Page 1 R-320 Operator’s Manual Serial #...
Page 2 All equipment manufactured by UniVersal Labeling Systems, Inc. carries a 30- day performance guarantee. If your machinery does not perform as described in our quote to you, UniVersal must be notified within 30 days of your dissatisfaction and we will make every attempt to correct it. If after a reasonable period of time, the machine does not meet the specified performance, we will take your machine back and reimburse you in full.
Page 3 Warranty Assembly and Operation Drawings Layout, Main Exploded View (conveyor) Exploded view BASE Conveyor Assembly, Applicator Crank Micro Adjustor Sensor Mounting Bracket SBK Wipe Down WPD-500 R320 Elect. Control box R320 Control Box Electrical Schematic Product Spacer Turning Unit BOM Turning Unit Mounting Assy CP-1000 Electrical Schematic L15...
Page 4 MODEL R-320 ASSEMBLY AND OPERATING INSTRUCTIONS Conveyor Height can be adjusted from your system’s specified height by adjusting the leveling pads RE-TIGHTEN LOCKING BOLT AND ANGULAR BRACE, BEFORE REMOVING SUPPORT AT BOTH ENDS OF CONVEYOR. FAILURE TO RE-TIGHTEN THE LOCKING SCREW ON SLIDING SLEEVE COULD RESULT IN THE CONVEYOR AND ATTACHMENTS DROPPING, CAUSING SERIOUS DAMAGE TO THE SYSTEM.
Page 5 MODEL R-320 ASSEMBLY AND OPERATING INSTRUCTIONS 8. Stop conveyor by turning speed control to “O”. Turn off turning unit. Plug power cord of applier into control box on front of conveyor. (NOTE: Applier and turning unit will not receive power with switch on control box on front of conveyor in OFF position).
Page 6 MODEL R-320 ASSEMBLY AND OPERATING INSTRUCTIONS IT IS EXTREMELY IMPORTANT THAT SPEEDS OF LABEL DELIVERY AND PRODUCT BE MATCHED FOR SATISFACTORY PLACEMENT AND WIPE DOWN OF LABEL. If label is tending to walk up or down on container, label applier may be rotated to position peeler bar in parallel with container, so that label is started on container accurately, by loosening large hex nut on swiveling bracket that applier is secured to and located on sliding sleeve on post.
Page 7 SUGGESTED SPEED SETTING As tested at the factory, the following are suggested setting of speeds and time delays: DIAL SETTING * Conveyor Speed _______________ * Turning Unit _______________ * Applier _______________ Product Spacer _______________ These settings will product approximately _______________ parts per minute production If speed of any of the above “*”...
Page 8 When machine is received, open carton carefully and remove machine by placing hands under machine base for lifting. Place machine on flat surface for installation of label roll holder to machine. (NOTE: Acorn nuts and hex nuts to be removed). Slide label reel over the two threaded studs, secure with hex nuts, then install the two acorn nuts.
Page 10 R320 AUTOMATIC SYSTEM WITH L15H APPLICATOR RECOMMENDED SPARE PARTS PART # PART DESCRIPTION 200109 MICRO SWITCH, LABEL SENSING 200198 POWER MODULE 420173 STARWHEEL SPRING L-129-S STARWHEEL, LABEL SENSING L-137-H DRIVE ROLLER (HD) L-140-F-3 SLIP CLUTCH COLLAR (REPLACES L-140-F-2) L-175-1 ASSY. SPROCKET W/FELT & BEARINGS L-143 LOWER IDLER ROLL ASSY (KNURLED ALUMINUM) L-176-1...
Page 20 TA-2/4 2 & 4 INCH TURNING UNITS Bill of Material PART# DESCRIPTION 300022 MOTOR, (1/4 HP. 100 RPM.) 400016 BEARING, (SEALED 3/8” 99R6) 410000 CHAIN, (# 25 LINK 19.375”) 410001 LINK, (# 25 MASTER) 600007 BELT, (2" X 37-1/4” 2" TA) 600008 BELT, (4"...
Page 21 TA-2/4 2 & 4 INCH TURNING UNITS Bill of Material PART# DESCRIPTION TA-2-215B GUIDE, BACK PLATE SS-112 KNOB, MICROMETER ADJ. TA-2-215A PLATE, TURN-AROUND MOUNT FLOOR STOCK BOLT, 3/8 x 2-1/4 H.H.M.S FLOOR STOCK WASHER, #10 x .06 THK. FLOOR STOCK WASHER, 1/4”...
