss of vacuum power, check the following: • The dirt receptacle and motor guard screen may need cleaned – follow instructions in this guide. • The hose may be clogged – To check if there is an obstruction, unplug the hose and insert an object that is smaller then the diameter of the hose (A butter knife works well). Pass the object completely through the hose, if it stops that will indicate where the obstruction is located. A dry garden hose can be inserted into the hose to help push the obstruction through. • The Dirt Canister may not be properly seated to the gasket – Follow instructions for replacing the dirt canister. • Tube lines may be obstructed – First check the 90 degree elbow located directly behind the inlet valves, if an obstruction occurs it will usually not make it past this elbow. If the obstruction is not visible at the elbow, attempt to purge the tubing at each inlet valve. To do this, connect the hose and use your hand to stop airflow at the end of the hose for a couple seconds, let airflow resume. Repeat if necessary. - Page 8 MODELS: 260, 466Q, 566Q, 760 & 960 • VACUFLO True Cyclonic ® ® IMPORTANTES MESURES DE SECURITÉ Lisez Complètement Le Mode D’emploi Avant D’utiliser Ce Système D’aspirateur. En employant un appareil électrique, des précautions fondamentales devraient toujours être prises, y compris: AVERTISSEMENT Pour réduire les dangers de feu, d’électrocution,...
-
Page 9: Instructions De Mise À La Terre
Ne brancher l’appareil qu’à une prise avec mise à la terre. INSTRUCTIONS DE MISE À LA TERRE Cet appareil doit avoir une mise à la terre. Si une défectuosité ou autre survenait, la mise à METHODE DE MISE Á LA TERRE la terre offre une voie de moindre résistance au 260, 466Q, courant électrique, d’où un risque moins élevé d 566Q électrocution. Cet appareil est équipé d’ un cordon électricque ayant un conducteur et une fiche de mise à la terre. Cette fiche doit être branchée dans une prise appropriée qui a été installée et mise à la terre convenablement en accord avec le code électrique de votre région. AVERTISSEMENT Un branchement incorrect de l’équipement de mise à la terre peut causer un risque d’électrocution. Si Modéle A vous avez un doute concernant la mise à la terre de votre prise, veuillez faire vérifier votre installation par METHODE DE MISE Á... - Page 10 VACUFLO cleaning attachment, the attachment will be repaired or replaced (at H-P Products, Inc. option) at an authorized VACUFLO dealer location at no cost to you for three (3) years from original date of consumer purchase. Electric powerheads and hoses are warranted to be free from defects in material and workmanship under normal use and care for one (1) year from original date of purchase, as more fully set forth in the electric powerhead manual.
