Dear Customer
If you require any help with your product, whether it
is a Warranty claim, spare part or user information,
please phone our Help Line for an immediate response.
Phone 1300 880 001 in Australia or 0800 445 721 in
New Zealand.

Introduction

Your new GMC power tool will more than satisfy your
expectations. It has been manufactured under stringent
GMC Quality Standards to meet superior performance
criteria.
You will find your new tool easy and safe to operate,
and, with proper care, it will give you many years of
dependable service.
Caution. Carefully read through this entire Instruction
Manual before using your new GMC Power Tool. Take
special care to heed the Cautions and Warnings.
Your GMC power tool has many features that will make
your job faster and easier. Safety, performance, and
dependability have been given top priority in the
development of this tool, making it easy to maintain
and operate.

Environmental protection

Recycle unwanted materials instead of
disposing of them as waste. All tools, hoses
and packaging should be sorted, taken to
the local recycling centre and disposed of
in an environmentally safe way.

Description of symbols

The rating plate on your tool may show symbols. These
represent important information about the product or
instructions on its use.
Wear hearing protection.
Wear eye protection.
Wear breathing protection.
Conforms to relevant standards for
electromagnetic compatibility.

Specifications

Parameter Model AC24L
Power 2hp/1.5kW
Voltage 230–240Vac ~ 50Hz
No load speed 2850 RPM
Current 7A
Output at 0.8MPa
(115psi) 0.1m3/min
Discharge pressure 0.8MPa (115psi)
Restart pressure 0.5MPa (70psi)
Tank capacity 24 litres
Air outlet size 6.35mm (1/4")
Dimensions 600mm x 360mm
x 640mm
Net weight 27kg
Cut-in pressure (factory set)
Cut-out pressure (factory set) 0.8MPa (115psi)
Maximum output pressure
Free air delivery
Pump displacement
4
Model AC40L
2.5hp/1.8kW
2850 RPM
8A
40 litres
685mm x 300mm
x 720mm
35kg
0.6MPa (85psi)
0.8MPa (115psi)
117 l/min (4.15 cfm)
206 l/min (7.3 cfm)
