GE Monogram ZDP48L4GWSS Dimension Manual page 2

Monogram. ™
ZDP48L4GWSS—48" Professional Ranges
Dimensions and Specifications (in inches)
18" Min.
8"
3/-1/4"
35-3/8" Max. for Counter Level
36-3/4" Max. with Range Leveling Legs Fully Extended
29-1/16"
12"
3-1/4"
High
21-1/4"
Shelf
12"
Low Back
0" Clearance
28-1/4"
31-1/2"
45-5/8"
Revised 7/97
48" Wide Range Hood
8"
13"
Max.
16"
12" Min. to
Combustible
12"
Material
Each Side
Cooking Surface
3/-1/2"
Electrical Supply
Gas Supply
36" Min.
to Combustibles
1-1/2"
If the range is installed in an island:
• Allow 12" min. clearance at the back to combustible
• Allow 36" min. above the cooking surface to
36" Min. to
Combustible
• Installation must conform with local codes. In the
Material From
Cooking Surface
A.G.A. approved
Installation Information:
Before installing, consult installation instructions
(Pub. #49-8786) packed with product for current
dimensional data.
12" Min. to Combustibles
Without Backguard
36" Min.
to Combustibles
Island Trim
0" Clearance
For answers to your GE Monogram,
GE, Hotpoint and RCA appliance questions, call
GE Answer Center
materials.
combustible materials.
– The vent hood blower should provide at least
800 CFM and up to 1200 CFM.
absence of local codes, the range must comply with
the National Fuel Gas Code, ANSI Z223.1-1990.
® service, 800.626.2000.
U L
Listed by
Underwriters
R
Laboratories
™ GE Profile, ™
