I NS T A L LAT I O N MA N UAL F O R TR U E F O O D PR E P M O DE L S
TFP-32-12M-D-2
T R U E F O OD P RE P MODEL S
............ www.truemfg.com ............
TRUE FOOD SERVICE EQUIPMENT, INC.
2001 East Terra Lane • O'Fallon, Missouri 63366-4434
(636)-240-2400 • FAX (636)272-2408 • INT'L FAX (636)272-7546 • (800)325-6152
Parts Department (800)424-TRUE • Parts Department FAX# (636)272-9471

TABLE OF CONTENTS

Cleaning Condenser Coil
CONGRATULATIONS!
You have just purchased the finest commercial
refrigerator available. You can expect many years of
trouble-free operation.
1
2
3
3
4
4
4
5
6
7
7
8
8
9
10
10
10
11-12
13-14
14
15
#954377
