5. Remove the screw securing the M-SATA board to the upper case assembly.
Figure 3-21. M-SATA Board Screw
Table 3-21. Screw
Step
M-SATA Board Disassembly
6. Detach the M-SATA board from the upper case assembly.
Figure 3-22. M-SATA Board
NOTE:
NOTE:
A circuit board that is > 10cm
Figure
3-22. Follow the local regulations for disposing this type of circuit board.
3-16
Screw
M2 x L3
2
has been highlighted with a yellow rectangle in
Quantity
Screw Type
1
Machine Maintenance
