Preparation for using your new TV
The Y, PB!CB and PRiCR" connectors on your component devices (PVR or DVD) are sometimes labeled Y, Boyand R=Y
or "_', C B and CR (Colors for inputs and cables must correspond to both devices)
NOTE: Some devices such as a PVRor DVD players require 'ComponentiYPBPR' signal to be set via output in the
devices settings. Please consuUtyour device user manual for instructions.
Connecting HDM%
Suppo_s digital connections between HDHI =enabled AV devices such as (PVRs, DVD, BluRay, HDDVD, AV receivers
and digital devices), No sound connection is needed for an HDHI to HDHI connection,
NOTE: Some devices such as a PVR or DVD players require a HDHI signal to be set via the output in the devices'
seWngs, Please consult your device user manual for instructions.
What is HDHI?
HDHI, or high-definition multimedia interface, is a nextogeneration interface that enables the transmission of digital
audio and video signals using a single cable without compression.
"Hultimedia interface" is a more accurate name for it especially because it allows multiple channels of digital audio
(5ol channe[s).The difference between HDHI and DVI is that the HDHI device is smaller in size, has the HDCP (High
Bandwidth Digital Copy Protection) coding feature installed, and suppo_s multi - channel digital audio.
Use the HDHI terminal for HDHI connection to a compatible device.
If your external device has DVI only, you should use a DVIotooHDMI cable( or adapter) for the connection, and the "R
=AUDIO-L" terminal on DVI for sound output,
Connecting computer
Connect the D=Sub cable to "VGA (VGA IN)" on the rear of your set and the other end to the Video Card of your
Connect the stereo audio cable to "VGA AUDIO IN" on the rear of your set and the other end to "Audio Out" of the
sound card on your computer.
This device may not be compatible with all PCvideo/graphic cards.
Connecting audio
Connect RCA audio cables to "R =AUDIO = L" on the rear of your set and the other ends to corresponding
audio in connectors on the Amplifier or DVD Home Theater.
10
