Removing the Battery Pack

1. Perform the "Removing the Lower
2. Remove the screw securing the battery pack to the upper case.
Figure 3-5. Battery Pack Screw
Table 3-5. Screw
Step
Battery Pack Disassembly
3. Lift the battery pack off its socket in the upper case assembly, then slide it a few
millimeters away from the mainboard.
Figure 3-6. Battery Cable
3-8
Case" procedure described on page 3-7.
Screw
M2 x L2
Quantity Screw Type
1
Machine Maintenance
