- Page 1 ULTRA QUIET OIL FREE AIR COMPRESSORS OwnER'S MAnUAL 461 A Customer Support 1-866-409-4581...
-
Page 2: Table Of Contents
Model: GMC ® Syclone 6310 ® Model: GMC Syclone 3010 ® ® The GMC Trademark is used under license from General Motors Corporation. GMC or General Motors Corporation makes no representation or warranties with respect to this product. Customer Support: 1-866-409-4581... -
Page 3: Important Safety Instructions
DANGER ® Even quality built equipment, such as the GMC Air Compressor you purchased, might need service or repair parts. Contact the ® California Air Tools GMC Air Compressor Customer Service... - Page 4 air compressor WARNING WARNING RISK TO BREATHING FLYING OBJECTS Flying objects can cause injury to the eyes, head and Dust or dust-like particulates caused by other parts of the body. power-sanding, sawing, grinding, drilling or any other construction-like activities can contain Air-powered equipment and power tools are capable contaminants that are harmful to breathe.
- Page 5 air compressor WARNING WARNING EXPLOSION EXPLOSION FIRE Improper care could lead to the air tank bursting or Use caution to minimize risk of fire or explosion. exploding. It is normal for the air compressor motor and Drain air tank daily or after each use to prevent pressure switch to produce sparks while operating.
-
Page 6: Locations Of Important Labels
California Air Tools ® Air Compressors Customer Service department at 1-866-409-4581 for replacements. model: gmc ® Syclone 4610a / 4610 Note: 1. The air compressor should only be placed in a well-ventilated and clean area. - Page 7 ® Syclone 6310 PRODUCT LAbEL Note: 1. The air compressor should only be placed in a well-ventilated and clean area. 2. Keep the air compressor on a firm and flat surface, with adequate space surrounding it for ventilation.
- Page 8 ® Syclone 3010 PRODUCT LAbEL Note: 1. The air compressor should only be placed in a well-ventilated and clean area. 2. Keep the air compressor on a firm and flat surface, with adequate space surrounding it for ventilation.
-
Page 9: Air Compressor Components
CompreSSor model: gmc ® Syclone 4610a Syclone 4610 ® ComponenTS description description description description Fan Cover Metal Strengthen Sheet bolt Washer Pressure Switch Crank Case Crank Joint Safety Valve Connecting Rod bearing bolt Drain Valve Piston Ring... - Page 10 ® Syclone 6310 description description description Fan Cover Handle Cover Crank Elbow Crank Case bearing Exhaust Pipe Connecting Rod Holding Screw Electromagnetism Valve Piston Ring Cheese Head Screw Check Valve Plate Pinch Crank Case Electrical Wire...
- Page 11 CompreSSor model:gmc Syclone 3010 ® ComponenTS description description description Fan Cover Pressure Gauge/Small Crank Pressure Gauge/Large Crank Case bearing Pressure Gauge Connector Connecting Rod Holding Screw Connecting bar Piston Ring Cheese Head Screw Safety Valve Plate Pinch...
-
Page 12: Pre-Operation Checklist
CheCklIST package contents & assembly model: gmc ® SycLone 4610a / 4610 model: gmc ® SycLone 6310 package contents: package contents: Air Compressor Air Compressor Owner's Manual Owner's Manual Air Filter Air Filter Wheel Assembly Kit assembly: 1. -
Page 13: Inspect For Damage
air compressor Inspect for damage maintain a clear area It is very important that the air compressor is positioned so that before using the air compressor, make sure the air tank is not there is adequate airflow around the machine. There must be at damaged, inspect all parts for damage, and check that all pipes least 2 feet of obstacle-free space surrounding and above the air are firmly connected. -
Page 14: Electrical Power
air compressor operaTIng The aIr electrical power CompreSSor electrical power requirements DANGER Save this manual for future reference. SHOCK There is a danger of electric shock. Use only undamaged electrical cords. DO NOT touch bare wires or receptacles. Introduction DO NOT operate air compressor in wet weather or in This air compressor features a compact structure, stable wet conditions. -
Page 15: Daily Operation
air compressor test run WARNING before using the air compressor for the first time, complete a test run as follows: 1. Turn the power switch to the OFF position. Plug the power supply cord into a power supply socket. Start the air compressor by turning the power switch to the ON position. -
Page 16: Maintenance
air compressor maInTenanCe draining the air tank adjusting the pressure Switch The frequency at which you should drain the air tank depends on The pressure switch is used to control the automatic stop-and- the environmental conditions and the amount of operating time start function of the air compressor, ensuring the correct pressure logged. -
Page 17: Troubleshooting
air compressor TroubleShooTIng probLem poSSIbLe cauSe poSSIbLe SoLutIonS Let the compressor build pressure in the tank, to the maximum pressure if possible. brush soapy Pressure drop in the tank. Air leaks at connections. water on air connections and look carefully for air bubbles. -
Page 18: Specifications
Compressor Tank Filter Check valve Solenoid Ball valve valve Syclone 3010 air compressor model Syclone 4610 / 4610a Syclone 6310 Output @ 40 PSI 3.80 CFM 3.80 CFM 3.80 CFM Output @ 90 PSI 2.35 CFM 2.35 CFM 2.35 CFM... - Page 19 San Diego, CA 92154 Limited Warranty ® California Air Tools Inc. will repair or replace, free of charge, to the original retail customer who purchased a GMC Syclone Air Compressor from an authorized dealer, distributor or distributor’s dealer in North America.
-
Page 20: Warranty
® Syclone Air Compressor Service Center. Service ® Do not return your air compressor to the place of purchase or any GMC car/truck dealership. ® For all customer service inquiries call California Air Tools GMC Air Compressor Customer Service at 1-866-409-4581 or visit www.GMCPOWEREQUIPMENT.com. -
Page 21: Product Registration
air compressor produCT regISTraTIon To register your product, please complete the information below and mail to the mailing address at the end of this form, or register online at WWW.GMCPOWEREQUIPMENT.COM 1. personal Information: Full Name (Include Middle Initial): _______________________________________________________________ Mailing Address: _____________________________________________________________________________ City:___________________________________ State:_______________ Zip Code: _______________________ Phone Number: _____________________________________________________________________________ E-mail Address: _____________________________________________________________________________...
