Grace Digital Audio GDI-AQCSE100 Manual

Waterproof Active Speaker (Model: GDI-AQCSE100,101,102,103,104,105)

Specifications

Frequency Range: 160Hz-20,000Hz
Output Power: 2.5W RMS
Power Source: 3 x AA-size batteries
Battery Life: 30 + hours with alkaline batteries
Dimensions: 7.3" (L) x 4.7" (W) x 2.6" (H), or 18.6cm (L) x 12.0cm (W) x 6.5cm (H)
Weight: 1.06lb / 480g
Max additional floating payload (MP3 player, keys, documents etc): 8 ounces
Temperature (Operating): -5°C to 40°C
Temperature (Storage): -10°C to 55°C

Introductions

Thank you for purchase of the Grace Digital Eco Extreme speaker case. The Eco Extreme case is a waterproof and
dirt proof case with a built in amplified speaker. The case will hold your MP3 player, cell phone, keys, and
anything you want to keep safe from the elements. Enjoy!

Location of controls

1) Power / volume knob: To optimize your speaker's sound set your audio device's volume (iPod, cell phone,
mp3 player etc) between the 70-80% levels. Rotate the Eco Extreme's volume knob to the right to
increase volume. To turn the Eco Extreme 'off', turn the knob to the left until a 'click' is felt and the LED
above the volume knob turns 'off'.
2) Power LED: The LED above the volume knob is 'on' when the batteries are in use even if you do not hear
sound from the speaker. To optimize the lifespan of the batteries please turn the Eco Extreme off when
not listening to music.

Installing batteries

1) Open the Eco Extreme and remove the battery door. The battery door is located on the inside of the Eco
Extreme.
