paper support
sheet feeder
left edge
guide
Accessories
Ink Cartridges
Cartridge
Part number
Black
T013201 (U.S.) or T013311 (Canada and Latin America)
Color
T014201 (U.S.) or T014311 (Canada and Latin America)
printer cover
output tray
ink cartridge clamps
ink cartridge holders
(do not remove)
Media
Media name
EPSON 360 dpi Ink Jet Paper
EPSON High Quality Ink Jet Paper Letter
EPSON Photo Quality Ink Jet
Paper
EPSON Photo Quality Glossy
Paper
EPSON Photo Quality Glossy Film Letter
EPSON Photo Paper
EPSON Ink Jet Transparencies
EPSON Photo Quality Ink Jet
Cards
EPSON Photo Quality Ink Jet Note
Cards
EPSON Glossy Photo Greeting
Cards
EPSON Photo Stickers Kit
(CD-ROM and paper)
EPSON Photo Stickers
(refill, paper only)
EPSON Iron-On Cool Peel Transfer
Paper
EPSON Photo Quality Self
Adhesive Sheets
EPSON Matte Paper -
Heavyweight
The Media Type setting for your paper may not be the
same name as your paper.
The availability of paper types varies by location.

Printer Specifications

Printing
Printing method
On-demand ink jet
Nozzle configuration
Black
48 nozzles
Color
45 nozzles
(15 each: cyan, magenta, yellow)
Maximum 1440 dpi × 720 dpi
Resolution
Print direction
Bidirectional with logic seeking
Control code
ESC/P
Input buffer
16KB
8/00

EPSON Stylus Color 580

Size
Part number
Letter
S041060
A4
S041059
S041111
A4
S041117
Letter
S041062
A4
S041161
Legal
S041067
Letter
S041124
A4
S041126
S041072
A4
S041071
A6
S041107
Letter
S041141
A4
S041140
4 × 6 inches
S041134
Panoramic
S041145
Letter
S041064
A6
S041054
A6 (4.1 x 5.8
S041147
inches)
4.75 x 7 inches
S041267
(folded)
A6, 16 frames per
S041144-KIT
sheet
A6, 16 frames per
S041144
sheet
Letter
S041153/
S041155
A4
S041106
Letter
S041257
®
Raster, EPSON Remote
EPSON Stylus Color 580
1
-
